804-001-06NF5-3SA

厂商：
GLENAIR(格伦尔)
封装：
描述：
804-001-06NF5-3SA - Plug Connectors - Glenair, Inc.

数据手册：

下载804-001-06NF5-3SA.pdf

立即购买

详情介绍
数据手册
价格&库存

804-001-06NF5-3SA 数据手册

A B C Series 804 Plug Connector Quick Disconnect These plugs snap securely into receptacle housings and release with a simple pull. Two Keying Styles: A single master key provides fast mating in low-light situations, or specify three keys for more polarizing options. Two Shell Styles: Integral platform for direct shield attachment using the BAND-IT® termination system, or an accessory thread for attaching a strain relief. D E F G H 804-002 804-001 Plug with Banding Platform J K L Series 804 Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect Series 804 Plug Connectors HOW TO ORDER Sample Part Number 804-001 Series -06 Shell Style -06 Plug M Shell Material / Finish C Aluminum / Black Anodize 9-19 Shell Size- Insert Arrangement 5-3 6-1 6-4 6-7 7-1 7-10 8-13 9-4 9-19 10-26 12-2 12-37 14-55 15-85 3 #23 Contacts 1 #16 Contact 4 #23 Contacts 7 #23 Contacts 1 #12 Contact 10 #23 Contacts 13 #23 Contacts 4 #16 Contacts 19 #23 Contacts 26 #23 Contacts 2 #12 Contacts 37 #23 Contacts 55 #23 Contacts 85 #23 Contacts S Contact Type Standard #23 contacts accept #22 through #28 AWG wire. Use the following contact codes to specify these contacts: Shell Key Position Omit for Single Master Key M Aluminum / Electroless Nickel P Pin NF Aluminum / Cadmium with Olive Drab Chromate S Socket Special contacts for #26 to #30 AWG are also available. Use the following contact codes to specify these contacts: Pos. A (Normal) A ZN Plug with Accessory Thread Aluminum / ZincNickel with Olive Drab Chromate Pos. B B C D Pos. C G Pin ZNU Aluminum / ZincNickel with Black Chromate #23 contacts are packaged with connectors. #16 and #12 contacts must be ordered separately. Pos. D H Socket Z1 Stainless Steel / Passivated © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com G-4 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect Series 804 Plug Connectors .990 (25.15) .561(14.25) .060 (1.52) .925 (23.50) MAX .561(14.25) .060 (1.52) KEY øA øB øC øD øC øD Integral Band Platform 804-001-06 E THREAD Accessory Thread 804-002-06 DIMENSIoNS Shell Size Size 5 6 7 8 9 10 12 14 15 In. ØA mm. 10.85 12.57 14.61 15.60 17.02 18.92 21.97 25.02 26.44 In. ØB mm. 6.25 7.26 9.91 11.23 12.70 14.33 16.51 20.45 21.59 In. ØC mm. 5.56 7.16 8.92 10.11 11.53 13.44 16.41 19.51 21.03 Ø D Max. In. mm. .250 .313 .383 .429 .486 .563 .676 .800 .860 6.35 7.95 9.73 10.90 12.34 14.30 17.17 20.32 21.84 E Threads .2500-32 UNEF-2A .3125-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .6875-24 UNEF-2A .9375-20 UNEF-2A .9375-20 UNEF-2A .427 .495 .575 .614 .670 .745 .865 .985 1.041 .246 .286 .390 .442 .500 .564 .650 .805 .850 .219 .282 .351 .398 .454 .529 .646 .768 .828 SERIES 804 PLUG kEY PoSITIoNS A° A B C D 150° 75° 95° 140° B° 210° 210° 230° 275° B° A° © 2007 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. E-Mail: sales@glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 Rev. 19-AUG-2008 G-5 Series 804 A B C D E F G H J K L M

下载 PDF

804-001-06NF5-3SA

1. 物料型号： - 804-001 Series - 804-002 Series

2. 器件简介： - Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect连接器是一种推拉式快速断开连接器，具有两种外壳风格，可以直接使用BAND-IT®终止系统进行屏蔽连接，或者使用附件螺纹连接应力消除装置。该连接器有两种键位风格，提供快速配对，尤其适用于低光环境中。

3. 引脚分配： - 引脚类型包括#23接触和#16接触，其中#23接触接受#22至#28 AWG线。#16和#12接触必须单独订购。

4. 参数特性： - 接触类型：标准#23接触接受#22至#28 AWG线。 - 特殊接触：为#26至#30线提供特殊接触。 - 外壳材料/表面处理：包括铝/黑色阳极氧化、铝/无电镀镍、铝/镉/橄榄色钝化处理等。

5. 功能详解： - 快速断开：这些插头可以安全地卡入插座外壳，并可以通过简单拉动来释放。 - 键位风格：单主键提供快速配对，或指定三个键位以获得更多的极化选项。

6. 应用信息： - 适用于需要快速连接和断开的应用场合，特别是在空间受限或需要频繁插拔的环境中。

7. 封装信息： - 外壳尺寸和螺纹规格在文档中有详细列出，包括英寸和毫米单位的尺寸，以及螺纹类型如.2500-32 UNEF-2A等。
