759-862AA16_10

Factory Terminated Conduit Assembly 759-862 Connector to Adapter MIL-PRF 24758A A Basic Number Adapter “A” Connector Designator A,C,D,F,G,H & W (Tables I & III) Adapter “T” Transition Adapter T = Transition (See Table II, Note 4) Conduit Dash Number (Table II) 759-862 A 16 Adapter “A” Shell Size (Table II) T 16 - 20 - 50.5 Adapter “B” Shell Size (Table II) Length In Inches (See Note 3) Length (See Note 3) A Thread 1.500 (38.1) Max I.D Table II D END A END B B Ref (M24758-(PRF Size) with Glenair “BlueJacket” C thread (See Note 4) APPLICATION NOTES 1. 2. 3. 4. Assembly identified with manufacurer’s code identification. Glenair 600 series backshell assembly tools are recommended for assembly installation. Length tolerance is 0-24” = +1/4”, for longer lengths is +1% of length. End “B” adapter (C thread) mates with corresponding MILPRF-24758-* adapter (see Table II). 7. 5. 6. Glenair series 600 backshell assembly tools are recommended for assembly and installation. Material / Finish: Adapter, ferrule & coupling nut - AISI 316L stainless steel / electroless nickel, matte finish. Metric dimensions (mm) are indicated in parentheses. © 2010 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com A-82 Factory Terminated Conduit Assembly TABLE I: CONNECTOR CODE CONN. CODE A C D F G H W SPECIFICATION MIL-DTL-5015 (MS34**) MIL-DTL-26482 Series II MIL-DTL-83723 Series I, III MIL-C-22992 Series R MIL-C-26482 Series I MIL-DTL-38999, Series I MIL-C-28840 MIL-DTL-38999 Series III, IV Glenair Series 22 (Geo-Marine®) CONDUIT DASH NO 08 12 16 20 24 32 40 48 64 80 96 TABLE II: CONDUIT DASH NO. MIL PRF SIZE A J B K C D E F G H L B MIN .245 (6.22) .370 (9.40) .495 (12.57) .620 (15.75) .745 (18.92) .995 (25.27) 1.245 (31.62) 1.495 (37.97) 1.995 (50.67) 2.495 (63.37) 2.995 (76.07) C THREAD CLASS 2B .438-28 UNEF .563-24 UNEF .688-24 UNEF .813-20 UNEF .938-20 UNEF 1.250-18 UNEF 1.563-18 UNEF 1.875-16 UN 2.375-16 UN 2.875-16 UN 3.375-16 UN D MAX .880 (22.4) .940 (23.9) 1.130 (28.7) 1.190 (30.2) 1.380 (35.1) 1.690 (42.9) 2.000 (50.8) 2.310 (58.7) 2.940 (74.7) 3.440 (87.4) 3.940 (100.1) TABLE III: REFERENCE ONLY MIL PRF DASH NO. 9 11 12 13 14 15 16 17 18 19 20 22 23 24 END “B” MATING ADAPTERS MIL-PRF-24758 MS3100 Series MIL-DTL-5015 Coaxial Connectors MIL-DTL-26482 Series I (Code D Table I) MS3155 Series (Code A Table I) MIL-DTL-28840 (Code G Table I) MIL-S-24235 Stuffing Tubes Miscellaneous Fittings Tapered Pipe Thread Straight Pipe Thread Bulkhead Termination MIL-DTL-38999 (Codes F & H Table I) Glenair Series 22 Geo-Marine® (Code W Table I) Union Fitting Shielded Cable Fitting © 2010 Glenair, Inc. www.glenair.com CAGE Codes 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com A-83 MIL-PRF 24758A 759-862 Connector to Adapter A
