249-002-17C

EMI Shielding Accessories Product Series C Typ A Typ B Dia Flange Mount Receptacle Connector 249-002 Conductive Gasket for Basic Number Material Symbol (See Table II) 249 - 002 - 09 Dash Number (See Table I) H D Dia 4 Places E Radius .030 (0.8) H NOTES: 1. Identified by bag and tag in suitable quantities. 2. Metric dimensions (mm) are indicated in parentheses. © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-30 Flange Mount Receptacle Connector 249-002 Conductive Gasket for TABLE I Dash Number -09 -11 -13 -15 -17 -19 -21 -23 -25 A ± .005 .719 .812 .906 .969 1.062 1.156 1.250 1.375 1.500 ØB ± .007 .687 .772 .937 1.063 1.187 1.312 1.437 1.562 1.600 C ± .008 .937 1.031 1.125 1.250 1.343 1.467 1.652 1.703 1.812 ØD ± .005 .125 .125 .125 .125 .125 .125 .125 .152 .152 E Radius ± .015 .105 .105 .105 .135 .135 .135 .135 .135 .135 TABLE II Designator C Material Flourosilicone Binder with Passivated Silver Plated Aluminum Particles (CHO-Seal in 1298 or Equivalent) Silicone Binder with Silver Plated Copper Particles (CHO-Seal 1215 or Equivalent) H © 2008 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com H-31 EMI Shielding Accessories H
