804-015-CB4M5-3N

厂商：
GLENAIR(格伦尔)
封装：
描述：
804-015-CB4M5-3N - Cordsets For Harsh Environments - Glenair, Inc.

数据手册：

下载804-015-CB4M5-3N.pdf

立即购买

详情介绍
数据手册
价格&库存

804-015-CB4M5-3N 数据手册

A B C D E F G H J K L 804-014 Series 804-014 Overmolded Cordset, Shielded, with Polyurethane Cable Jacket Series 804 Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect Series 804 ASAP Cordsets For Harsh Environments Glenair’s ASAP “Mighty Mouse” Overmolded Cordsets offer watertight sealing and excellent cold temperature flexibility. These cables are 100% tested and ready to use. Standard overmolded cables feature polyurethane jackets. Two Jacket Types – Extruded Estane polyurethane jacket resists abrasion and chemicals. Or, choose low smoke/ zero halogen polyurethane jackets for compliance with toxicity regulations. Shielded – These cables feature 90% coverage tinned copper braid. cable shields are terminated directly to connectors with stainless steel BAND-IT ® straps. Simpliﬁed Ordering, No Minimums ASAP cordsets are made-to-order from stocked connectors and cable. Choose #22 or #24 AWG cable with standard Estane jacket for best availability. Series 804 Overmolded ASAP Cordset HOW TO ORDER Sample Part Number -C N 2 Wire Size 2 #22 AWG (Std.) ZNU Shell Material / Finish M Aluminum / Electroless Nickel 9-19 Insert Arr. 5-3 6-1 6-4 6-7 7-1 7-10 8-13 9-4 9-19 10-26 12-2 12-37 14-55 15-85 3 #23 1 #16 4 #23 7 #23 1 #12 10 #23 13 #23 4 #16 19 #23 26 #23 2 #12 37 #23 55 #23 85 #23 N Protective Shell Cover Key Pos. P Metal Protective Covers Included -48 Length Overall Length In Inches 12 Inch Min. End A End B Connector Connector -A Plug, with Male Pin Contacts A Plug, with Male Pin Contacts Omit for Single Master Key 4 #24 AWG (Std.) -B Plug, with Female Socket Contacts B Plug, with Female Socket Contacts NF Aluminum / Cadmium with Olive Drab Chromate A N No Covers Supplied Pos. A (Normal) 804-015 6 #26 AWG Overmolded Cordset, 8 Shielded, #28 AWG -C C ZN with Low Aluminum / ZincSmoke/ Zero Receptacle, Receptacle, with with Nickel with Olive Halogen Male Pin Male Pin Drab Chromate Polyurethane Contacts Contacts Jacket ZNU B Pos. B C Pos. C D Pos. D -D D Receptacle, Receptacle, with Female with Female Socket Socket Contacts Contacts Aluminum / ZincNickel with Black Chromate Z1 Stainless Steel / Passivated N No Connector (SingleEnded) © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com G-16 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 804 “Mighty Mouse” Push-Pull Quick-Disconnect A MAX. LENGTH + 2.0/-0.0 (+50.8/ -0.0) 12 IN. (300 mm.) MIN. B MAX. SHIELDED JACKETED CABLE POLYAMIDE OVERMOLDED STRAIN RELIEF SERIES 804 RECEPTACLE OPTIONAL PROTECTIVE COVER WITH POLYURETHANE WIRE ROPE AND PULL RING RIGHT ANGLE CORDSETS LENGTH + 2.0/-0.0 (+50.8/ -0.0) 12 IN. (300 mm.) MIN. C MAX. MASTER KEY LOCATED 180° FROM CABLE EXIT DIMENSIONS Shell Size 5 6 7 8 9 10 12 14 15 A Max. B Max. C Max. D Max. E Max. In. mm. In. mm. In. mm. In. mm. In. mm. 2.20 55.9 .44 2.70 68.6 .49 2.70 68.6 .57 2.70 68.6 .60 2.70 68.6 .67 2.95 74.9 .74 3.20 81.3 .86 3.70 94.0 .98 3.95 100.3 1.04 11.2 12.4 14.5 15.2 17.0 18.8 21.8 24.9 26.4 1.500 1.500 1.700 1.750 1.750 1.750 1.750 1.750 2.000 38.10 38.10 43.18 44.45 44.45 44.45 44.45 44.50 50.80 .44 .49 .57 .60 .67 .74 .86 .98 1.04 11.2 12.4 14.5 15.2 17.0 18.8 21.8 24.9 26.4 1.85 1.85 1.90 1.95 1.95 1.95 1.95 1.95 2.20 47.0 47.0 48.3 49.5 49.5 49.5 49.5 49.5 55.9 E MAX. D MAX. How To Order Right Angle Cordsets Insert the letter “R” after the End A or End B Connector letter designator. Example Straight cable 804-014-AA4M6-4PN-48 Right Angle 804-014-ARAR4M6-4PN-48 HARSH ENVIRONMENT CORDSET SPECIFICATIONS Cable Jacket Material Cable Shield Conductors BAND-IT® Shield Termination Band Current Rating Test Voltage (Dielectric Withstanding Voltage) Insulation Resistance Operating Temperature Immersion, Mated and Unmated Solvent Resistance, Polyamide Overmold Electrical Resistance Shielding Effectiveness Flammability and Toxicity (LSZH Jacket) Thermoplastic Polyurethane, Black, UL 94 V-0 Rated Tin-Coated Copper Braid, 90% Minimum Coverage Silver Coated Stranded Wire, TFE Insulated, Per M22759/11 Stainless Steel Up to 5 AMP Continuous Duty With #22 AWG Wire 500 VAC RMS sea level, 100 VAC RMS 70,000 feet 200 megohms minimum -30° C. to +105° C. 1 meter water immersion for 1 Hour per MIL-STD-810 Method 512 Excellent Resistance to Most Solvents, Fuels, and Oils; Poor Resistance to Strong Acids and Bipolar Solvents (Alcohol) (8 Milliohms Mated Contacts) + (Wire Resistance) 50 dB minimum from 100MHz to 1000MHz. Toxicity Index 3.9 per NES 713 Oxygen Index 28% per ASTM D-2863 Smoke Index 24 per NES 711 © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com G-17 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 804 A B C D E F G H J K L M

下载 PDF

804-015-CB4M5-3N

1. 物料型号： - 804-014-C - 804-015-C - 804-015-D

2. 器件简介： - Glenair的ASAP “Mighty Mouse” Overmolded Cordsets提供防水密封和出色的低温柔性。这些电缆是100%测试并准备使用的。标准过模电缆采用聚亚安酯护套。

3. 引脚分配： - 804-014-C型号具有2个#23号男性针式接触件和3个#23号金属保护罩。 - 804-015-C型号具有C型连接器，具有女性插座接触件。 - 804-015-D型号具有D型连接器，具有女性插座接触件。

4. 参数特性： - 电缆护套材料：聚亚安酯，耐磨损和化学品。 - 电缆屏蔽：90%覆盖镀锡铜编织层。 - 导体：银包绞合线，TFE绝缘，符合M22759/11标准。 - 屏蔽效果：100MHz至1000MHz至少50dB。 - 毒性指数：NES 713标准下为3.9。 - 耐溶剂性：对大多数溶剂、燃料和油脂有极好的抗性；对强酸和双极性溶剂（如酒精）抗性差。

5. 功能详解： - 提供快速断开连接功能，适用于恶劣环境。 - 具有防水密封和低温柔性。 - 屏蔽电缆提供电磁兼容性。

6. 应用信息： - 适用于需要快速断开连接和防水密封的应用场合，特别是在恶劣环境下。

7. 封装信息： - 804-014-C型号：过模ASAP电缆组件，带有男性针式插头，屏蔽，聚亚安酯护套。 - 804-015-C型号：过模ASAP电缆组件，带有女性插座，屏蔽，低烟/零卤素聚亚安酯护套。 - 804-015-D型号：过模ASAP电缆组件，带有女性插座，无连接器（单端）。

804-015-CB4M5-3N 价格&库存

-> 查询更多价格&库存

很抱歉，暂时无法提供与“804-015-CB4M5-3N”相匹配的价格&库存，您可以联系我们找货

免费人工找货
