750-035-16

750-035 Type C Series 75 Flexible Metal-Core Conduit 750-035-16 Product Series Basic Part No. Dash No. (Table I) TYPE C BRASS CONDUIT INNER BRONZE BRAID BRAIDED CENTER FERROUS EMI SHIELD BRAIDED OUTER TIN/COPPER EMI SHIELD NEOPRENE JACKET * NEOPRENE JACKET * OUTER TIN/COPPER SHIELD CENTER FERROUS SHIELD INNER BRONZE BRAID BRASS CONDUIT A DIA (Table I) B DIA (Table I) LENGTH (AS SPECIFIED IN FEET) MINIMUM BEND RADIUS Metric dimensions (mm) are in parentheses. * For other jacket materials or for conduit without the jacket, consult the factory. © 2003 Glenair, Inc. DASH NO. 08 12 16 20 24 32 40 48 56 64 80 96 A DIA .250 (6.4) .375 (9.5) .500 (12.7) .625 (15.9) .750 (19.1) 1.000 (25.4) 1.250 (31.8) 1.500 (38.1) 1.750 (44.5) 2.000 (50.8) 2.500 (63.5) 3.000 (76.2) TABLE I B DIA MINIMUM MAX BEND RADIUS** .688 (17.5) 1.750 (44.5) .812 (20.6) 2.000 (50.8) .937 (23.8) 2.500 (63.5) 1.062 (27.0) 3.000 (76.2) 1.203 (30.6) 3.750 (95.3) 1.562 (39.7) 5.000 (127.0) 1.812 (46.0) 6.250 (158.8) 2.062 (52.4) 7.750 (196.9) 2.312 (58.7) 8.500 (215.9) 2.593 (65.9) 10.000 (254.6) 3.093 (78.6) 12.500 (317.5) 3.630 (92.2) 15.000 (381.0) ** The minimum bend radius shown for each size is based on Type A construction (see page C-5). For multiple-braided coverings, these minimum bend radii may be increased slightly. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com C-7 Series 75 Metal-Core Conduit
