800-009-06C6-4P

厂商：
GLENAIR(格伦尔)
封装：
描述：
800-009-06C6-4P - Plug Connector Ordering Information - Glenair, Inc.

数据手册：

下载800-009-06C6-4P.pdf

立即购买

详情介绍
数据手册
价格&库存

800-009-06C6-4P 数据手册

A B C D E F Hex Plug with Banding Platform G H J K L Knurled Round Plug with Accessory Thread Knurled Round Plug with Band Platform Hex Plug with Accessory Thread Series 800 Series 800 “Mighty Mouse” with UN Mating Thread Plug Connector Ordering Information 800-006 Thru 800-009 Compact Size saves space and weight. Smaller than other Series 80 plugs, these Series 800 plugs are suitable for hostile environments and are watertight when mated. Two Shell Styles: Integral platform for direct shield attachment using BANDIT® termination system, or accessory thread for attaching a strain relief. Crimp, Rear Release contact system, now with #12 and #16 M39029 coaxial or power contacts. Two Coupling Nut Styles: Hex nut or round knurled nut. Either style is available with optional wave spring which helps to prevent the nut from backing off. Si Series 800 Plug C Pl Connector t HOW TO ORDER Sample Part Number 800-006 Series -06 Shell Style -06 M Shell Material / Finish C 7-10 Shell Size- Insert Arrangement No. of Contacts Arr. P Contact Type Connector supplied with contacts Pin Socket Connector supplied without contacts Pin Socket Connector Connectors with contacts are supplied with signal and/or power crimp contacts. These contacts are not installed. Coaxial contacts and nonstandard signal contacts are ordered separately. Z Shell Key Position N Normal Standard Coupling Nut 800-006 Coupling Nut with AntiDecoupling Wave Spring -16 Aluminum / Black Anodize (Non-Conductive) RoHS Compliant Aluminum / Electroless Nickel RoHS Compliant Aluminum / Cadmium with Olive Drab Chromate Aluminum / Zinc-Nickel with Olive Drab Chromate Aluminum / Zinc-Cobalt with Black Chromate RoHS Compliant M NF 800-007 ZN UCR 800-008 Aluminum / Zinc-Nickel with Black Chromate Aluminum / Nickel-PTFE RoHS Compliant ZNU MT 800-009 Stainless Steel / Passivated RoHS Compliant Z1 5-3 6-1 6-4 6-7 7-1 7-10 8-2 8-13 8-200 9-4 9-19 9-200 9-201 10-5 10-26 10-200 10-201 10-202 12-2 12-3 12-7 12-37 12-200 12-201 #23 #20 #16 #12 3 1 4 7 1 10 2 13 4 2 4 19 4 2 8 2 5 26 12 1 4 2 8 2 2 3 7 37 6 2 10 2 P S X Pos. X Y Pos. Y A B Z Pos. Z © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-4 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 “Mighty Mouse” with UN Mating Thread Plug Connector Dimensions 800-006 Thru 800-009 .850 (21.6) MAX SAFETY WIRE HOLE 3X .031/.027 (0.79/0.69) ØB ØC ØD E THREADS F THREADS A HEX Hex Coupling Nut 800-006 800-007 Round Knurled Coupling Nut 800-008 800-009 Integral Band Platform 800-006 800-008 Accessory Threads 800-007 800-009 DIMENSIONS Shell Size 5 6 7 8 9 10 12 A Hex Style 06 In. mm. .430 .500 .625 .680 .750 .812 .875 10.92 12.70 15.88 17.27 19.05 20.62 22.23 A Hex Style 16 In . mm. .495 .563 .720 .743 .813 .875 .938 12.57 14.30 18.29 18.87 20.65 22.23 23.83 ØB Style 06 In. mm. .470 .550 .680 .750 .830 .900 .970 11.94 13.97 17.27 19.05 21.08 22.86 24.64 ØB Style 16 In. mm. .540 .620 .800 .830 .890 .960 1.030 13.72 15.75 20.32 21.08 22.61 24.38 26.16 ØC Style 06 In. mm. .430 .500 .620 .680 .750 .810 .880 10.92 12.70 15.75 17.27 19.05 20.57 22.35 ØC Style 16 In. mm. .490 .560 .680 .750 .810 .880 .940 12.45 14.22 17.27 19.05 20.57 23.35 23.88 ØD In. mm. .230 .286 .390 .445 .500 .565 .650 5.84 7.26 9.91 11.30 12.70 14.35 16.51 E Threads Coupling Nut .3125-28 UN-2B .3750-28 UN-2B .4375-28 UNEF-2B .5000-32 UN-2B .5625-32 UN-2B .6250-32 UN-2B .7500-28 UN-2B F Threads Accessory .250-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A SERIES 800 KEY POSITIONS Key Position Normal (N) X Y Z Key Rotation 150° 140° 130° 120° NORMAL Z° Y° X° Z° Y° X° NORMAL 60° 60° Shell size 5 and 6: master key is located at top dead center for normal (N) position. Shell size 7 thru 12: master key is rotated 90° from TDC for normal position. Plug Key Position Receptacle Key Position © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-5 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 A B C D E F G H J K L M

下载 PDF

800-009-06C6-4P

### 物料型号 - 800-006：六角插头，带有绑线平台 - 800-007：六角插头，带有波形弹簧 - 800-008：圆形滚花插头，带有辅助螺纹 - 800-009：圆形滚花插头，带有辅助螺纹

### 器件简介 Series 800 “Mighty Mouse”系列插头连接器，具有紧凑的尺寸，重量轻，适合恶劣环境使用，并且在连接时具有防水性能。该系列插头连接器采用压接、后释放式接触系统，支持#12和#16 M39029同轴或电源接触。

### 引脚分配 - 800-006：包含23、20、16、12号接触 - 800-007：包含10个接触 - 800-008：包含19个接触 - 800-009：包含37个接触

### 参数特性 - 两种耦合螺母风格：六角螺母或圆形滚花螺母，均带有可选的波形弹簧，防止螺母松动。 - 两种壳体风格：集成平台用于直接屏蔽连接，或辅助螺纹用于连接防振装置。 - 耦合螺母材料包括铝、电镀锌镍、锌镍合金等，均符合RoHS标准。

### 功能详解 - 该系列连接器具有不同的壳体尺寸和接触排列，以满足不同的应用需求。 - 提供了不同的接触类型，包括针和插座，以及信号和/或电源压接接触。 - 连接器未安装压接接触，同轴接触和非标准信号接触需单独订购。

### 应用信息 适用于需要小型化、轻量化和防水连接的应用场合，特别是在恶劣环境下。

### 封装信息 - 封装材料包括铝、锌镍合金、不锈钢等，表面处理包括黑色阳极氧化、电镀锌镍、黑色铬酸盐等。 - 封装尺寸从5到12不等，具体尺寸和螺纹规格在文档中有详细描述。

800-009-06C6-4P 价格&库存

-> 查询更多价格&库存

很抱歉，暂时无法提供与“800-009-06C6-4P”相匹配的价格&库存，您可以联系我们找货
