500-016-J09EN4-06

Micro-D Backshells Switching/Shorting, One Piece 500-016 Shorting Backshells are closed shells used to provide a convenient way to protect Micro-D connectors used for circuit switching or shorting. Lanyards provide easy attachment to chassis panels. MATERIALS Shell Clips Hardware Aluminum Alloy 6061 -T6 17-7PH Stainless Steel 300 Series Stainless Steel HOW TO ORDER 500-016 SHORTING BACKSHELLS Series 500-016 E J M NF Z2 Shell Finish – Chem Film – Cadmium, Yellow Connector Size 09 15 21 25 31 37 51 51-2 67 69 100 Hardware Option B – Fillister Head Jackscrew Lanyard Option N – No Lanyard F – Wire Rope, Nylon Jacket Lanyard Length Length in One Inch Increments Example: “6” equals six inches. Ring Terminal Ordering Code 06 01 05 04 – – – – .125 (3.2) .140 (3.6) .167 (4.2) .197 (5.0) Chromate – Electroless Nickel – Cadmium, Olive H – Hex Head Jackscrew H – Wire Rope, Teflon Jacket E – Extended Jackscrew Drab – Gold F – Jackpost, Female I.D. of Ring Terminal Sample Part Number 500-016 –M 25 F B LENGTH H F 4 – 06 SEE ORDERING INFO D E A C .175 (4.4) CONNECTOR ORDERED SEPARATELY #2-56 UNC THDS. 9-69 PIN #4-40 UNC THDS. 100 PIN CODE B CODE H FILLISTER HEAD HEX HEAD JACKSCREW JACKSCREW CODE F FEMALE JACKPOST CODE E EXTENDED JACKSCREW A Max. Size 09 15 21 25 31 37 51 51-2 67 69 100 B Max. In. .370 .370 .370 .370 .370 .370 .410 .370 .370 .410 .460 C In. .565 .715 .865 .965 1.115 1.265 1.215 1.615 2.015 1.515 1.800 D Max. mm. 14.35 18.16 21.97 24.51 28.32 32.13 30.86 41.02 51.18 38.48 45.72 E Max. In. .350 .470 .590 .650 .710 .750 .780 .780 .780 .780 .840 F Max. In. .410 .580 .740 .850 .980 1.130 1.080 1.510 1.880 1.380 1.470 In. .850 1.000 1.150 1.250 1.400 1.550 1.500 1.910 2.310 1.810 2.235 mm. 21.59 25.40 29.21 31.75 35.56 39.37 38.10 48.51 58.67 45.97 56.77 mm. 9.40 9.40 9.40 9.40 9.40 9.40 10.41 9.40 9.40 10.41 11.68 In. .500 .620 .740 .800 .860 .900 .930 .930 .930 .930 .990 mm. 12.70 15.75 18.80 20.32 21.84 22.86 23.62 23.62 23.62 23.62 25.15 mm. 8.89 11.94 14.99 16.51 18.03 19.05 19.81 19.81 19.81 19.81 21.34 mm. 10.41 14.73 18.80 21.59 24.89 28.70 27.43 38.35 47.75 35.05 37.34 L © 2006 Glenair, Inc. CAGE Code 06324/0CA77 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com L-11 E-Mail: sales@glenair.com
