70-FUSE-3AC

System 50 ACCESSORIES CABLE ASSEMBLIES Several standard cable assemblies to connect controllers to our I/O module mounting racks may be ordered. The 72-CHH cable has a 50-pin header connector on each end to mate with those on mounting racks. The 72-CHE cable has a 50-pin header connector on one end and a 50-pin edge card connector on the other. TEST MODULES Modules for use in system set up and testing may be ordered. Modules 70M-ISW1and 70G-ISW1 simulates an input; 70M-OSW1 switch simulates an output. ORDERING INFORMATION Part Number Description Cable Assemblies 72-CHH-1 72-CHH-2 72-CHH-4 72-CHH-6 72-CHE-2 72-CHE-4 72-CHE-6 Ribbon Ribbon Ribbon Ribbon Ribbon Ribbon Ribbon cable cable cable cable cable cable cable assembly, assembly, assembly, assembly, assembly, assembly, assembly, header header header header header header header to to to to to to to header, 1 foot long header, 2 feet long header, 4 feet long header, 6 feet long edge card, 2 feet long edge card, 4 feet long edge card, 6 feet long FUSE KITS Fuse and fuse holder Replacement kits of 10 can be ordered directly from Grayhill. Controller Boards, I/O Modules, Module Racks, and Accessories are available through Authorized Grayhill Industrial Distributors. For prices and discounts, contact your local sales office, an authorized Industrial Distributor, or Grayhill. Test Modules 70L-ISW 70G-ISW1 70M-ISW1 70M-OSW1 Input module test switch, OpenLine® package Input module test switch, G5 package Input module test switch, mini package Output module test switch, 3 amp, mini package Fuses 70-FUSE-3AC 70-FUSE-3DC 70-FUSE-H Fuse, 3.15A, 5x20mm, used on all AC Digital Output Modules Fuse, 3.15A, 5x20mm, used on all Solid State OpenLine ® DC Digital Output Modules Fuse holder for Output Modules, used on all Digital Output Modules SYSTEM 50 JUMPER BARS Grayhill jumper bars are available for applications that require common terminals to be bussed together on digital I/O mounting racks. Jumper bars are available for both our Mini and G5 racks. Grayhill jumper bars are made from .032” thick tin-plated brass. The jumper bars are insulated with a molded sleeve for excellent dielectric properties. DIMENSIONS: Jumper Bars G5 .240 (6,10) DIM. L ± .010 (0,25) .500 (12,7) TYP. .100 (2,54) .180 (4,57) .032 (0,81) System 50 .655 (16,64) .087 (2,21) Mini .240 (6,10) DIM. L ± .010 (0,25) .400 (10,16) TYP. .080 (2,03) .180 (4,57) .032 (0,81) .555 (14,10) .087 (2,21) ORDERING INFORMATION: Jumper Bars for Grayhill G5 and Mini Series I/O Racks Part Number 70G-JUMP8 70G-JUMP12 70M-JUMP6 70M-JUMP8 Description 8 position jumper for G5 I/O racks 12 position jumper for G5 I/O racks 6 position jumper for Mini I/O racks 8 position jumper for Mini I/O racks Dimension “L” in. (mm) 3.60 (91,44) 5.60 (142,24) 2.08 (52,83) 2.88 (73,15) Use on Grayhill I/O Rack 70GRCK8-HL, 70GRCK16-HL, 70GRCM32-HL, 70GRCP32-HL, 70GRCK16I, 70GRCK16T 70GRCQ24-HL 70MRCQ24-HL 70MRCK8-HL, 70MRCK16-HL, 70MRCK24-HL System 50 38 G rayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
