750-100

7 Pre-Terminated Assemblies 750-100, 750-101 and 750-116 Adapter to Adapter Pre-Terminated Assemblies Series 72 & 74 Tubing & Series 75 Conduit FOR ADAPTER-TO-ADAPTER APPLICATIONS FOR USE WITH "Y" AND "T" TRANSITION ADAPTERS SUCH AS 710-077 THROUGH 710-120 713-100 THROUGH 713-103 750 N A 100 M 24-36 Product Series 720 = Series 72 740 = Series 74 ** 750 = Series 75 Jacket E = EPDM H = With Hypalon Jacket N = With Neoprene Jacket V = With Viton Jacket X = No Jacket Conduit Type Length in inches * Conduit Dash No. (Table I) Finish (Table II) End Fitting Material 100 = Aluminum 101 = Brass 116 = Stainless Steel O-RING A THREAD 1.69 MAX (42.9) LENGTH * B DIA C DIA Metric dimensions (mm) are in parentheses. * Length tolerance is ± .250 (12.7) for lengths up to 24 inches (619.6 mm). Length tolerance for longer lengths is ± one percent (1%) of the length. ** Pre-terminated assemblies using product Series 740 will be supplied with FEP material, standard wall thickness, standard convolutions, tin copper braid, and neoprene jacket. For other options consult factory. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com E-Mail: sales@glenair.com B-2 750-100, 750-101 and 750-11 Pre-Terminated Assemblies 750-100, 750-101 and 750-11 Adapter to Adapter Pre-Terminated Assemblies Series 72 & 74 Tubing & Series 75 Conduit TABLE I: CONDUIT DASH NUMBER COND. AVAILABILITY DASH 72 74 75 A THREAD B NO. CLASS 2B MAX 06 06 7/16 - 28 UNEF .640 (16.3) 08 08 1/2 - 20 UNF .640 (16.3) 09 09 09 9/16 - 24 UNEF .690 (17.5) 10 10 9/16 - 24 UNEF .690 (17.5) 12 12 12 12 5/8 - 24 UNEF .760 (19.3) 14 14 11/16 - 24 UNEF .890 (22.6) 16 16 16 16 3/4 - 20 UNEF .890 (22.6) 20 20 20 20 7/8 - 20 UNEF 1.024 (26.0) 24 24 24 24 1- 20 UNEF 1.152 (29.3) 28 28 28 1 3/16 - 18 UNEF 1.363 (34.6) 32 32 32 32 1 5/16 - 18 UNEF 1.488 (37.8) 40 40 40 40 1 1/2 - 18 UNEF 1.676 (42.6) 48 48 48 1 3/4 - 18 UNS 1.960 (49.8) 56 56 56 2 - 18 UNS 2.210 (56.1) 64 64 64 2 1/4 - 16 UN 2.460 (62.5) 80 80 2 3/4 - 16 UN 2.930 (74.4) 96 96 3 1/4 - 16 UN 3.460 (87.9) C MAX .188 (4.8) .250 (6.4) .281 (7.1) .312 (7.9) .375 (9.5) .438 (11.1) .500 (12.7) .625 (15.9) .750 (19.1) .875 (22.2) 1.000 (25.4) 1.250 (31.8) 1.500 (38.1) 1.750 (44.5) 2.000 (50.8) 2.500 (63.5) 3.000 (76.2) TABLE II: FINISH OPTIONS SYMBOL FINISH B J M N NC NF T Z1 Olive Drab over Cadmium Plate Gold Iridite over Cadmium Plate over Nickel Electroless Nickel Olive Drab over Cadmium Plate over Nickel Zinc-Cobalt, Olive Drab Olive Drab over Cadmium Plate over Electroless Nickel (500 Hour Salt Spray) Bright Dip Cadmium Plate over Nickel Passivate Metric dimensions (mm) are in parentheses. © 2003 Glenair, Inc. CAGE Codes 06324 Printed in U.S.A. www.glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com B-3
