801-008-16M5-3SA

厂商：
GLENAIR(格伦尔)
封装：
描述：
801-008-16M5-3SA - Double-Start ACME Thread - Glenair, Inc.

数据手册：

下载801-008-16M5-3SA.pdf

立即购买

详情介绍
数据手册
价格&库存

801-008-16M5-3SA 数据手册

A B C D E F G H J K 801-008 Rear Accessory Thread L Series 801 Series 801 “Mighty Mouse” Double-Start ACME Thread Se Series 801 Plug Connectors Double-Start ACME Threads resist cross-threading and shearing.These aerospace-grade Series 801 plugs feature 1½ turns of the coupling nut to full mating. Two Shell Styles: Integral platform for direct shield attachment using BANDIT® termination system, or accessory thread for attaching a strain relief. Crimp, Rear Release contact system, now with #12 and #16 M39029 coaxial or power contacts. Harsh Environment: ﬂuorosilicone seals, aluminum or stainless steel shells, and gold-plated beryllium copper contacts for superior performance in demanding applications. Series 801 Plug Connector HOW TO ORDER Sample Part Number 801-007 Series -16 Shell Style -16 Plug with AntiDecoupling Spring M Shell Material / Finish C Aluminum / Black Anodize 7-10 Shell Size- Insert Arrangement 5-3 6-1 6-4 6-7 7-1 7-10 8-13 9-4 9-19 10-26 13-2 13-37 16-55 17-85 3 #23 1 #16 4 #23 7 #23 1 #12 10 #23 13 #23 4 #16 19 #23 26 #23 2 #12 37 #23 55 #23 85 #23 P Contact Type A Shell Key Position M Aluminum / Electroless Nickel A Standard #23 contacts Normal accept #22 through #28 AWG wire. Use the following contact codes to Alternate Key specify these contacts: Positions: P Pin 801-007 Banding Platform NF Aluminum / Cadmium with Olive Drab Chromate B C D ZN Aluminum / Zinc-Nickel with Olive Drab Chromate S Socket Special contacts for #26 to #30 AWG are also available. Use the following contact codes to specify these contacts: ZNU Aluminum / Zinc-Nickel with Black Chromate Z1 Stainless Steel / Passivated #23 contacts are packaged with connectors. #16 and #12 contacts must be ordered separately. G Pin H Socket © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com D-4 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 801 “Mighty Mouse” Double-Start ACME Thread Series 801 Cable Plug Connectors B THREAD 1.000(25.4) MAX .960 (24.4) MAX. MASTER KEY B 1 3 7 12 16 13 17 19 øC øA 4 8 STRAIGHT KNURL D THREAD Integral Band Platform 801-007 Accessory Thread 801-008 DIMENSIONS Shell Size 5 6 7 8 9 10 13 16 17 In. ØA mm. B Thread In. ØC mm. 6.22 7.37 9.91 11.30 12.70 14.22 16.51 20.45 21.59 PLUG KEY POSITIONS D Thread UNEF-2A .250-32 .3125-32 .4375-28 .5000-28 .5625-24 .6250-24 .6875-24 .9375-20 .9375-20 A° A B C D 150° 75° 95° 140° B° 210° 210° 230° 275° B° A° .540 .600 .680 .750 .810 .880 1.050 1.240 1.300 13.72 .3125-.05P-1L-2B 15.24 .375-.05P-1L-2B 17.27 .4375-.05P-1L-2B 19.05 .5000-.05-.1L-2B 20.57 .5625-.05P-.1L-2B 22.35 .6250-.05P-1L-2B 26.67 .8125-.1P-.2L-2B 31.50 1.000-.1P-.2L-2B 33.02 1.062-.1P-.2L-2B .245 .290 .390 .445 .500 .560 .650 .805 .850 © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com D-5 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 801 A C D E F G H J K L M

下载 PDF

801-008-16M5-3SA

物料型号： - 801-007系列：具有不同的壳体尺寸和插入排列，如5-3、6-1、6-4等。 - 801-008系列：后部附件螺纹式，如13-2、13-37等。

器件简介： - Series 801 “Mighty Mouse”是双起始ACME螺纹连接器，具有防交叉螺纹和剪切特性。这些航空级连接器只需要1.5圈的耦合螺母即可完全配合。

引脚分配： - 连接器支持多种引脚配置，如3#23、4#23、7#23等，表示有3个、4个和7个23号标准接触件。

参数特性： - 连接器具有氟硅橡胶密封，铝或不锈钢壳体，以及镀金铍铜接触件，适用于恶劣环境。

功能详解： - 连接器有两种壳体样式：一种是集成平台式，适用于直接屏蔽连接，使用BANDIT®终止系统；另一种是附件螺纹式，用于连接防振器。 - 提供压接、后释放接触系统，现在支持#12和#16 M39029同轴或电源接触件。

应用信息： - 适用于要求严格的应用环境，提供卓越的性能。

封装信息： - 提供多种壳体材料和表面处理选项，如阳极氧化铝、电镀锌镍、钝化不锈钢等。 - 连接器的尺寸和螺纹规格在文档中有详细说明，包括英寸和毫米单位。

801-008-16M5-3SA 价格&库存

-> 查询更多价格&库存

很抱歉，暂时无法提供与“801-008-16M5-3SA”相匹配的价格&库存，您可以联系我们找货
