Axial Lead & Cartridge Fuses
3AG > Time Lag > 313/315 Series
313/315 Series
®
Lead-Free 3AG, Slo-Blo
PS
E
Fuse
Description
The 3AG Slo-Blo® fuse solves a broad range of application
requirements while offering reliable performance and costeffective circuit protection.
The fuse catalog number with the suffix “ID” instantly
identifies itself upon opening by showing a discoloration
of its glass body. Guesswork and time consuming circuit
testing are eliminated. This unique design offers the same
quality performance characteristics as the standard 3AG
Slo-Blo® Fuse design.
Features
Agency Approvals
Agency
PS
E
t *OBDDPSEBODFXJUI6-
Standard 248-14
Agency File Number
Ampere Range
E10480
10mA - 10A**
LR 29862
10mA - 10A**/15A**
E10480
10A - 30A
NBK 040205E10480B/D/F/G/H
1A - 10A**/ 15A**
SU050015007/5008/5009/6004
2.25A - 8A
t 3P)4DPNQMJBOUBOE
Lead-free
t "WBJMBCMFJODBSUSJEHF
and axial lead format
and with various
forming dimensions
Applications
Used as supplementary protection in appliance or
utilization equipment to provide individual protection for
components or internal circuits.
10mA - 10A**/15A**
% of Ampere
Rating
Ampere Rating
Opening Time
100%
10mA – 30A
4 hours, Minimum
135%
10mA – 30A
1 hour, Maximum
10mA – 15A
5 sec., Min.,
30 sec., Max
20A – 30A
5 sec., Min.,
60 sec Max
200%
© 2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com/series/313.html
or /315.html for current information.
317
Revised: April 26, 2011
313/315 Series
313/315 Series
Electrical Characteristics by Series
Introduction
to &
Circuit
Protection
Axial Lead
Cartridge
Fuses
3AG > Time Lag > Transientology
313/315 Series
Electrical Characteristic Specifications by Item
Amp
Code
Ampere
Rating
(A)
Voltage
Rating
(V)
Interrupting
Rating
Agency Approvals
Nominal
Nominal
Cold
Melting
Resistance 2
I t (A2 sec)
(Ohms)
PS
E
.010
0.01
250
4300.0000
0.000121
x
x
x
.031
0.031
250
430.0000
0.00303
x
x
x
.040
0.04
250
300.0000
0.00630
x
x
x
.062
0.062
250
120.0000
0.0210
x
x
x
.100
0.1
250
43.0000
0.0850
x
x
x
.125
0.125
250
30.0000
0.152
x
x
x
.150
0.15
250
20.0000
0.270
x
x
x
.175
0.175
250
8.6700
0.177
x
x
x
.187
0.187
250
8.0100
0.230
x
x
x
.200
0.2
250
.250
0.25
250
35A@250Vac
10KA@125Vac
6.5900
0.270
x
x
x
4.2700
0.385
x
x
x
.300
0.3
250
3.1350
0.730
x
x
x
.375
0.375
250
2.0950
1.23
x
x
x
.400
0.4
250
1.8750
1.35
x
x
x
.500*
0.5
250
1.2600
2.55
x
x
x
.600
0.6
250
0.9120
4.00
x
x
x
.700
0.7
250
0.7000
5.90
x
x
x
.750
0.75
250
0.6215
7.16
x
x
x
.800
0.8
250
0.5540
8.00
x
x
x
001.*
1
250
0.3750
14.0
x
x
x
x
01.2
1.2
250
0.2780
21.5
x
x
x
x
1.25
1.25
250
0.2600
24.0
x
x
x
x
01.5*
1.5
250
0.1910
38.0
x
x
x
x
01.6
1.6
250
0.1710
49.6
x
x
x
x
01.8
1.8
250
0.1410
58.0
x
x
x
x
002.*
2
250
0.1169
77.0
x
x
x
x
2.25
2.25
250
0.0968
121
x
x
x
x
100A@250Vac
10KA@125Vac
x
02.5
2.5
250
0.0811
130
x
x
x
x
x
02.8
2.8
250
0.0675
170
x
x
x
x
x
003.*
3
250
0.0593
200
x
x
x
x
x
03.2
3.2
250
0.0529
209
x
x
x
x
x
004.*
4
250
0.0311
76.1
x
x
x
x
x
005.*
5
250
0.0214
140
x
x
x
x
x
6.25*
6.25
250
06.3
6.3
250
200@250Vac
10KA@125Vac
0.0154
242
x
x
x
x
x
0.0154
242
x
x
x
x
x
007.*
7
250
0.0128
347
x
x
x
x
x
008.*
8
250
0.0111
445
x
x
x
x
x
010.**
10
250
0.0083
760
x
x
x
x
010.*
10
32
0.0083
760
x
x
x
012.
12
32
0.0065
1200
015.**
15
125
0.0050
1870
015.
15
32
0.0050
1870
x
x
300A@32Vac
x
x
x
020.
20
32
0.0022
9560
025.
25
32
0.0017
16500
x
030.
30
32
0.0012
26900
x
* For 313series, these ratings available with an indicating option. Add the “ID” designation to the series number. i.e. 313.500ID.
** These 2 ratings are designed for special voltage requirement. For 10A, it is available as 250Vac rated and the part number is 0313010.
MX250P; for 15A, it is available as 125Vac rated and the part number is 0315015.MX125P.
313/315 Series
318
© 2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com/series/313.html
or /315.html for current information.
Axial Lead & Cartridge Fuses
3AG > Time Lag > 313/315 Series
Average Time Current Curves
1/16A
1/10A
15/100
.175A
1/4A
3/8A
1/2A
3/4A
1A
1 1/2A
2A
3A
4A
5A
7A
8A
10A
12A
15A
20A
25A
30A
Temperature Rerating Curve
1000
A
B
100
B
TIME IN SECONDS
A
10
1
A - For 313/315 Series, from 10mA to 150mA
0.1
B - For all other ampere ratings of 313/315 series
0.01
0.05 0.1
1
10
CURRENT IN AMPERES
100
1000
Soldering Parameters - Wave Soldering
260
Wave Parameter
240
220
200
Preheat:
180
(Depends on Flux Activation Temperature)
160
140
120
100
80
60
40
Lead-Free Recommendation
(Typical Industry Recommendation)
Temperature Minimum:
100° C
Temperature Maximum:
Preheat Time:
150° C
60-180 seconds
Solder Pot Temperature:
260° C Maximum
Solder Dwell Time:
2-5 seconds
240
230
220
210
200
190
180
170
160
150
140
130
120
110
90
100
80
70
60
50
40
30
0
0
20
20
Recommended Hand-Solder Parameters:
Time (Seconds)
Cooling Time
Preheat Time
Solder Iron Temperature: 350° C +/- 5°C
Heating Time: 5 seconds max.
Dwell Time
Note: These devices are not recommended for IR or
Convection Reflow process.
© 2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com/series/313.html
or /315.html for current information.
319
313/315 Series
313/315 Series
Recommended Process Parameters:
280
10
Temperature (°C) - Measured on bottom side of board
300
Introduction
to &
Circuit
Protection
Axial Lead
Cartridge
Fuses
3AG > Time Lag > Transientology
313/315 Series
Product Characteristics
Materials
Body: Glass
Cap: Nickel–plated brass
Leads: Tin–plated Copper
Operating
Temperature
–55ºC to +125ºC
Terminal Strength
MIL-STD-202G, Method 211A, Test
Condition A
Thermal Shock
MIL-STD-202G, Method 107G, Test
Condition B: (5 cycles -65°C to +125°C)
Reference IEC 60127 Second Edition
2003-01 Annex A
Vibration
MIL-STD-202G, Method 201 A
Solderability
Humidity
Product Marking
Cap1: Brand logo, current and voltage
ratings
Cap2: Series and agency approval marks
MIL-STD-202G, Method 103B, Test
Condition A: High RH (95%) and Elevated
temperature (40°C) for 240 hours
Salt Spray
MIL- STD-202G, Method 101D, Test
Condition B
Dimensions
Part Numbering System
313 000P Series
315 000P Series
0313 xxxx M X P
0.813 (.032") (1/100 - 15A)
1.016 (.040") (20 - 30A)
6.985 (.275")
Series
6.35 (.25")
Amp Code
31.75
(1.25")
32.385
(1.275")
Refer to Amp Code column of
Electrical Characteristics Table
38.1
(1.50") TYP.
Quantity Code
Axial Lead Material: Tin coated copper.
M = 1000
Packaging Code
X = Filler
Lead-free
Packaging
Packaging Specification
Quantity
Quantity &
Packaging Code
Taping Width
Bulk
Bulk
N/A
N/A
1000
100
MX
HX
N/A
N/A
Bulk
Bulk
Bulk
N/A
N/A
N/A
1000
100
1000
MX
HX
MXB
N/A
N/A
N/A
Packaging Option
313 Series
315 Series
313/315 Series
320
© 2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com/series/313.html
or /315.html for current information.
