500-015-2SL-1

MIL-DTL-83513 Micro-D 500-015 Micro-D Backshell Clip C Dia .30 (0.8) Ref A B Screw Option See Part Number Development TABLE I: CLIP DIMS Dash A B C No. Dia 1 .172 (4.4) .210 (5.3) .090 (2.3) 2 .250 (6.4) .320 (8.1) .120 (3.0) HOW TO ORDER Shell Jackscrew Assembly SeriesType* Less Clip Basic Part Size Number (Table I) (Table II) (Jackscrew Only) 500-015 1 – 09- S – Fillister L – Assembly 51 H – Socket Less Clip 2 – 100 Clip Material 1 – Clip: Berillium Copper/Gold Plated Screw: Brass/Gold Plated (Omit for Std. Cres/Passivate) Sample Part Number: S 500-015 — 1 L — 1 Metric dimensions (mm) are indicated in parentheses © 2004 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-8
