SD103A

SD103A thru SD103C Small-Signal Diode Schottky Diodes Features For general purpose applications The SD103 series is a Metal-on-silicon Schottky barrier device which is protected by a PN junction guard ring. The low forward voltage drop and fast switching make it ideal for protection of MOS devices, steering, biasing and coupling diodes for fast switching and low logic level applications. Other applications are click suppression, efficient full wave bridges in telephone subsets, and blocking diodes in rechargeable low voltage battery systems. These diodes are also available in the MiniMELF case with type designations LL103A thru LL103C. Mechanical Data Case: DO-35 Glass Case Weight: approx. 0.13g Maximum Ratings and Thermal Characteristics (Ratings at 25oC ambient temperature unless otherwise specified.) Parameter S D 103A S D 103B S D 103C Symbol Value 40 30 20 400 15 0.3 125 (1) (1) Unit Peak inverse voltage Power dissipation (Infinite heatsink) Single cycle surge 60 Hz sine wave Thermal resistance junction to ambient air Junction temperature Storage temperature range VRRM Ptot IFSM RθJA Tj TS Volts mW Amps o C/mW o (1) C C -55 to +150 (1) o Notes: 1. Valid provided that leads at a distance of 4mm from case are kept at ambient temperature. 691 Electrical Characteristics (TJ=25oC unless otherwise noted.) Parameter S D 103A S D 103B S D 103C Symbol Test Condition VR=30V VR=20V VR=10V IF=20mA IF=200mA VR=0V, f=1MHz IF=IR=50mA to 200mA, recover to 0.1IR Min. Typ. 50 10 Max. 5 5 5 0.37 0.6 Unit Leakage current Forward voltage drop Junction capacitance Reverse recovery time IR VF Ctot trr uA Volt pF ns RATINGS AND CHARACTERISTIC CURVES (TA = 25oC unless otherwise noted) 692 RATINGS AND CHARACTERISTIC CURVES (TA = 25oC unless otherwise noted) 693
