240-030-33-9SP

Micro-D Connectors Micro-D Solder Cup Basic Part Number Filter Connector Product Code Shell Finish (See Table I) 240-030 Micro-D Filter Connectors Solder Cup Contact Type P - Pin S - Socket Filter Class A, B, C, D, E, F or G (See Table III) 240 - 030 - 2 - 25 P P Filter Type P - Pi Circuit C - C Circuit B P Hardware (See Table II) Number of Contacts 9, 15, 21, 25, 31, 37 A B C PI FILTER .800 (20.32) MAX. C FILTER .500 (12.70) MAX. .600 (15.24) F D E D .096/.088 (2.43/2.23) DIA. .125 (3.18) MAX, .093 ± .005 (2.36 ± 0.13) H .287 (7.3) .322 (8.18) Max Glenair’s Filtered Solder Cup Micro-D's provide EMI solutions in a miniaturized M83513 type connector. These connectors feature ceramic capacitor planar arrays and ferrite inductors. Solder cups accept #26 thru #30 AWG wire, or specify oversize contacts for #24 gage wire. Choose Pi or C Filter Arrays in seven filter classes and eight layouts. Glenair filtered Micro-D connectors comply with applicable MIL-DTL-83513 requirements and are 100% intermateable with standard connectors. Choose 9 to 67 Contacts, with standard cadmium or nickel plating on the connector housing or choose optional finishes such as gold or chem film. © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-6 240-030 Micro-D Filter Connectors Solder Cup TABLE lll: CAPACITOR ARRAY CODE CAPACITANCE RANGE TABLE I: SHELL FINISH SYM 1 2 5 6 33 MATERIAL Aluminum Aluminum Aluminum Aluminum Aluminum FINISH DESCRIPTION Cadmium Nickel Gold Chem Film Ni-PTFE 1000 Hour GreyTM CLASS A B C D E F G PI - CIRCUIT (pF) 38,000 - 56,000 32,000 - 45,000 18,000 - 33,000 8,000 - 12,000 3,300 - 5,000 800 - 1,300 400 - 600 C - CIRCUIT (pF) 19,000 - 28,000 16,000 - 22,500 9,000 - 16,500 4,000 - 6,000 1,650 - 2,500 400 - 650 200 - 300 TABLE ll: MICRO-D MOUNTING HARDWARE B P M M1 S S1 L K F R Thru-Hole Jackpost Jackscrew Jackscrew Jackscrew Jackscrew Jackscrew Jackscrew Float Mount Float Mount Order Hardware Separately Removable Includes Nut and Washer Hex Head Removable E-ring Hex Head Removable E-ring Extended Slot Head Removable E-ring Slot Head Removable E-ring Extended Hex Head NonRemovable Slot Head NonRemovable Extended For Front Panel Mounting For Rear Panel Mounting MICRO-D FILTER SOLDER CUP DIMENSIONS A Max. Layout 9P 9S 15P 15S 21P 21S 25P 25S 31P 31S 37P 37S In. .785 .785 .935 .935 1.085 1.085 1.185 1.185 1.335 1.335 1.485 1.485 mm. 19.94 19.94 23.75 23.75 27.56 27.56 30.01 30.01 33.91 33.91 37.72 37.72 ± .003 .565 .565 .715 .715 .865 .865 .965 .965 1.115 1.115 1.265 1.265 In . B ± 0.08 mm. C Max. In. .333 .400 .483 .551 .633 .701 .733 .801 .883 .951 1.033 1.101 D Max. In. .184 .250 .184 .250 .184 .250 .184 .250 .184 .250 .184 .250 E Max. In. .310 .310 .310 .310 .310 .310 .310 .310 .310 .310 .310 .310 mm. 8.46 10.16 12.27 14.00 16.08 17.81 18.62 20.35 22.43 24.16 26.24 27.96 mm. 4.67 6.35 4.67 6.35 4.67 6.35 4.67 6.35 4.67 6.35 4.67 6.35 mm. 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 ± .004 .183 .195 .183 .195 .183 .195 .183 .195 .183 .195 .183 .195 In. F mm. ± 0.10 4.65 4.95 4.65 4.95 4.65 4.95 4.65 4.95 4.65 4.95 4.65 4.95 H Max. In. .400 .400 .550 .550 .700 .700 .800 .800 .950 .950 1.100 1.100 mm. 10.16 10.16 13.97 13.97 17.78 17.78 20.32 20.32 24.13 24.13 27.94 27.94 14.35 14.35 18.16 18.16 21.97 21.97 24.51 24.51 28.32 28.32 32.13 32.13 © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-7 Micro-D Connectors D
