233-103-H9Z115

for MIL-DTL-38999 Series III Type Shell Size 09 11 13 15 17 19 21 23 25 2.000 (50.8) Max Insert Arrangement Per MIL-DTL-38999 Series III MIL-STD-1560 Contact Termination P - Pin on Plug Side S - Socket on Plug Side Connector Series 233 - D38999 Series III Type Connector Type 103 - Hermetic Bulkhead Feed-Thru .890 (22.6) Max .125 (3.2) 233 - 103 - H9 P 11 - 35 P N - 01 Shell Style H9 - Jam Nut Mount Plug/ Receptacle Gender Changer Connector Material and Finish Z1 - CRES, Passivated ZL - CRES, Nickel Finish Alternate Positions: A, B, C, D, E (N = Normal) Panel Accomodation 01 - .0625″ (Min) .125″ (Max) 02 - .0625″ (Min) .250″ (Max) 03 - .0625″ (Min) .500″ (Max) A Thread F Thread Panel Accomodation .520/.500 (13.2/12.7) to rear of red full-mate indicator band Insert Arrangements per MIL-DTL-38999 Series III MIL-STD-1560 TABLE I: CONNECTOR DIMENSIONS SHELL SIZE 9 11 13 15 17 19 21 23 25 A THREAD 0.1 P-0.3L-TS-2 .6250 .7500 .8750 1.0000 1.1875 1.2500 1.3750 1.5000 1.6250 B DIM .945(24.0) 1.063(27.0) 1.260(32.0) 1.417(36.0) 1.457(37.0) 1.614(41.0) 1.811(46.0) 1.968(50.0) 2.017(51.2) C DIM MAX 1.090(27.7) 1.280(32.5) 1.400(35.6) 1.530(38.9) 1.660(42.2) 1.840(46.7) 1.970(50.5) 2.090(53.1) 2.210(56.1) D DIA .698(17.7) .822(20.9) 1.010(27.6) 1.135(28.8) 1.260(32.0) 1.385(35.2) 1.510(38.4) 1.635(41.5) 1.760(44.7) E DIM .322(8.9) .385(9.8) .479(12.3) .541(13.7) .604(15.3) .635(16.1) .698(17.7) .760(19.3) .822(20.9) F THREAD x1-6g-0.100R M17 M20 M25 M28 M32 M35 M38 M41 M44 E D Dia B C Recommended Panel Cut-Out APPLICATION NOTES 1. 2. 3. Power to a given contact on one end will result in power to contact directly opposite, regardless of identification letter. Hermeticity = less than 1 x 10-4 cc/sec at one atmosphere. Not for use in liquid atmosphere. Material/finish: Shell, nut – CRES/passivated, carbon steel/fused tin or CRES/nickel per QQ-N-290. 4. Contacts – Gold Plated. Pin: alloy 52; Skt.: copper alloy Insulator – fused vitreous glass/N.A. Seals – fluorosilicone rubber/N.A. Metric dimensions (mm) are indicated in parentheses. © 2008 Glenair, Inc. www.glenair.com CAGE CODE 06324 Printed in U.S.A. E-Mail: sales@glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-13 Bulkhead Feed-Thrus 233-103-H9 Jam Nut Mount Hermetic Plug/Receptacle Bulkhead Feed-Thru E
