805-002-16NF10-13SB

厂商：
GLENAIR(格伦尔)
封装：
描述：
805-002-16NF10-13SB - Plug Connectors - Glenair, Inc.

数据手册：

下载805-002-16NF10-13SB.pdf

立即购买

详情介绍
数据手册
价格&库存

805-002-16NF10-13SB 数据手册

A B C D E 805-002 -16 Shell Style -16 Plug Connector with Ratcheting Anti-Decoupling Mechanism F G H J K L Series 805 Series 805 “Mighty Mouse” Triple-Start Series 805 Plug Connectors Two Shell Styles: Integral platform for direct shield attachment using BANDIT® termination system, or accessory thread for attaching a strain relief. EMI Ground Spring provides low shell-to-shell resistance. This nickelplated beryllium copper serpentine spring enables the Series 805 to meet greater than 60 dB shielding effectiveness from 100 MHz. to 15 GHz. Ratchet Mechanism for Secure Coupling: Series 805 connectors feature a spring mechanism in the coupling nut that locks into radial teeth on the plug barrel. This feature allows the Series 805 to stay mated even when under high vibration, without the need for safety wire or torque tools. HOW TO ORDER Sample Part Number M Shell Material / Finish C Aluminum / Black Anodize 8-4 Shell Size- Insert Arrangement 1 #16 Contact 4 #23 Contacts 7 #23 Contacts 1 #12 Contact 10 #23 Contacts 13 #23 Contacts 4 #16 Contacts 19 #23 Contacts 26 #23 Contacts 2 #12 Contacts 15-37 37 #23 Contacts 18-55 55 #23 Contacts 19-85 85 #23 Contacts Size #23 contacts are supplied with connectors. Other contact sizes are ordered separately. P Contact Type Standard #23 contacts accept #22 through #28 AWG wire. Use the following contact codes to specify these contacts: A Shell Key Position A Position A (Normal) Series M Aluminum / Electroless Nickel 805-001 Plug with Banding Platform NF Aluminum / Cadmium with Olive Drab Chromate ZN Aluminum / Zinc-Nickel with Olive Drab Chromate 8-1 8-4 8-7 9-1 9-10 10-13 11-4 11-19 12-26 15-2 B Position B P Pin C Position C S Socket Special contacts for #26 to #30 AWG are also available. Use the following contact codes to specify these contacts: D Position D ZNU 805-002 Plug with Accessory Thread Aluminum / Zinc-Nickel with Black Chromate Z1 Stainless Steel / Passivated G Pin H Socket © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com H-4 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 805 “Mighty Mouse” Triple-Start Series 805 Plug Connectors 1.131 (28.73) 1.131 (28.73) MASTER KEY EMI/RFI SPRING A THREAD EMI/RFI SPRING A THREAD øB øC øC D THREAD KNURL SELF-LOCKING COUPLING PLUG WITH ACCESSORY THREAD 805-002 PLUG WITH INTEGRAL BAND PLATFORM 805-001 DIMENSIoNS Shell Size A Threads .5000-.1P-.3L-TS-2B 8 .5625-.1P-.3L-TS-2B 9 .6250-.1P-.3L-TS-2B 10 .6875-.1P-.3L-TS-2B 11 .7500-.1P-.3L-TS-2B 12 .9375-.1P-.3L-TS-2B 15 1.1250-.1P-.3L-TS-2B 18 1.1875-.1P-.3L-TS-2B 19 In. ØB mm. Ø C Max. In. mm. 17.55 19.99 20.98 23.27 24.94 27.86 32.77 33.27 SERIES 805 kEY poSITIoNS D Threads Accessory .3750-32 UNEF-2A .4375-28 UNEF-2A .5000-28 UNEF-2A .5625-24 UNEF-2A .6250-24 UNEF-2A .7500-20 UNEF-2A .9375-20 UNEF-2A .9375-20 UNEF-2A .317 .397 .473 .519 .585 .687 .884 .884 8.05 .691 10.08 .787 12.01 .826 13.18 .916 14.86 .982 17.45 1.097 22.45 1.290 22.45 1.310 B° A° pERFoRMANCE SpECIFICATIoNS DWV Insulation Resistance Contact Resistance Operating Temperature Immersion EMI 500 VAC Sea level 5000 Megohms Minimum 8 Milliohms Maximum -55° C. to +150° C. MIL-STD-810 Method 512. One Meter for One Hour. 60 dB Minimum from 100 MHz. to 10 GHz. key Rotation key position Normal (A) B C D A 150° 75° 95° 140° B 210° 210° 230° 275° MATERIALS AND FINISHES Connector Shell Insulator Seals Pin Contact Socket Contact Contact Retainer Clip © 2007 Glenair, Inc. www.glenair.com Aluminum or Stainless Steel Liquid Crystal Polymer (LCP) Fluorosilicone Rubber, Blue Beryllium Copper, Gold over Nickel Plating Beryllium Copper, Gold over Nickel Plating, with SST Hood Beryllium Copper, Unplated CAGE Code 06324 Printed in U.S.A. E-Mail: sales@glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 Rev. 19-AUG-2008 H-5 Series 805 A B C` D E F G H K L M

下载 PDF

805-002-16NF10-13SB

1. 物料型号： - 样本零件型号：M 8-4 - 系列：805-002 - 壳体样式：带附件螺纹 - 壳体材料/表面处理：ZNU铝合金/锌镍与黑色铬酸盐Z1 - 螺纹：不锈钢/钝化

2. 器件简介： - 系列805“强力鼠”三启动 - 两种壳体样式：集成平台用于直接屏蔽附件，使用BANDIT®终止系统，或附件螺纹用于附加应力消除。 - 棘轮机制用于安全耦合：系列805连接器在耦合螺帽中设有弹簧机制，可锁定到插头桶上的径向齿。即使在高振动下也能保持连接，无需安全线或扭矩工具。 - EMI接地弹簧提供低壳体到壳体电阻。这种镀镍铍铜螺旋弹簧使系列805能够满足100 MHz至15 GHz大于60 dB的屏蔽效果。

3. 引脚分配： - 18-55 55#23接触，19-85 85#23接触也可用。使用以下接触代码指定这些接触：G针H插座。

4. 参数特性： - 介电电压：500 VAC海平面 - 绝缘电阻：至少5000兆欧姆 - 接触电阻：最大8毫欧姆 - 工作温度：-55°C至+150°C - 浸水MIL-STD-810方法512。一米一小时。 - EMI：100 MHz至10 GHz至少60 dB。

5. 功能详解： - 系列805连接器具有弹簧机制，可在高振动下保持连接，无需额外工具。 - EMI接地弹簧提供低壳体到壳体电阻，满足高屏蔽效果。

6. 应用信息： - 适用于需要高振动下保持连接和高屏蔽效果的应用。

7. 封装信息： - 连接器壳体：铝或不锈钢 - 绝缘体：液晶聚合物(LCP) - 密封：蓝色氟硅橡胶 - 针脚接触：铍铜，金镀镍 - 插座接触：铍铜，金镀镍，带SST罩 - 接触保持器夹：未镀铍铜
