800-006-06C5-3S

A B C D E F Hex Plug with Banding Platform G H J K L Knurled Round Plug with Accessory Thread Knurled Round Plug with Band Platform Hex Plug with Accessory Thread Series 800 Series 800 “Mighty Mouse” with UN Mating Thread Plug Connector Ordering Information 800-006 Thru 800-009 Compact Size saves space and weight. Smaller than other Series 80 plugs, these Series 800 plugs are suitable for hostile environments and are watertight when mated. Two Shell Styles: Integral platform for direct shield attachment using BANDIT® termination system, or accessory thread for attaching a strain relief. Crimp, Rear Release contact system, now with #12 and #16 M39029 coaxial or power contacts. Two Coupling Nut Styles: Hex nut or round knurled nut. Either style is available with optional wave spring which helps to prevent the nut from backing off. Si Series 800 Plug C Pl Connector t HOW TO ORDER Sample Part Number 800-006 Series -06 Shell Style -06 M Shell Material / Finish C 7-10 Shell Size- Insert Arrangement No. of Contacts Arr. P Contact Type Connector supplied with contacts Pin Socket Connector supplied without contacts Pin Socket Connector Connectors with contacts are supplied with signal and/or power crimp contacts. These contacts are not installed. Coaxial contacts and nonstandard signal contacts are ordered separately. Z Shell Key Position N Normal Standard Coupling Nut 800-006 Coupling Nut with AntiDecoupling Wave Spring -16 Aluminum / Black Anodize (Non-Conductive) RoHS Compliant Aluminum / Electroless Nickel RoHS Compliant Aluminum / Cadmium with Olive Drab Chromate Aluminum / Zinc-Nickel with Olive Drab Chromate Aluminum / Zinc-Cobalt with Black Chromate RoHS Compliant M NF 800-007 ZN UCR 800-008 Aluminum / Zinc-Nickel with Black Chromate Aluminum / Nickel-PTFE RoHS Compliant ZNU MT 800-009 Stainless Steel / Passivated RoHS Compliant Z1 5-3 6-1 6-4 6-7 7-1 7-10 8-2 8-13 8-200 9-4 9-19 9-200 9-201 10-5 10-26 10-200 10-201 10-202 12-2 12-3 12-7 12-37 12-200 12-201 #23 #20 #16 #12 3 1 4 7 1 10 2 13 4 2 4 19 4 2 8 2 5 26 12 1 4 2 8 2 2 3 7 37 6 2 10 2 P S X Pos. X Y Pos. Y A B Z Pos. Z © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-4 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 “Mighty Mouse” with UN Mating Thread Plug Connector Dimensions 800-006 Thru 800-009 .850 (21.6) MAX SAFETY WIRE HOLE 3X .031/.027 (0.79/0.69) ØB ØC ØD E THREADS F THREADS A HEX Hex Coupling Nut 800-006 800-007 Round Knurled Coupling Nut 800-008 800-009 Integral Band Platform 800-006 800-008 Accessory Threads 800-007 800-009 DIMENSIONS Shell Size 5 6 7 8 9 10 12 A Hex Style 06 In. mm. .430 .500 .625 .680 .750 .812 .875 10.92 12.70 15.88 17.27 19.05 20.62 22.23 A Hex Style 16 In . mm. .495 .563 .720 .743 .813 .875 .938 12.57 14.30 18.29 18.87 20.65 22.23 23.83 ØB Style 06 In. mm. .470 .550 .680 .750 .830 .900 .970 11.94 13.97 17.27 19.05 21.08 22.86 24.64 ØB Style 16 In. mm. .540 .620 .800 .830 .890 .960 1.030 13.72 15.75 20.32 21.08 22.61 24.38 26.16 ØC Style 06 In. mm. .430 .500 .620 .680 .750 .810 .880 10.92 12.70 15.75 17.27 19.05 20.57 22.35 ØC Style 16 In. mm. .490 .560 .680 .750 .810 .880 .940 12.45 14.22 17.27 19.05 20.57 23.35 23.88 ØD In. mm. .230 .286 .390 .445 .500 .565 .650 5.84 7.26 9.91 11.30 12.70 14.35 16.51 E Threads Coupling Nut .3125-28 UN-2B .3750-28 UN-2B .4375-28 UNEF-2B .5000-32 UN-2B .5625-32 UN-2B .6250-32 UN-2B .7500-28 UN-2B F Threads Accessory .250-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A SERIES 800 KEY POSITIONS Key Position Normal (N) X Y Z Key Rotation 150° 140° 130° 120° NORMAL Z° Y° X° Z° Y° X° NORMAL 60° 60° Shell size 5 and 6: master key is located at top dead center for normal (N) position. Shell size 7 thru 12: master key is rotated 90° from TDC for normal position. Plug Key Position Receptacle Key Position © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-5 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 A B C D E F G H J K L M
