660-072MCS_10

MIL-PRF28876 Product Series Finish (Table II) Threaded Protective Covers Attachment Type (Table III) Ring or Eyelet Dash No. (Tables IV, V, VI, VII) 660-072 and 660-073 MIL-PRF-28876 Type 660 - 072 Basic Part Number -072 - Plug Cover -073 - Receptacle Cover M C S 5 - 04 Attachment Length (In Inches) Shell Size (Table VIII) 1.000 (25.4) Max .047 (1.2) Max .780 (19.8) Max .047 (1.2) Max Gasket C F Dia Length Attachment Type (Table III) Attachment Type (Table III) F Dia Length E Thread E Thread 660-072 Plug Cover MIL-PRF-28876/10 Style TABLE I: CONNECTOR SHELL SIZE Designator A B C D E F G H J Shell Size (Ref) 11 13 15 17 19 23 25 29 33 A Thread .750-.1P-.2L-DS .875-.1P-.2L-DS 1.062-.1P-.2L-DS 1.125-.1P-.2L-DS 1.312-.1P-.2L-DS 1.500-.1P-.2L-DS 1.625-.1P-.2L-DS 1.812-.1P-.2L-DS 2.000-.1P-.2L-DS B Dia Max 1.028 (26.1) 1.141 (29.0) 1.263 (32.1) 1.387 (35.2) 1.513 (38.4) 1.703 (43.5) 1.825 (46.4) 2.143 (54.4) 2.329 (59.2) 660-073 Receptacle Cover MIL-PRF-28876/15 Style TABLE II: FINISH SYM C M NF ZN Z1 MATERIAL Aluminum Aluminum Aluminum Aluminum Stainless Steel FINISH Black Anodize Electroless Nickel (Coupling Nut Electrodeposited) Olive Drab Cadmium over Electroless Nickel Zinc-Nickel/Olive Drab over Electroless Nickel Passivate © 2010 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 C-14 E-Mail: sales@glenair.com Threaded Protective Covers ROPE (Types F, G, H, R, T, U) EYELET TABLE III: ATTACHMENT TYPE Sym K Dia. (Table IV) D F G K Dia. (Table IV) H N R S T U Attachment Type Bead Chain, Cres., Passivate Wire Rope, Nylon Jacket Nylon Rope Wire Rope, Teflon Jacket No Attachment Wire Rope, PVC Jacket #8 Sash Chain, Cres., Passivate Wire Rope, No Jacket Wire Rope, Polyurethane Jacket with Terminal 660-072 and 660-073 MIL-PRF-28876 Typer TABLE IV: EYELET Dash No. 01 02 03 04 05 06 07 09 00 K Dia +.010 (3.6) .140 (3.6) .182 (4.6) .191 (4.9) .197 (5.0) .167 (4.2) .125 (3.2) .218 (5.5) .156 (4.0) No Eyelet SASH CHAIN (Type S) BEAD CHAIN (Type D) SPLIT RING - Style C L Dia K Dia. (Table IV) SOLID RING - Style B M Dia SOLID RING - Style A N Dia TABLE V: SPLIT RING Dash No. 50 52 54 56 58 60 62 64 66 68 70 72 L Dia +.015 (4.0) .425 (10.8) .485 (12.3) .640 (16.3) .750 (19.1) .890 (22.6) 1.015 (25.8) 1.095 (27.8) 1.130 (28.7) 1.250 (31.8) 1.350 (34.3) 1.390 (35.3) 1.485 (37.7) Dash No. 74 76 78 80 82 84 86 88 90 92 94 L Dia +.015 (4.0) 1.625 (41.3) 1.750 (44.5) 1.220 (31.0) 1.980 (50.3) 2.060 (52.3) 2.235 (56.8) 2.310 (58.7) 2.475 (62.9) 2.655 (67.4) 2.810 (71.4) 3.045 (77.3) TABLE VI: SOLID RING STYLE B Dash No. 08 10 12 13 14 15 16 17 18 19 20 21 22 23 M Dia +.015 (4.0) .468 (11.9) .593 (15.1) .718 (18.2) .765 (19.4) .844 (21.4) .890 (22.6) .968 (24.6) 1.015 (25.8) 1.093 (27.8) 1.140 (29.0) 1.203 (30.6) 1.265 (32.1) 1.343 (34.1) 1.453 (36.9) Dash No. 24 25 27 28 29 30 31 32 33 35 36 40 44 48 M Dia +.015 (4.0) 1.484 (37.7) 1.577 (40.1) 1.640 (41.7) 1.687 (42.8) 1.765 (44.8) 1.890 (48.0) 1.953 (49.6) 1.968 (50.0) 2.077 (52.8) 2.140 (54.4) 2.187 (55.5) 2.406 (61.1) 2.656 967.5) 3.031 (77.0) TABLE VII: SOLID RING STYLE A Dash No. 095 100 101 102 103 104 105 205 106 206 107 207 108 308 208 N Dia +.015 (4.0) .312 (7.9) .391 (9.9) .516 (13.1) .583 (14.8) .641 (16.3) .708 (18.0) .766 (19.5) .788 (20.0) .896 (22.8) .907 (23.0) 1.016 (25.8) 1.025 (26.0) 1.141 (29.0) 1.188 (30.2) 1.203 (30.6) Dash No. 109 209 110 210 111 211 112 113 213 114 214 115 116 117 N Dia +.015 (4.0) 1.266 (32.2) 1.312 (33.3) 1.391 (35.3_ 1.391 (35.3) 1.521 (38.6) 1.536 (39.0) 1.641 (41.7) 1.766 (44.9) 1.812 (46.0) 1.891 (48.0) 1.938 (49.2) 2.078 (52.8) 2.406 (61.1) 2.510 (63.8) Metric dimensions (mm) are indicated in parenthesis. © 2010 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 C-15 E-Mail: sales@glenair.com MIL-PRF28876 C
