A B C D E F In-Line G H J K L Series 800 Series 800 “Mighty Mouse” with UN Mating Thread Crimp Receptacle Ordering Information 800-010 and 800-011 In-Line Rear Panel Jam Nut Mount Square Flange Mount Integral Band Platform for direct attachment of a cable Three Shell Options: Jam nut with o-ring for rear panel shield using a BAND-IT® strap. Install a boot, or overmold mounting, square flange or in-line receptacle for free-hanging onto the band platform. An accessory thread is available cables. for attaching strain reliefs and backshells. HOW TO ORDER Sample Part Number 8 0 0 - 0 11 Series -0 1 Shell Style M Shell Material / Finish C 6-4 Shell Size- Insert Arrangement No. of Contacts Arr. P Contact Type Connector supplied with contacts Pin Socket Connector supplied without contacts Pin Socket Connector Connectors with contacts are supplied with signal and/or power crimp contacts. These contacts are not installed. Coaxial contacts and nonstandard signal contacts are ordered separately. N Shell Key Position N Normal -01 Aluminum / Black Anodize (Non-Conductive) RoHS Compliant Aluminum / Electroless Nickel RoHS Compliant Receptacle with Banding Platform 800-010 M -02 Receptacle with Accessory Thread 800-011 Square Flange for Front or Rear ZN Mounting Aluminum / Zinc-Nickel with Olive Drab Chromate Aluminum / Zinc-Cobalt with Black Chromate RoHS Compliant Aluminum / Cadmium with Olive Drab Chromate NF UCR -07 Jam Nut for Rear ZNU Panel Mounting Aluminum / Zinc-Nickel with Black Chromate Aluminum / Nickel-PTFE RoHS Compliant Stainless Steel / Passivated RoHS Compliant MT Z1 5-3 6-1 6-4 6-7 7-1 7-10 8-2 8-13 8-200 9-4 9-19 9-200 9-201 10-5 10-26 10-200 10-201 10-202 12-2 12-3 12-7 12-37 12-200 12-201 #23 #20 #16 #12 3 1 4 7 1 10 2 13 4 2 4 19 4 2 8 2 5 26 12 1 4 2 8 2 2 3 7 37 6 2 10 2 P S X Pos. X Y Pos. Y A B Z Pos. Z © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-6 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 “Mighty Mouse” with UN Mating Thread Jam Nut Crimp Receptacle Dimensions 800-010-07 and 800-011-07 Integral Band Platform 800-010-07 .460 (11.7) ØA E MAX Accessory Thread 800-011-07 .460 (11.7) H MAX C FLAT ØF D THREAD B FLATS .125 (3.2) MAX PANEL THICKNESS SHELL SIZE 5 & 6 .100 (2.5) MAX PANEL THICKNESS SHELL SIZE 7 & UP G D THREAD G .125 (3.2) MAX PANEL THICKNESS SHELL SIZE 5 & 6 .100 (2.5) MAX PANEL THICKNESS SHELL SIZE 7 & UP J THREAD DIMENSIONS Shell Size 5 6 7 8 9 10 12 ØA In. mm. .541 .610 .670 .775 .875 .980 1.062 13.74 15.49 17.02 19.69 22.23 24.89 26.97 B In. .500 .562 .635 .735 .806 .940 .986 C mm. 12.70 14.27 16.13 18.67 20.47 23.88 25.04 In. .285 .352 .411 .473 .530 .604 .712 mm. 7.24 8.94 10.44 12.01 13.46 15.34 18.08 D Threads Mating .3125-28 UN-2A .3750-28 UN-2A .4375-28 UNEF-2A .5000-32 UN-2A .5625-32 UN-2A .6250-32 UN-2A .7500-28 UN-2A E Max. In. mm. .875 .875 .875 .875 .875 .875 .875 22.22 22.22 22.22 22.22 22.22 22.22 22.22 ØF In. mm. .230 .286 .390 .445 .500 .565 .650 5.84 7.26 9.91 11.30 12.70 14.35 16.51 ØG In. mm. .051 .051 .093 .093 .093 .093 .093 1.30 1.30 2.36 2.36 2.36 2.36 2.36 H Max. In. mm. .850 .850 .850 .850 .850 .850 .850 21.59 21.59 21.59 21.59 21.59 21.59 21.59 J Threads Accessory .250-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A SERIES 800 PANEL CUTOUTS øB SERIES 800 KEY POSITIONS 60° 60° A FLAT NORMAL Z° Y° X° Z° Y° X° NORMAL Shell Size 5 6 7 8 9 10 12 A Flat In. .302 / .298 .365 / .361 .424 / .420 .486/ .482 .543/ .539 .617/.613 .725/.721 mm. 7.67/ 7.57 9.27/9.17 10.77/ 10.67 12.34/ 12.24 13.79/ 13.69 15.67/ 15.57 18.42/ 18.31 In. .318 .386 .449 .510 .574 .635 .760 øB mm. 8.08 9.80 11.40 12.95 14.58 16.12 19.30 Plug Receptacle Key Position Normal (N) X Y Z Key Rotation 150° 140° 130° 120° Shell size 5 and 6: master key is located at top dead center for normal (N) position. Shell size 7 thru 12: master key is rotated 90° from TDC. Printed in U.S.A. © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-7 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 A B C D E F G H J K L M A ØC E THREAD B A SQ B BSC ØF C H THREAD 4X Ø D THRU HOLE .320 (8.1) SHELL SIZE 5 & 6 .460 (11.7) SHELL SIZE 7 THRU 12 .039 (.10) SHELL SIZE 5 & 6 .050 (1.27) SHELL SIZE 7 THRU 12 D E F G H J K L Shell Size 5 6 7 8 9 10 12 Series 800 A SQ In. mm. .527 .588 .650 .710 .938 .938 1.031 13.39 14.92 16.51 18.03 23.83 23.83 26.19 Series 800 “Mighty Mouse” with UN Mating Thread Square Flange Crimp Receptacle Dimensions 800-010-02 and 800-011-02 Integral Band Platform 800-010-02 G MAX E THREAD Accessory Thread 800-011-02 J MAX DIMENSIONS B In. .363 .423 .483 .542 .719 .719 .812 mm. 9.22 10.74 12.27 13.77 18.26 18.26 20.62 ØD ØC In. mm. In. mm. ± .005 ± 0.13 .680 .750 .830 .938 1.250 1.250 1.375 17.27 19.05 21.08 23.83 31.75 31.75 34.93 .094 .094 .128 .128 .128 .128 .128 2.39 2.39 3.25 3.25 3.25 3.25 3.25 E Threads Mating .3125-28 UN-2A .3750-28 UN-2A .4375-28 UNEF-2A .5000-32 UN-2A .5625-32 UN-2A .6250-32 UN-2A .7500-28 UN-2A In. ØF mm. 5.84 7.26 9.91 11.30 12.70 14.35 16.51 G Max. In. mm. .750 .750 .825 .825 .825 .825 .825 19.05 19.05 20.96 20.96 20.96 20.96 20.96 H Threads Accessory .250-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A J Max. In. mm. .725 .725 .800 .800 .800 .800 .800 18.42 18.42 20.32 20.32 20.32 20.32 20.32 .230 .286 .390 .445 .500 .565 .650 SERIES 800 KEY POSITIONS Key Position Normal (N) X Y Z Key Rotation 150° 140° 130° Z° 60° 60° 120° NORMAL Y° X° Z° Y° X° NORMAL Shell size 5 and 6: master key is located at top dead center for normal (N) position. Shell size 7 thru 12: master key is rotated 90° from TDC. Plug Key Position Receptacle Key Position © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-8 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 “Mighty Mouse” with UN Mating Thread In-Line Crimp Receptacle Dimensions 800-010-01 and 800-011-01 Integral Band Platform 800-010-01 Accessory Thread 800-011-01 A FLATS øB C THREAD D MAX C THREAD F MAX G THREAD øE .320 (8.1) SHELL SIZE 5 & 6 .460 (11.7) SHELL SIZE 7 THRU 12 .039 (.10) SHELL SIZE 5 & 6 .050 (1.27) SHELL SIZE 7 THRU 12 DIMENSIONS Shell Size 5 6 7 8 9 10 12 A In. .312 .375 .445 .550 .613 .675 .800 mm. 7.92 9.53 11.30 13.97 15.57 17.15 20.32 In. ØB mm. 9.02 10.16 12.45 15.24 16.84 18.42 21.59 C Threads Mating .3125-28 UN-2A .3750-28 UN-2A .4375-28 UNEF-2A .5000-32 UN-2A .5625-32 UN-2A .6250-32 UN-2A .7500-28 UN-2A D Max. In. mm. .750 .750 .825 .825 .825 .825 .825 19.05 19.05 20.96 20.96 20.96 20.96 20.96 In. ØE mm. 5.84 7.26 9.91 11.30 12.70 14.35 16.51 F Max. In. mm. .725 .725 .800 .800 .800 .800 .800 18.42 18.42 20.32 20.32 20.32 20.32 20.32 G Threads Accessory .250-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A .355 .400 .490 .600 .663 .725 .850 .230 .286 .390 .445 .500 .565 .650 SERIES 800 KEY POSITIONS Key Position Normal (N) X Y Z Key Rotation 150° 140° 130° Z° 60° 60° 120° NORMAL Y° X° Z° Y° X° NORMAL Shell size 5 and 6: master key is located at top dead center for normal (N) position. Shell size 7 thru 12: master key is rotated 90° from TDC for normal position. Plug Key Position Receptacle Key Position © 2009 Glenair, Inc. Dimensions in inches (millimeters) and are subject to change without notice. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com C-9 Rev. 01-FEB-2009 E-Mail: sales@glenair.com Series 800 A B C D E F G H J K L M
