805-005-07ZL9-1SA

厂商：
GLENAIR(格伦尔)
封装：
描述：
805-005-07ZL9-1SA - Receptacles With PCB or Solder Cup Contacts - Glenair, Inc.

数据手册：

下载805-005-07ZL9-1SA.pdf

立即购买

详情介绍
数据手册
价格&库存

805-005-07ZL9-1SA 数据手册

A B C D E 805-005 -07 Shell Style F G H J K L Series 805 Series 805 “Mighty Mouse” Triple-Start Series 805 Receptacles With PCB or Solder Cup Contacts These receptacles feature a low proﬁle shell for minimum protrusion inside enclosures. Contacts are nonremovable. Connectors are backﬁlled with epoxy for a watertight seal. Two Shell Styles: jam nut with o-ring for rear panel mounting, or square ﬂange. PCB Contacts feature gold-plated tails for solder termination to rigid or ﬂexible circuits. Solder Cup Contacts are factoryinstalled and fully sealed with epoxy. Series 805 Jam Nut PCB Receptacle Connector HOW TO ORDER Sample Part Number M Shell Material / Finish C Aluminum / Black Anodize 10-13 Shell Size- Insert Arrangement 8-1 8-4 8-7 9-1 9-10 10-13 11-4 11-19 12-26 15-2 1 #16 Contact 4 #23 Contacts 7 #23 Contacts 1 #12 Contact 10 #23 Contacts 13 #23 Contacts 4 #16 Contacts 19 #23 Contacts 26 #23 Contacts 2 #12 Contacts 15-37 37 #23 Contacts 18-55 55 #23 Contacts 19-85 85 #23 Contacts P Contact Type P Pin, PC Tail B Shell Key Position A Position A (Normal) Series 805-005 Receptacle, with Solder Cup or Printed Circuit Board Contacts M Aluminum / Electroless Nickel B S Socket, PC Tail Position B NF -02 Square Flange Aluminum / Cadmium with Olive Drab Chromate C Position C ZN Aluminum / Zinc-Nickel with Olive Drab Chromate D E Pin, Solder Cup Position D ZNU -07 Jam Nut Aluminum / Zinc-Nickel with Black Chromate F Socket, Solder Cup Z1 Stainless Steel / Passivated © 2007 Glenair, Inc. CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com H-10 Rev. 05-APR-2007 E-Mail: sales@glenair.com Series 805 “Mighty Mouse” Triple-Start Series 805 Receptacles With PCB or Solder Cup Contacts 4X ø D ø.005 M B BSC TYP MASTER KEYWAY .809 (20.55) øC E THREAD .227 / .217 (5.77 / 5.51) .060 (1.52) .125 (3.18) MIN. SQUARE FLANGE WITH PC TAIL 805-005-02 A SQ TYP øL .025 (0.64) øF RED FULL MATE INDICATOR BAND .888 (22.56) .165 / .155 (4.19 / 3.93) MASTER� KEYWAY E THREAD .060 (1.52) .125 (3.18) MIN. JAM NUT WITH PC TAIL 805-005-07 G FLAT øL .025 (0.64) .100 MAX PANEL THICKNESS øF øH RED FULL MATE INDICATOR BAND J FLAT TYP K THREAD DIMENSIoNS Shell Size Size 8 9 10 11 12 15 18 19 ØD E A B ØC In. mm. Threads In. mm. In. mm. In. mm. ± .003 ± .08 -.3L-TS-2A .850 .913 .975 1.039 1.099 1.288 1.475 1.537 21.59 23.19 24.77 26.39 27.91 32.74 37.47 71.06 .660 .723 .785 .848 .909 1.058 1.255 1.327 16.76 18.36 19.94 21.54 23.09 26.87 31.88 33.71 1.150 1.230 1.330 1.410 1.500 1.750 2.000 2.094 29.21 31.24 33.78 35.81 38.10 44.45 50.80 53.19 .094 .094 .094 .094 .094 .128 .128 .128 2.39 2.39 2.39 2.39 2.39 3.25 3.25 3.25 .5000-.1P .5625-.1P .6250-.1P .6875-.1P .7500-.1P .9375-.1P 1.1250-.1P 1.1875.1P K ØF G ØH ØJ Threads In. mm. In. mm. In. mm. In. mm. UN-2A .330 .432 .493 .551 .620 .703 .863 .912 8.38 .535 13.59 10.97 .661 16.79 12.52 .661 16.79 14.00 .721 18.31 15.78 .784 19.91 17.86 .970 24.64 21.92 1.147 29.13 23.16 1.221 31.01 .760 .880 .880 .955 1.060 1.203 1.389 1.450 19.30 22.35 22.35 24.26 26.92 30.56 35.28 36.83 .730 .850 .850 .925 1.035 1.173 1.359 1.420 18.54 .5625-28 21.59 .6875-28 21.59 .6875-28 23.50 .7500-28 26.29 .8125-28 29.79 1.0000-28 34.52 1.1875-28 36.07 1.2500-28 Tail Dia. #23 .018/.022 (0.46/0.56) #16 .060/.064 (1.52/1.63) #12 .092/.096 (2.34/2.44) ØL © 2007 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. E-Mail: sales@glenair.com GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 Rev. 19-AUG-2008 H-11 Series 805 A B C` D E F G H K L M

下载 PDF

805-005-07ZL9-1SA

1. 物料型号： - 805-005 Series - 样本型号：M 10-13

2. 器件简介： - Series 805 Jam Nut PCB Receptacle Connector，即Series 805 系列的Jam Nut PCB插座连接器。 - PCB接触件具有镀金尾部，用于刚性或柔性电路的焊接终止。 - 焊接杯接触件在工厂已安装并用环氧树脂完全密封。 - 这些插座具有低轮廓外壳，以最小化在机壳内部的突出部分。接触件不可拆卸。连接器用环氧树脂回填，以实现防水密封。

3. 引脚分配： - 8-1：1#16接触件 - 8-4：4#23接触件 - 9-1：8-7 7#23接触件1#12接触件 - 11-4：4#16接触件11-19 19#23接触件 - 18-55：55#23接触件 - 19-85：85#23接触件

4. 参数特性： - 两种外壳样式：带O型圈的Jam Nut用于后面板安装，或方形法兰。 - 外壳材料/表面处理：C Aluminum/Black Anodize，M Aluminum/Electroless Nickel，Drab Chromate ZN，Aluminum/Zinc-Nickel with Black Chromate Z1 Stainless Steel/Passivated。

5. 功能详解： - 该系列连接器具有三重启动功能，提供防水密封，适用于需要在恶劣环境下保持连接稳定性的应用。

6. 应用信息： - 适用于需要防水密封和低轮廓外壳的场合，如户外设备、工业控制面板等。

7. 封装信息： - 封装类型包括Jam Nut和Square Flange两种外壳样式。 - 接触件类型包括Solder Cup或Printed Circuit。 - 详细尺寸信息在文档中有表格列出，包括外壳尺寸、螺纹规格等。
