265-002

181-047 GHD • Glenair High Density Fiber Optic Genderless Terminus Size 18 Keyed Terminus for APC Polish Glenair High Density C Fiber Optic ØA Ferrule Hole .066 (1.7 Max) © 2011 Glenair, Inc. Size 18 Glenair High Density (GHD) Fiber Optic Genderless Terminus, Keyed for APC Polish The Glenair High Density Fiber Optic Connector System is designed for applications that require reduced size and weight as well as outstanding optical and environmental performance. The System offers insertion loss values less than .5dB (typical loss for Glenair termini is .3 dB). Dense cavity spacing is acheived with an innovative front release terminus design and accomodation for M85045/16 cable. The 181-047 version is equipped with a single keying feature for APC polish. 1.112 (28.2) Max .200 (5.1) 1.25 mm Ferrule OD Retaining Clip Compression Bushing A Ferrule Ø .081 Max Spring Environmental Seal A Key .035 (00.9) Max View A-A Crimp Sleeve (see Table II) Material and Finish Ferrule: Zirconia Ceramic Terminus Assembly: Stainless Steel/ Passivate Retaining Clip: Spring Alloy Spring: High Tensile Stainless Steel/ Passivate O-Ring: Fluorosilicone Crimp Sleeve: Brass Alloy/Nickel Tools and Accessories Crimp Sleeve is supplied with Terminus Assembly, and may be ordered separately (see Table II). For terminus less crimp sleeve, omit C from end of part number (e.g. 181-047-1260) See Glenair assembly procedure GAP-032 for complete termination instructions. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 C-30 Size 18 Keyed Terminus for APC Polish Part Number 181-047-1250C 181-047-1255C 181-047-1260C 181-047-1270C 181-047-1420C 181-047-1450C 181-047-1560C 181-047-1570C 181-047-1730C 181-047-1750C 181-047-2360C 181-047-2860C 181-047-4480C ØA (Microns) 125.0 125.5 126.0 127.0 142.0 145.0 156.0 157.0 173.0 175.0 236.0 286.0 448.0 Typ. Fiber Type Single Mode Single Mode Single Mode OR Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode Multi Mode C CRIMP SLEEVE Part Number 265-002 Description Crimp Sleeve Ø2.2mm Max Jacket © 2011 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 C-31 Fiber Optic 181-047 GHD • Glenair High Density Fiber Optic Genderless Terminus
