500-047-J15HM

Micro-D Backshells EMI, Elliptical, One Piece 500-047 Elliptical Backshells provide extra room for large wire bundles. This one piece version features an oversize shield termination area for both standard and micro BANDIT® shield termination straps. MATERIALS Shell Clips Hardware Aluminum Alloy 6061 -T6 17-7PH Stainless Steel 300 Series Stainless Steel HOW TO ORDER 500-047 ELLIPTICAL BACKSHELLS Series 500-047 E J M NF Z2 Shell Finish – Chem Film – Cadmium, Yellow Connector Size 09 15 21 25 31 37 51 51-2 67 69 100 Hardware Option B – Fillister Head Jackscrew EMI Band St rap Option Omit (Leave Blank) Band Not Included B – Standard Band .250" Wide .125" Wide Chromate – Electroless Nickel – Cadmium, Olive H – Hex Head Jackscrew E – Extended Jackscrew F – Jackpost, Female Drab – Gold M – Micro Band Sample Part Number 500-047 F B E H .175 (4.4) A D C –M G 25 H CONNECTOR ORDERED SEPARATELY #2-56 UNC THDS. 9-69 PIN #4-40 UNC THDS. 100 PIN CODE B CODE H FILLISTER HEAD HEX HEAD JACKSCREW JACKSCREW CODE F FEMALE JACKPOST CODE E EXTENDED JACKSCREW A Max. Size 09 15 21 25 31 37 51 51-2 67 69 100 B Max. In. .370 .370 .370 .370 .370 .370 .410 .370 .370 .410 .460 C In. .565 .715 .865 .965 1.115 1.265 1.215 1.615 2.015 1.515 1.800 D Max. mm. 14.35 18.16 21.97 24.51 28.32 32.13 30.86 41.02 51.18 38.48 45.72 In. .850 1.000 1.150 1.250 1.400 1.550 1.500 1.910 2.310 1.810 2.235 mm. 21.59 25.40 29.21 31.75 35.56 39.37 38.10 48.51 58.67 45.97 56.77 mm. 9.40 9.40 9.40 9.40 9.40 9.40 10.41 9.40 9.40 10.41 11.68 In. mm. E In. mm. ± .015 ± 0.38 .281 .281 .281 .281 .281 .281 .312 .281 .281 .312 .360 7.14 7.14 7.14 7.14 7.14 7.14 7.92 7.14 7.14 7.92 9.14 F Max. In. .450 .450 .450 .450 .450 .450 .481 .450 .450 .481 .529 G Max. In. .481 .589 .759 .859 .989 1.139 1.089 1.489 1.889 1.389 1.459 H Max. In. .780 .910 1.030 1.090 1.150 1.180 1.220 1.220 1.220 1.220 1.280 mm. 11.43 11.43 11.43 11.43 11.43 11.43 12.22 11.43 11.43 12.22 13.44 mm. 12.22 14.96 19.28 21.82 25.12 28.93 27.66 37.82 47.98 35.28 37.06 mm. 19.81 23.11 26.16 27.68 29.21 29.97 30.99 30.99 30.99 30.99 32.51 .312 7.92 .420 10.67 .591 15.01 .690 17.53 .820 20.83 .970 24.64 .920 23.37 1.030 26.16 1.720 43,69 1.220 30.99 1.290 32.77 © 2006 Glenair, Inc. CAGE Code 06324/0CA77 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com L-12 E-Mail: sales@glenair.com
