750-033-16

Series 75 Metal-Core Conduit 750-033 Type D Series 75 Flexible Metal-Core Conduit TYPE D BRASS CONDUIT INNER BRONZE BRAID BRAIDED CENTER TIN/COPPER EMI SHIELD BRAIDED OUTER TIN/COPPER EMI SHIELD NEOPRENE JACKET * 750-033-16 Product Series Basic Part No. Dash No. (Table I) NEOPRENE JACKET * OUTER TIN/COPPER SHIELD CENTER TIN/COPPER SHIELD INNER BRONZE BRAID BRASS CONDUIT A DIA (Table I) B DIA (Table I) LENGTH (AS SPECIFIED IN FEET) TABLE I B DIA MAX .688 (17.5) .812 (20.6) .937 (23.8) 1.062 (27.0) 1.203 (30.6) 1.562 (39.7) 1.812 (46.0) 2.062 (52.4) 2.312 (58.7) 2.593 (65.9) 3.093 (78.6) 3.630 (92.2) MINIMUM BEND RADIUS Metric dimensions (mm) are in parentheses. * For other jacket materials or for conduit without the jacket, consult the factory. DASH NO. 08 12 16 20 24 32 40 48 56 64 80 96 A DIA .250 (6.4) .375 (9.5) .500 (12.7) .625 (15.9) .750 (19.1) 1.000 (25.4) 1.250 (31.8) 1.500 (38.1) 1.750 (44.5) 2.000 (50.8) 2.500 (63.5) 3.000 (76.2) MINIMUM BEND RADIUS** 1.750 (44.5) 2.000 (50.8) 2.500 (63.5) 3.000 (76.2) 3.750 (95.3) 5.000 (127.0) 6.250 (158.8) 7.750 (196.9) 8.500 (215.9) 10.000 (254.6) 12.500 (317.5) 15.000 (381.0) ** The minimum bend radius shown for each size is based on Type A construction (see page C-5). For multiple-braided coverings, these minimum bend radii may be increased slightly. CAGE Codes 06324 Printed in U.S.A. © 2003 Glenair, Inc. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-8
