SAM-H2-LR14SPA

SAM Series Multiway Switches NEW Features/Benefits • Multi-directional switches Typical Applications •  Automotive •  Industrial •  Avionics • Joystick switch 2-way & 4-way • Actuation force 5.3N or 6N • Footprint 20.7x18.0 mm (2-way) & 26.2x26.2 mm (4-way) • Momentary action - SPDT Specifications Environmental FUNCTION: Momentary action. OPERATING TEMPERATURE: -40ºC to +85ºC CONTACT ARRANGEMENT: SPDT per switching circuit STORAGE TEMPERATURE: -40ºC to +85ºC SWITCHING MODE: Non-Shorting SEALING LEVEL: IP30 TERMINALS: THT - Through Hole Terminals Process Mechanical Navigation C SOLDERING: Wave compatible TERMINALS: Silver plated P/N Force (N) Operating Life (Cycles*) SAM-H2-LR10SPA 6.0±2.0 30,000 1.00±0.4 Materials SAM-H2-LR14SPA 5.3±2.0 30,000 1.25±0.4 HOUSING: Polyamide UL94 HB SAM-H2-MR14SPA 5.3±2.0 30,000 1.25±0.4 COVER: PBT+ASA UL94 HB SAM-H4-MR11SPA 6.0±2.0 30,000 1.00±0.4 ACTUATOR: Polyamide UL94 HB Travel (mm) TERMINAL: Copper alloy, silver plated Notes: * per direction CONTACT: Silver alloy Electrical RATING: 15A @ 14V DC Packaging INITIAL CONTACT RESISTANCE: 100MΩ 264 pieces per box for SAM-H4-MR11SPA BOUNCE TIME:
