GSX-13

SM Crystal Specifications GSX-13 Parameters Frequency range: 20.0 ~ 50.0MHz Calibration tolerance: ±30ppm ±50ppm Other values 3 5 specify 3 5 C specify 1 2 specify Product GSX-13 Option Codes Temperature stability: 3.35 (max) 2.65 (max) ±30ppm ±50ppm ±100ppm Other values (±20ppm ~ ±100ppm) 1.00 (max) ACTUAL SIZE SOLDER PAD LAYOUT 0.80 0.40 4 1 1.30 3 2 1.30 1.30 1.30 Operating temperature range: -10 to +60°C -20 to +70°C Other values Storage temperature range: -30 to +85°C Circuit condition: 16pF 18pF 20pF 30pF 7pF max 1 4 1.20 2 3 0.70 D E F J TOP VIEW Static capacitance (C0): Scale 3:1 Oscillation mode: Fundamental Features Equivalent series resistance: 90 max Ageing: ±5ppm max first year 100µW « « « « Ceramic SM package Fundamental mode up to 50.0MHz Low cost for volume applications Suitable for hand held applications Test drive level: Soldering condition: 260°C, 10 sec x2 max Standard. Optional - Please specify required code(s) when ordering Ordering Information Product name + option codes + frequency eg: GSX-13/551D 30.0MHz 50/50/10/16-F (standard) GSX-13/5C2J 40.0MHz 50/100/20/30-F (standard) Option code X (eg GSX-13/X) denotes a custom specification. Standard Frequencies Fundamental in MHz 20.000000 24.000000 25.000000 30.000000 32.000000 40.000000 50.000000 Available on T&R - 3k pcs per reel. Refer to our website for T&R and soldering details. Tel: +44 1460 256 100 05 Feb 2002 Fax: +44 1460 256 101 E-mail: sales@golledge.com Web: www.golledge.com
