713-100

Adapters and Transitions 713-100 Metal Straight, 45°, and 90° Connector Adapters for Series 72 & 74 Tubing and Series 75 Conduit 713 A S 100 M 16 1 32-4 Product Series Connector Designator (Pages F-4 to F-6) Angular Function S = Straight K = 45° L = 90° Adapter Material 100 = Aluminum 101 = Brass 110 = Stainless Steel Length - S Only [In 1/2 inch (12.7 mm) increments, e.g. 4 = 2 inches] See Page F-15 Conduit Dash Number (Table II) 1 = Style 1 Shell Size (Table I) Finish (Table III) O-RING A THREAD (Page F-17) LENGTH (Page F-15) C OR D DIA (Page F-17) J DIA TYP H THREAD F 45° D G E Metric dimensions (mm) are in parentheses. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com G-16 713-100 Metal Straight, 45°, and 90° Connector Adapters for Series 72 & 74 Tubing and Series 75 Conduit TABLE I SHELL SIZE * H 08 10 12 14 16 18 20 22 24 28 32 36 09 11 13 15 17 19 21 23 25 MAX CONDUIT DASH NO. REF ** 08 12 16 20 24 24 32 32 40 40 48 64 * ** D MAX .531 (13.5) .625 (15.9) .688 (17.5) .719 (18.3) .906 (23.0) .968 (24.6) 1.031 (26.2) 1.156 (29.4) 1.219 (31.0) 1.281 (32.5) 1.593 (40.5) 1.718 (43.6) E MAX .781 (19.8) .906 (23.0) .906 (23.0) 1.000 (25.4) 1.062 (27.0) 1.062 (27.0) 1.093 (27.8) 1.156 (29.4) 1.281 (32.5) 1.531 (38.9) 1.719 (43.7) 1.906 (48.4) F MAX G MAX .437 (11.1) .625 (15.9) .500 (12.7) .656 (16.7) .500 (12.7) .719 (18.3) .562 (14.3) .781 (19.8) .656 (16.7) .844 (21.4) .656 (16.7) .844 (21.4) .719 (18.3) .844 (21.4) .812 (20.6) .906 (23.0) .812 (20.6) .906 (23.0) 1.093 (27.8) .906 (23.0) 1.093 (27.8) 1.219 (31.0) 1.156 (29.4) 1.281 (32.5) Connector Designators A-D-E-F-J-K-L-S. Dimensions D-E-F-G apply to connector Shell Size and Conduit Dash No. combinations listed. When larger Conduit Dash Numbers are selected, consult factory for dimensions. CONDUIT DASH NO. 06 08 09 10 12 14 16 20 24 28 32 40 48 56 64 80 *** TABLE II AVAILABILITY H THREAD 72 74 75 CLASS 2A 06 7/16 - 28 UNEF 08 1/2 - 20 UNF 09 09 9/16 - 24 UNEF 10 9/16 - 24 UNEF 12 12 12 5/8 - 24 UNEF 14 11/16 - 24 UNEF 16 16 16 3/4 - 20 UNEF 20 20 20 7/8 - 20 UNEF 24 24 24 1 - 20 UNEF 28 28 1 3/16 - 18 UNEF 32 32 32 1 5/16 - 18 UNEF 40 40 40 1 1/2 - 18 UNEF 48 48 1 3/4 - 18 UNS 56 56 2 - 18 UNS 64 64 2 1/4 - 16 UN 80 2 3/4 - 16 UN TABLE III J DIA + .015 (.4) .193 (4.9) .255 (6.5) .286 (7.3) .317 (8.1) .380 (9.7) .442 (11.2) .505 (12.8) .630 (16.0) .755 (19.2) .880 (22.4) 1.005 (25.5) 1.255 (31.9) 1.505 (38.2) 1.755 (44.6) 2.005 (50.9) 2.505 (63.6) SYMBOL B J FINISH Olive Drab over Cadmium Plate Gold Iridite over Cadmium Plate over Nickel Electroless Nickel Olive Drab over Cadmium Plate over Nickel Zinc Cobalt, Olive Drab Olive Drab over Cadmium Plate over Electroless Nickel (500 Hour Salt Spray) Bright Dip Cadmium Plate over Nickel Passivate M N NC NF T Z1 *** Consult factory for adapters using 3.000 inch (76.2) conduit © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com G-17 Adapters and Transitions
