469-001-04

469-001 Shield Support Ring for Use with G-Spring Backshells 469-001-22 Length Basic Part No. Dash No. For use with Series 460 and 463 G-Spring Backshells I.D. O.D. Dash I.D. No. ± .010 (.3) 01 .187 (4.7) 02 .218 (5.5) 03 .250 (6.4) 04 .281 (7.1) 05 .312 (7.9) 06 .343 (8.7) 07 .375 (9.5) 08 .406 (10.3) 09 .438 (11.1) 10 .468 (11.9) 11 .500 (12.7) 12 .531 (13.5) 13 .562 (14.3) 14 .593 (15.1) 15 .625 (15.9) 16 .656 (16.7) 17 .687 (17.4) 18 .718 (18.2) 19 .750 (19.1) 20 .781 (19.8) 21 .812 (20.6) 22 .843 (21.4) 23 .875 (22.2) 24 .906 (23.0) 25 .937 (23.8) 26 .968 (24.6) 27 1.000 (25.4) O.D. ± .010 (.3) .227 (5.8) .258 (6.6) .290 (7.4) .321 (8.2) .352 (8.9) .383 (9.7) .415 (10.5) .446 (11.3) .478 (12.1) .508 (12.9) .540 (13.7) .571 (14.5) .602 (15.3) .633 (16.1) .665 (16.9) .696 (17.7) .727 (18.5) .758 (19.3) .790 (20.1) .821 (20.9) .852 (21.6) .883 (22.4) .915 (23.2) .946 (24.0) .977 (24.8) 1.008 (25.6) 1.040 (26.4) Length (Note 2) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .50 (12.7) .75 (19.1) .75 (19.1) .75 (19.1) .75 (19.1) .75 (19.1) .75 (19.1) .75 (19.1) .75 (19.1) .75 (19.1) Dash No. 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 I.D. ± .010 (.3) 1.031 (26.2) 1.062 (27.0) 1.093 (27.8) 1.125 (28.6) 1.156 (29.4) 1.187 (30.1) 1.218 (30.9) 1.250 (31.8) 1.281 (32.5) 1.312 (33.3) 1.343 (34.1) 1.375 (34.9) 1.406 (35.7) 1.437 (36.5) 1.468 (37.3) 1.500 (38.1) 1.531 (38.9) 1.562 (39.7) 1.593 (40.5) 1.625 (41.3) 1.656 (42.1) 1.687 (42.8) 1.718 (43.6) 1.750 (44.5) 1.781 (45.2) 1.812 (46.0) 1.843 (46.8) Length O.D. ± .010 (.3) (Note 2) 1.071 (27.2) .75 (19.1) (27.2) 1.102 (28.0) .75 (19.1) (28.0) 1.133 (28.8) .75 (19.1) (28.8) 1.165 (29.6) .75 (19.1) (29.6) 1.196 (30.4) .75 (19.1) (30.4) 1.227 (31.2) .75 (19.1) (31.2) 1.258 (32.0) .75 (19.1) (32.0) 1.290 (32.8) .75 (19.1) (32.8) 1.321 (33.6) .75 (19.1) (33.6) 1.352 (34.3) 1.00 (25.4) (34.3) 1.383 (35.1) 1.00 (25.4) (35.1) 1.415 (35.9) 1.00 (25.4) (35.9) 1.446 (36.7) 1.00 (25.4) (36.7) 1.477 (37.5) 1.00 (25.4) (37.5) 1.508 (38.3) 1.00 (25.4) (38.3) 1.540 (39.1) 1.00 (25.4) (39.1) 1.571 (39.9) 1.00 (25.4) (39.9) 1.602 (40.7) 1.00 (25.4) (40.7) 1.633 (41.5) 1.00 (25.4) (41.5) 1.665 (42.3) 1.00 (25.4) (42.3) 1.696 (43.1) 1.00 (25.4) (43.1) 1.727 (43.9) 1.00 (25.4) (43.9) 1.758 (44.7) 1.00 (25.4) (44.7) 1.790 (45.5) 1.00 (25.4) (45.5) 1.821 (46.3) 1.00 (25.4) (46.3) 1.852 (47.0) 1.00 (25.4) (47.0) 1.883 (47.8) 1.00 (25.4) (47.8) 1. Finish : Clear Anodize 2. Consult factory for other available lengths. 3. Metric dimensions (mm) are indicated in parentheses. © 2005 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. www.glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com Series 460 - Page 3 460
