Adapters and Transitions
710-318 Composite Split "T" Junction Fitting for Series 72 and 74 Convoluted Tubing
710-318 XM 03*04*05
Basic Part No. Finish (Table II) End A Dash No. (Table I) End C Dash No. (Table I) End B Dash No. (Table I) Note: When all ends are identical, insert only one dash no. When multiple dash numbers are ordered, transition size will be determined by the largest. Adapter may be supplied on smaller entries. Letter to folow entry will be supplied with adapters. Adapter
End A .50 (12.7) Max
Shape optional RFI/EMI Tongue & Groove Joint
45° Typ. End B B Dia Typ
C
End C
A Thread - Typ. D
Table I
Dash No. 01 02 03 04 05 06 07 A Thread Unified .750 - 20 1.000 - 20 1.312 - 18 1.500 - 18 2.000 - 18 .500 - 20 .625 - 24 B Dia .500 (12.7) .750 (19.1) 1.000 (25.4) 1.250 (31.8) 1.625 (41.3) .281 (7.1) .375 (9.5) C Max 2.375 (60.3) 2.625 (66.7) 2.875 (73.0) 3.125 (79.4) 3.500 (88.9) 2.125 (54.0) 2.250 (57.2) D Max 1.187 (30.1) 1.312 (33.3) 1.437 (36.5) 1.652 (42.0) 1.750 (44.5) 1.062 (27.0) 1.125 (28.6) Weight in Pounds Max. .082 .114 .160 .191 .273 .031 .043 XM XW
Table II TABLE 2
Electroless Nickel Cadmium Olive Drab Over Electroless Nickel No Plating Black Material No Plating - Base Material Non-conductive
Printed in U.S.A.
XB XO
1. Metric dimensions (mm) are in parentheses and are for reference only. 2. Consult factory for availability.
© 2003 Glenair, Inc.
CAGE Codes 06324
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com G-22
