620-003

620-003 Backshell Accessory - Straight Strain Relief Rotatable Coupling 620 A S 003 M 16 62 CONNECTOR DESIGNATOR Product Series Connector Designator Angle and Profile S = Straight Basic Part No. E (Table III) Shell Size Finish (Table II) A-F-L-H-S ROTATABLE COUPLING A Thread (Table I) Cable Entry C (Table I) F (Table III) TABLE III: CABLE ENTRY Shell Size Conn. Desig. A,F,L H 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 28 H Cable Entry E Max .625 (15.9) .656 (16.7) .718 (18.2) .968 (24.6) 1.105 (28.1) 1.105 (28.1) 1.105 (28.1) 1.105 (28.1) 1.105 (28.1) 1.105 (28.1) F Nom .750 (19.1) .750 (19.1) .937 (23.8) 1.015 (25.8) 1.125 (28.6) 1.188 (30.2) 1.312 (33.3) 1.437 (36.5) 1.562 (39.7) 1.812 (46.0) Closed .055 (1.4) .055 (1.4) .095 (2.4) .219 (5.6) .219 (5.6) .345 (8.8) .469 (11.9) .594 (15.1) .594 (15.1) .859 (21.8) Open .125 (3.2) .188 (4.8) .250 (6.4) .375 (9.5) .500 (12.7) .625 (15.9) .750 (19.1) .875 (22.2) 1.000 (25.4) 1.250 (31.8) 1. Cable Entry is defined as the accommodation entry for the wire bundle or cable. Dimensions are not intended for inspection criteria. 2. Metric dimensions (mm) are indicated in parentheses. © 20053 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com Series 62 - Page 2
