710-107B

710-106/107/370 and 710-108/109/371 Metal "Y" and "T" Transitions for Series 72 & 74 Tubing and Series 75 Conduit "Y" Transitions 710-106/107/370 E "B" END "T" Transitions 710-108/109/371 "B" END G "A" END D "C" END "A" END F "C" END H THREAD 710 - 106 M A24 B08 C16 Product Series Y Transition Material 106 = Aluminum 107 = Brass 370 = Stainless Steel T Transition Material 108 = Aluminum 109 = Brass 371 = Stainless Steel "C" End Conduit Dash No. "B" End Conduit Dash No. "A" End Conduit Dash No. Finish (Table I) H THREAD TABLE I SYMBOL FINISH B J M N NC NF T Olive Drab over Cadmium Plate Gold Iridite over Cadmium Plate over Nickel Electroless Nickel Olive Drab over Cadmium Plate over Nickel Zinc-Cobalt, Olive Drab Olive Drab over Cadmium Plate over Electroless Nickel (500 Hour Salt Spray) Bright Dip Cadmium Plate over Nickel Z1 Passivate Metric dimensions (mm) are in parentheses. TABLE II CONDUIT DASH AVAILABILITY H THREAD D E NO. 72 74 75 CLASS 2A MAX MAX 06 06 7/16 - 28 UNEF 1.97 (50.0) 1.20 (30.5) 08 08 1/2 - 20 UNF 1.97 (50.0) 1.20 (30.5) 09 09 09 9/16 - 24 UNEF 2.13 (54.1) 1.30 (33.0) 10 10 9/16 - 24 UNEF 2.13 (54.1) 1.30 (33.0) 12 12 12 12 5/8 - 24 UNEF 2.22 (56.4) 1.34 (34.0) 14 14 11/16 - 24 UNEF 2.37 (60.2) 1.49 (37.8) 16 16 16 16 3/4 - 20 UNEF 2.37 (60.2) 1.49 (37.8) 20 20 20 20 7/8 - 20 UNEF 2.69 (68.3) 1.70 (43.2) 24 24 24 24 1 - 20 UNEF 2.75 (69.9) 1.84 (46.7) 28 28 28 1 3/16 - 18 UNEF 3.06 (77.7) 2.09 (53.1) 32 32 32 32 1 5/16 - 18 UNEF 3.28 (83.3) 2.23 (56.6) 40 40 40 40 1 1/2 - 18 UNEF 3.59 (91.2) 2.50 (63.5) 48 48 48 1 3/4 - 18 UNS 4.23 (107.4) 2.96 (75.2) 56 56 56 2 - 18 UNS 5.00 (127.0) 3.50 (88.9) 64 64 64 2 1/4 - 16 UN 5.00 (127.0) 3.50 (88.9) 80 80 2 3/4 - 16 UN 5.70 (144.8) 4.10 (104.1) * * Consult factory for adapters using 3.000 inch (76.2) conduit © 2003 Glenair, Inc. CAGE Codes 06324 F MAX 1.33 (33.8) 1.35 (34.3) 1.43 (36.3) 1.43 (36.3) 1.47 (37.3) 1.58 (40.1) 1.65 (41.9) 1.78 (45.2) 1.85 (47.0) 2.09 (53.1) 2.43 (61.7) 2.65 (67.3) 3.15 (80.0) 3.40 (86.4) 3.75 (95.3) 4.25 (108.0) G MAX .81 (20.6) .84 (21.3) .88 (22.4) .88 (22.4) .91 (23.1) .94 (23.9) .94 (23.9) 1.03 (26.2) 1.13 (28.7) 1.16 (29.5) 1.16 (29.5) 1.28 (32.5) 1.53 (38.9) 1.69 (42.9) 1.87 (47.5) 2.13 (54.1) Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com G-9 Adapters and Transitions
