891-013-9PT-BRS

891-012 and -013 Series 89 Nanominiature Connectors Double Row Right Angle Surface Mount Right Angle Surface Mount PCB Nano Connectors feature gold alloy TwistPin contacts. These nanomimiature connectors offer premium performance and reliability for demanding applications. Available with #0-80 female threads, or with jackscrews for use with flexible circuits. Pre-Tinned PC Tails are coated with Sn63Pb37 tin-lead for excellent solderability. Choose Aluminum, Titanium or Stainless Steel Shells in seven layouts from 9 to 51 contacts. Complies to the requirements of MIL-DTL-32139. HOW TO ORDER RIGHT ANGLE SURFACE MOUNT PCB CONNECTORS Series Insert Arrangement/ Contact Type Shell Material and Finish Termination Type Hardware 891-012 Plug, Pin Contacts, Double Row, Right Angle Surface Mount Nanominiature Plugs (891-012) A1 Aluminum Shell, Cadmium Plating BRS ”Board Right Angle Surface Mount” T #0-80 Female Threads 891-013 Receptacle, Socket Contacts, Double Row, Right Angle Surface Mount Nanominiature 9P 15P 21P 25P 31P 37P 51P Receptacles (891-013) A2 Aluminum Shell, Electroless Nickel Plating T Titanium Shell, Unplated 9S 15S 21S 25S 31S 37S 51S S Stainless Steel Shell, Passivated Sample Part Number 891-012 — 25P A1 —BRS T MATERIALS AND FINISHES Connector Shell Insulator Contacts Hardware PC Tails PCB Trays Encapsulant See Ordering Information Liquid Crystal Polymer (LCP),30% Glass-Filled Gold Alloy, Unplated 300 Series Stainless Steel #30 (.010 Dia.) Copper Wire, Solder Dipped Liquid Crystal Polymer (LCP) or Epoxy Epoxy SPECIFICATIONS Durability Current Rating Voltage Rating (DWV) Insulation Resistance Operating Temperature Contact Resistance Thermal Vacuum Outgassing 200 Cycles Minimum 1 AMP Maximum 300 VAC RMS Sea Level 5000 Megohms Minimum -55° C. to +125° C. 71 mV. @1 AMP #30 AWG Wire 1.0% Max TML, 0.1% Max. CVCM © 2007 Glenair, Inc. CAGE Code 06324/0CA77 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 53 E-Mail: sales@glenair.com Double Row Connectors 891-012 and -013 Series 89 Nanominiature Connectors Double Row Right Angle Surface Mount DOUBLE ROW RIGHT ANGLE SURFACE MOUNT NANO DIMENSIONS Plug (Pin) Connectors A #0-80 UNF-2B, 2X FEMALE THREADED INSERTS OPTION T .125 (3.18) .040 (1.02) PIN 1 .025 (0.64) TYP .0125 (0.32) TYP .108 / .102 (2.74 / 2.59) .120 (3.05) .345 .187 (8.76) (4.75) .051 (1.30) .015 (0.38) .0575 (1.46) SKT 1 Double Row Connectors B C .015 (0.38) .0575 (1.46) .010 (0.25) .225 (5.72) .101 .051 (2.57) (1.30) D Receptacle (Socket) Connectors A .020 (0.51) #0-80 UNF-2B, 2X FEMALE THREADED NSERTS OPTION T I .125 (3.18) .040 (1.02) B C .020 (0.51) .010 (0.25) .025 (0.64) TYP .0125 (0.32) TYP D .187 (4.75) .225 (5.72) .101 (2.57) #0-80 UNF-2B 2X #0-80 UNF-2B 2X A Layout In. ± .005 9P 9S 15P 15S 21P 21S 25P 25S 31P 31S 37P 37S 51P 51S .375 .375 .450 .450 .525 .525 .575 .575 .650 .650 .725 .725 .900 .900 B BSC. mm. ± 0.13 9.52 9.52 11.43 11.43 13.33 13.33 14.60 14.60 16.51 16.51 18.41 18.41 22.86 22.86 C BSC. mm. 6.86 6.86 8.76 8.76 10.67 10.67 11.94 11.94 13.84 13.84 15.75 15.75 20.19 20.19 D mm. 4.06 4.14 5.97 6.04 7.87 7.95 9.14 9.22 11.05 11.12 12.95 13.03 17.40 17.47 In. .270 .270 .345 .345 .420 .420 .470 .470 .545 .545 .620 .620 .795 .795 In. .160 .163 .235 .238 .310 .313 .360 .363 .435 .438 .510 .513 .685 .688 In. ± .005 .170 .170 .245 .245 .320 .320 .370 .370 .445 .445 .520 .520 .695 .695 mm. ± 0.13 4.32 4.32 6.22 6.22 8.13 8.13 9.40 9.40 11.30 11.30 13.21 13.21 17.65 17.65 © 2007 Glenair, Inc. CAGE Code 06324/0CA77 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 54 E-Mail: sales@glenair.com 891-012 and -013 Series 89 Nanominiature Connectors Double Row Right Angle Surface Mount Patterns shown are for connector mounting side of PC Board. DOUBLE ROW RIGHT ANGLE SURFACE MOUNT BOARD LAYOUT—891-012 PLUGS (PIN CONTACTS) .016 (0.41) TYP PAD WIDTH .035 (0.89) LEAD LENGTH .010 (0.25) LEAD WIDTH .040 (1.02) PAD HEIGHT PAD/ FOOTPRINT DETAIL 1 . 00 (2.54) .0125 (0.32) TYP .025 (0.64) TYP 9876 54321 .037 (0.94) .175 (4.45) .0125 (0.32) TYP .025 (0.64) TYP .037 (0.94) 1111119 543210 8 7654321 .085 (2.16) .270 (6.86) .013 (0.33) .085 (2.16) .345 (8.76) .013 (0.33) 9 Contacts .0125 (0.32) TYP .025 (0.64) TYP .250 (6.35) 2211111111 1098765432 11987654321 10 15 Contacts .037 (0.94) .0125 (0.32) TYP .025 (0.64) TYP .300 (7.62) 222222111111 543210987654 .037 (0.94) .085 (2.16) .420 (10.67) .013 (0.33) 1111987654321 3210 .085 (2.16) .470 (11.94) .013 (0.33) 21 Contacts .0125 (0.32) TYP .025 (0.64) TYP .375 (9.53) 332222222222111 109876543210987 1111111987654321 6543210 25 Contacts .037 (0.94) .0125 (0.32) TYP .025 (0.64) TYP .450 (11.43) 333333332222222222 765432109876543210 .037 (0.94) .085 (2.16) .545 (13.84) .013 (0.33) 1111111111987654321 9876543210 .085 (2.16) .620 (15.75) .013 (0.33) 31 Contacts .0125 (0.32) TYP .025 (0.64) TYP .625 (15.88) 5544444444443333333333222 1098765432109876543210987 22222221111111111987654321 65432109876543210 37 Contacts .037 (0.94) .085 (2.16) .795 (20.19) .013 (0.33) 51 Contacts © 2007 Glenair, Inc. CAGE Code 06324/0CA77 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 55 E-Mail: sales@glenair.com Double Row Connectors 891-012 and -013 Series 89 Nanominiature Connectors Double Row Right Angle Surface Mount Patterns shown are for connector mounting side of PC Board. Double Row Connectors .100 (2.54) .0125 (0.32) TYP .025 (0.64) TYP 6789 DOUBLE ROW RIGHT ANGLE SURFACE MOUNT BOARD LAYOUT—891-013 RECEPTACLES .016 (0.41) TYP PAD WIDTH .035 (0.89) LEAD LENGTH .010 (0.25) LEAD WIDTH .040 (1.02) PAD HEIGHT PAD/ FOOTPRINT DETAIL .175 (4.45) .0125 (0.32) TYP .025 (0.64) TYP 9111111 012345 12345 .142 (3.61) .092 (2.34) .085 (2.16) .142 (3.61) .092 (2.34) .085 (2.16) 12345678 .270 (6.86) .345 (8.76) 9 Contacts .250 (6.35) 1111111122 2345678901 15 Contacts .300 (7.62) 111111222222 456789012345 .0125 (0.32) TYP .025 (0.64) TYP .142 (3.61) .092 (2.34) .085 (2.16) .0125 (0.32) TYP .025 (0.64) TYP .142 (3.61) .092 (2.34) .085 (2.16) 12345678911 01 1234567891111 0123 .420 (10.67) .470 (11.94) 21 Contacts .0125 (0.32) TYP .025 (0.64) TYP .142 (3.61) .092 (2.34) .085 (2.16) .375 (9.53) 111222222222233 789012345678901 1234567891111111 0123456 25 Contacts .0125 (0.32) TYP .025 (0.64) TYP .142 (3.61) .092 (2.34) .085 (2.16) .450 (11.43) 222222222233333333 012345678901234567 1234567891111111111 0123456789 .545 (13.84) .620 (15.75) 31 Contacts .0125 (0.32) TYP .025 (0.64) TYP .142 (3.61) .092 (2.34) .085 (2.16) .625 (15.88) 2223333333333444444444455 7890123456789012345678901 12345678911111111112222222 01234567890123456 37 Contacts .795 (20.19) 51 Contacts © 2007 Glenair, Inc. CAGE Code 06324/0CA77 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912 www.glenair.com 56 E-Mail: sales@glenair.com
