804-001-06C67-SA

厂商：
GLENAIR(格伦尔)
封装：
描述：
804-001-06C67-SA - Plug Connectors - Glenair, Inc.

数据手册：

下载804-001-06C67-SA.pdf

立即购买

详情介绍
数据手册
价格&库存

804-001-06C67-SA 数据手册

A B C Series 804 Plug Connector Quick Disconnect These plugs snap securely into receptacle housings and release with a simple pull. Two Keying Styles: A single master key provides fast mating in low-light situations, or specify three keys for more polarizing options. Two Shell Styles: Integral platform for direct shield attachment using the BAND-IT® termination system, or an accessory thread for attaching a strain relief. D E F G H 804-002 804-001 Plug with Banding Platform J K L Series 804 Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect Series 804 Plug Connectors HOW TO ORDER Sample Part Number 804-001 Series -06 Shell Style -06 Plug M Shell Material / Finish C Aluminum / Black Anodize 9-19 Shell Size- Insert Arrangement 5-3 6-1 6-4 6-7 7-1 7-10 8-13 9-4 9-19 10-26 12-2 12-37 14-55 15-85 3 #23 Contacts 1 #16 Contact 4 #23 Contacts 7 #23 Contacts 1 #12 Contact 10 #23 Contacts 13 #23 Contacts 4 #16 Contacts 19 #23 Contacts 26 #23 Contacts 2 #12 Contacts 37 #23 Contacts 55 #23 Contacts 85 #23 Contacts S Contact Type Standard #23 contacts accept #22 through #28 AWG wire. Use the following contact codes to specify these contacts: Shell Key Position Omit for Single Master Key M Aluminum / Electroless Nickel P Pin NF Aluminum / Cadmium with Olive Drab Chromate S Socket Special contacts for #26 to #30 AWG are also available. Use the following contact codes to specify these contacts: Pos. A (Normal) A ZN Plug with Accessory Thread Aluminum / ZincNickel with Olive Drab Chromate Pos. B B C D Pos. C G Pin ZNU Aluminum / ZincNickel with Black Chromate #23 contacts are packaged with connectors. #16 and #12 contacts must be ordered separately. Pos. D H Socket Z1 Stainless Steel / Passivated © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com G-4 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect Series 804 Plug Connectors .990 (25.15) .561(14.25) .060 (1.52) .925 (23.50) MAX .561(14.25) .060 (1.52) KEY øA øB øC øD øC øD Integral Band Platform 804-001-06 E THREAD Accessory Thread 804-002-06 DIMENSIoNS Shell Size Size 5 6 7 8 9 10 12 14 15 In. ØA mm. 10.85 12.57 14.61 15.60 17.02 18.92 21.97 25.02 26.44 In. ØB mm. 6.25 7.26 9.91 11.23 12.70 14.33 16.51 20.45 21.59 In. ØC mm. 5.56 7.16 8.92 10.11 11.53 13.44 16.41 19.51 21.03 Ø D Max. In. mm. .250 .313 .383 .429 .486 .563 .676 .800 .860 6.35 7.95 9.73 10.90 12.34 14.30 17.17 20.32 21.84 E Threads .2500-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A .9375-20 UNEF-2A .9375-20 UNEF-2A .427 .495 .575 .614 .670 .745 .865 .985 1.041 .246 .286 .390 .442 .500 .564 .650 .805 .850 .219 .282 .351 .398 .454 .529 .646 .768 .828 SERIES 804 PLUG kEY PoSITIoNS A° A B C D 150° 75° 95° 140° B° 210° 210° 230° 275° B° A° © 2007 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. E-Mail: sales@glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 Rev. 19-AUG-2008 G-5 Series 804 A B C D E F G H J K L M

下载 PDF

804-001-06C67-SA

### 物料型号 - 804-001 Series - 804-002 Series

### 器件简介 Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect连接器是一种推拉式快速断开连接器，具有两种外壳风格：一种是用于直接屏蔽附件的集成平台，使用BAND-IT®终止系统；另一种是附件螺纹用于附加拉力释放。

### 引脚分配 - 804-001 Series提供不同的引脚配置，如5-3（3个#23接触）、6-1（1个#16接触）、6-4（4个#23接触）等。 - 804-002 Series提供2#12接触和37#23接触的配置。

### 参数特性 - 接触类型：#23接触接受#22至#28 AWG线。#16和#12接触必须单独订购。 - 两种键位风格：单主键适用于低光环境下快速配对，或指定三个键位以获得更多的极化选项。

### 功能详解 这些连接器可以安全地卡入插座外壳，并可以通过简单的拉动来释放。它们提供快速连接和断开的功能，适用于需要频繁连接和断开的应用场景。

### 应用信息 适用于需要快速、可靠连接和断开的场合，特别是在空间受限或需要频繁插拔的环境中。

### 封装信息 - 外壳材料和表面处理：铝/黑色阳极氧化、铝/无电镀镍、铝/锌镍与橄榄色钝化等。 - 外壳尺寸：提供多种尺寸，如5、6、7、8、9、10、12、14、15英寸，具体尺寸和螺纹规格在文档中有详细描述。
