240-031-2-37SP

Micro-D Connectors Micro-D Vertical Mount PCB Basic Part Number Filter Connector Product Code Shell Finish (See Table I) Vertical Mount Printed Circuit Board 240-031 Micro-D Filter Connectors PC Tail Length (Inches) 1 - .110 (2.79 mm) 2 - .250 (6.35 mm) Filter Type P - Pi Circuit C - C Circuit Contact Type PS - Pin/Socket 240 - 031 - 2 - 25 PS C D 1 PN Number of Contacts 9, 15, 21, 25, 31, 37 Filter Class A, B, C, D, E, F or G (See Table II) A B C D E D .096/.088 (2.43/2.23) DIA. PI FILTER .930 (23.62) MAX. C FILTER .530 (13.46) MAX. F Hardware Option NN - No Jackpost, No Threaded Insert PN - Extended Jackpost for .062" (1.6) PCB, No Threaded Insert RN - Extended Jackpost for .196" (5.0) PCB, No Threaded Insert NU - Threaded Insert Only, No Jackposts PU - Short Jackpost and Threaded Insert Rear Panel Jackposts with Threaded Insert: R6U - 0.125" (3.2) Panel R5U - 0.094" (2.4) Panel R4U - 0.062" (1.6) Panel R3U - 0.047" (1.2) Panel R2U - 0.031" (0.8) Panel Jack screw Options: M - Hex Head Jackscrews S - Slot Head Jackscrews .025 (0.64) Ø.018 ± .002 (0.46 ± 0.05) TAIL LENGTH ± .015 (± 0.38) Printed Circuit Board Micro-D Filter Connectors. These vertical mount PCB connectors are ideal for flexible circuit or motherboard applications. Integral Board Standoffs and Pre-Tinned Tails—These connectors are solder dipped (63/37 SnPb) and feature a full complement of mounting hardware options. © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-8 Vertical Mount Printed Circuit Board 240-031 Micro-D Filter Connectors TABLE ll: CAPACITOR ARRAY CODE CAPACITANCE RANGE* TABLE I: SHELL FINISH SYM 1 2 5 6 33 MATERIAL Aluminum Aluminum Aluminum Aluminum Aluminum FINISH DESCRIPTION Cadmium Nickel Gold Chem Film Ni-PTFE 1000 Hour GreyTM CLASS A B C D E F G PI - CIRCUIT (pF) 38,000 - 56,000 32,000 - 45,000 18,000 - 33,000 8,000 - 12,000 3,300 - 5,000 800 - 1,300 400 - 600 C - CIRCUIT (pF) 19,000 - 28,000 16,000 - 22,500 9,000 - 16,500 4,000 - 6,000 1,650 - 2,500 400 - 650 200 - 300 MICRO-D FILTER PIGTAIL DIMENSIONS A Max. Layout 9P 9S 15P 15S 21P 21S 25P 25S 31P 31S 37P 37S In. .785 .785 .935 .935 1.085 1.085 1.185 1.185 1.335 1.335 1.485 1.485 mm. 19.94 19.94 23.75 23.75 27.56 27.56 30.01 30.01 33.91 33.91 37.72 37.72 ± .003 .565 .565 .715 .715 .865 .865 .965 .965 1.115 1.115 1.265 1.265 In . B ± 0.08 mm. C Max. In. .333 .400 .483 .551 .633 .701 .733 .801 .883 .951 1.033 1.101 D Max. In. .184 .250 .184 .250 .184 .250 .184 .250 .184 .250 .184 .250 E Max. In. .310 .310 .310 .310 .310 .310 .310 .310 .310 .310 .310 .310 mm. 8.46 10.16 12.27 14.00 16.08 17.81 18.62 20.35 22.43 24.16 26.24 27.96 mm. 4.67 6.35 4.67 6.35 4.67 6.35 4.67 6.35 4.67 6.35 4.67 6.35 mm. 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 7.87 ± .004 .183 .195 .183 .195 .183 .195 .183 .195 .183 .195 .183 .195 In. F mm. ± 0.10 4.65 4.95 4.65 4.95 4.65 4.95 4.65 4.95 4.65 4.95 4.65 4.95 14.35 14.35 18.16 18.16 21.97 21.97 24.51 24.51 28.32 28.32 32.13 32.13 © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-9 Micro-D Connectors D Micro-D Connectors A Vertical Mount PCB Hardware Options Connector Supplied Without Hardware Connector Supplied With Threaded Inserts 240-031 Micro-D Filter Connectors A DIAMETER 9-51 CONTACTS .096/.088 (2.44/2.24) 100 CONTACTS .150/.145 (3.81/3.68) 9-51 CONTACTS NO. 2-56 UNC-2B 100 CONTACTS NO. 4-40 UNC-2B Thru-Hole, No Hardware Jackpost and Threaded Insert NN Style Threaded Insert Rear Panel Jackpost and Threaded Insert NU Style D Ø.018 ± .002 (0.46 ± 0.05) .160 (4.1) MIN. (9-51 PINS) .225 (5.7) MIN. (100 PIN) .160 (4.1) MIN. (9-51 PINS) .225 (5.7) MIN. (100 PIN) PU Style Jackpost with Threaded Insert Extended Jackpost RU Style Rear Panel Jackpost with Threaded Insert Jackscrew, Hex Jackscrew, Slot PC BOARD PN Style for .062" PCB RN Style for .196" PCB M Style Hex Head Jackscrew with E-Ring S Style Slot Head Jackscrew with E-Ring © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-10 Vertical Mount PCB Pin Connector Layouts 240-031 Micro-D Filter Connectors PC Tail Diameter .018 ± .002 (0.46 ± 0.05) Contact numbers shown are for pin connectors. Reverse for socket. .050 (1.27) TYP .025 (0.64) TYP 1 6 5 1 9 9 .050 (1.27) TYP .025 (0.64) TYP 8 15 .050 (1.27) TYP .565 (14.35) .096 (2.44) DIA TYP .050 (1.27) TYP .715 (18.16) .096 (2.44) DIA TYP 9 Contacts 15 Contacts .050 (1.27) TYP .025 (0.64) TYP 1 12 11 1 14 21 .050 (1.27) TYP .025 (0.64) TYP 13 25 .050 (1.27) TYP .865 (21.97) .096 (2.44) DIA TYP .050 (1.27) TYP .865 (21.97) .096 (2.44) DIA TYP 21 Contacts 25 Contacts .050 (1.27) TYP .025 (0.64) TYP 1 17 16 31 1 .050 (1.27) TYP .025 (0.64) TYP 19 .050 (1.27) TYP 1.115 (28.32 .096 (2.44) DIA TYP 20 .050 (1.27) TYP 1.265 (32.13) 37 .096 (2.44) DIA TYP 31 Contacts © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 37 Contacts Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com D-11 Micro-D Connectors D
