600-102-14

600-006, 600-079 & 600-102 Circular Backshell Assembly Wrenches and Repacement Insert Pads Product Series Basic Number 006 - Standard (Aluminum) 079 - Anti-Decoupling (Aluminum) 102 - Standard (Stainless Steel) 600 - 006 - 16 Dash Number or: KIT - Complete Kit 600-006 and 600-102 (Standard Coupling) A B Dash Shell Ref. Ref. No. Size Ref. 6.50 (165.1) .617 (15.7) 08 08/09 6.50 (165.1) .734 (18.6) 10 10/11 6.50 (165.1) .858 (21.8) 12 12/13 6.50 (165.1) .984 (25.0) 14 14/15 6.50 (165.1) 1.112 (28.2) 16 16/17 7.00 (177.8) 1.198 (30.4) 18 18/19 7.00 (177.8) 1.323 (33.6) 20 20/21 7.00 (177.8) 1.448 (36.8) 22 22/23 7.00 (177.8) 1.573 (40.0) 24 24/25 7.00 (177.8) 1.969 (50.0) 28 28 600-079 and 600-103 (Anti-Decoupling) A B Dash Shell Ref. Ref. No. Size Ref. 7.38 (187.5) .659 (16.7) 01 08/09 7.50 (190.5) .783 (19.9) 02 10/11 7.50 (190.5) .906 (23.0) 03 12/13 7.50 (190.5) 1.035 (26.3) 04 14/15 7.50 (190.5) 1.140 (29.0) 05 16/17 7.75 (196.9) 1.260 (32.0) 06 18/19 8.00 (203.2) 1.383 (35.1) 07 20/21 8.25 (209.6) 1.510 (38.4) 08 22/23 8.25 (209.6) 1.630 (41.4) 10 24/25 A 2.25 (57.2) Approx. B Adjustable Stop (600-079 Only) APPLICATION NOTES 1. Grips are covered in vinyl. 2. Metric dimensions (mm) are indicated in parentheses. Consult Factory for Larger Sizes Replacement Insert Pads Approx. Length 600-008 - 3.56 (90.4) 600-078 - 4.00 (101.6) .38 (9.7) Approx. Replacing Insert Pads in Backshell Assembly Tools 1. The urethane pad strips are mechanically retained without adhesive. To remove, grasp an edge of the strip and pull loose from tool. 2. Beginning with retaining hole adjacent to assembly tool hinge, insert first retaining knob on strip into hole. Continue inserting knobs on pad strip into remaining holes on tool. 3. Using side-cutters or scissors, trim end of pad strip flush with metal surface of assembly tool. Retain remainder of strip for replacement in other size assembly tools. Printed in U.S.A. .28 (7.1) Approx. 600-008 Fits standard coupling series sizes 08 through 24, color black. 600-078-01 Fits anti-decoupling coupling sizes 09 through 23, color red. 600-078-02 Fits anti-decoupling coupling size 25, color red. © 2008 Glenair, Inc. CAGE Code 06324 GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 13 E-Mail: sales@glenair.com Wrenches, Pliers & Kits
