507-002

MIL-C-81659 Qwik-Ty® for MIL-C-81659 Connectors 507-002 507-002 L H Basic Part No. Angular Functions A = Angle Mount Right B = Back Mount C = Angle Mount Left D = 90° Back Mount L = Left Mount N = None (Base Only) R = Right Mount H = Hardware Supplied, Omit for None 1. Metric dimensions (mm) are indicated in parentheses. 2. Material - Al Alloy Finish - Black Anodize Hardware = Cres/Passivate 2.50 (63.5) .125 (3.2) Dia Holes 4 Places Typ. 1.62 (41.1) Max Typ. 1.69 (42.9) Max Sym. A Angle Mount Qwik-Ty Right .550 (14.0) Max Typ. Sym. B Back Mount Qwik-Ty 2.32 (58.9) .188 (4.8) ±.031 (.8) Sym A, C, D, L, & R 1.69 (42.9) Max Sym. C Angle Mount Qwik-Ty Sym. D 90° Back Mount Qwik-Ty .375 (9.5) Max Typ .406 (10.3) ±.031 (.8) Sym B & N 1.377 (35.0) .938 (23.8) Max Typ. Sym. N Base Only 1.438 (36.5) 1.734 (44.0) Max Sym. R Right Mount Qwik-Ty © 5/2001 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. Sym. L Left Mount Qwik-Ty 1.195 (30.4) Max Typ. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 B-6
