850-002-20-363

Standard Duty Electrical Pin Contact D38999 M39029/58 850-002 A AS39029 Ser. I, II, III, IV M24308 M55302 M83733 Standard Pin Crimp Contact for MIL-DTL-38999 Series I, II, III and IV Connectors Mating End Size 22 20 16 12 10 Wire Accomodation 22-28 AWG 20-24 AWG 16-20 AWG 12-14 AWG 10 AWG Military Part Number M39029/58-360 M39029/58-363 M39029/58-364 M39029/58-365 M39029/58-528 T (Ref) Color Bands H x 45° 2nd 1st S 3rd M .033 .029 .300 .295 Glenair Part Number 850-002-22-360 850-002-20-363 850-002-16-364 850-002-12-365 850-002-10-528 ØB Ø F (Flat) ØC ØG ØE Ø D Thru One Side Only V K Manufacturer Symbol S .129 .122 A Rad .010 Typ .004 .041 Ø.036 ØG ØU .040 .030 -10-528 Only 60° Typ Material and Finish* Pin Contact: Copper Alloy/Gold Plated Socket Contact: Copper Alloy/Gold Plated Socket Contact Hood: Passivated Stainless Steel * See pages A-4 and A-5 for detailed material specifications © 2011 Glenair, Inc. www.glenair.com CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com A-10 Standard Duty Electrical Pin Contact TABLE I: CONTACT DIMENSIONS Size 22 20 16 12 10 Part Number 850-002-22-360 850-002-20-363 850-002-16-364 850-002-12-365 850-002-10-528 Military Number M39029/58-360 M39029/58-363 M39029/58-364 M39029/58-365 M39029/58-528 A (rad) .020 .010 .025 .020 .025 .020 .025 .020 .025 .020 ø B Min. .0305 .0295 .041 .039 .0635 .0616 .095 .093 .126 .124 øC .062 .060 .094 .091 .130 .127 .182 .179 .242 .238 øD .022 .018 .032 .026 .042 .036 .042 .036 .052 .040 øE .0355 .0335 .048 .046 .068 .066 .102 .098 .140 .134 øF .011 max .015 max .030 .011 .062 .043 .094 .074 øG .048 .046 .070 .068 .103 .101 .151 .148 .213 .207 H .005 .003 .010 .005 .010 .005 .016 .005 .016 .005 A TABLE I (Continued): CONTACT DIMENSIONS Size 22 20 16 12 10 Part Number 850-002-22-360 850-002-20-363 850-002-16-364 850-002-12-365 850-002-10-528 Military Number M39029/58-360 M39029/58-363 M39029/58-364 M39029/58-365 M39029/58-528 K Min. .141 .209 .209 .209 .355 M – .078 .072 .088 .082 .088 .082 .115 .108 S .237 .231 .237 .231 .237 .231 .237 .231 .405 .395 T (Ref) .531 .531 .531 .531 .698 ØU – – – – .183 .177 V – – – – .121 .111 Color Bands 1st Orange Orange Orange Orange Green 2nd Blue Blue Blue Blue Red 3rd Black Orange Yellow Green Gray TABLE II: TOOL COMPATIBILITY Size 22 Part Number 850-002-22-360 Military Number M39029/58-360 AWG Handling 22, 24, 26, 28 Crimp Tool M22520/2-01 M22520/7-01 M22520/7-01 M22520/2-01 M22520/1-01 M22520/1-01 M22520/7-01 M22520/1-01 Daniels 1716P-1 Positioner M22520/2-09 M22520//7-07 M22520/7-08 M22520/2-10 M22520/1-04 (Red) M22520/1-04 (Blue) M22520/7-04 M22520/1-04 (Yellow) Daniels 1716P-1 Insertion Tool M81969/14-01 M81969/8-01 M81969/8-05 M81969/14-02 Extraction Tool M81969/14-01 M81969/8-02 M81969/8-06 M81969/14-02 20 850-002-20-363 M39029/58-363 20, 22, 24 16 12 10 850-002-16-364 850-002-12-365 850-002-10-528 M39029/58-364 M39029/58-365 M39029/58-528 16, 18, 20 12, 14 10 M81969/8-07 M81969/14-03 M81969/8-09 M81969/14-04 M81969/14-05 and M81969/8-11 M81969/8-08 M81969/14-03 M81969/8-10 M81969/14-04 M81969/14-05 and M81969/8-12 Printed in U.S.A. © 2011 Glenair, Inc. www.glenair.com CAGE Code 06324 GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 E-Mail: sales@glenair.com A-11 AS39029 M39029/58 850-002
