RF-300M-V255

assuredcommunications ® RF-300M-V150 50-watt Multiband VehiculaR aMpliFieR adapteR (Vaa) (including an/pRc-117g(V)1(c)) A high-efficiency VAA for the FAlcon III® Manpack radio in a low-profile, compact package The Falcon III® RF-300M-V150 is a 50-watt vehicular amplifier adapter (Vaa) that includes the Falcon III an/PRc-117G(V)1(c) manpack radio. Designed for long-range applications and increased communications reliability, the RF-300M-V150 provides 50 watts from 30 to 450 MHz and 20 watts from 450 MHz to 2 GHz, supporting both narrowband and wideband waveforms up to 5 MHz bandwidth. The single-unit Vaa is extremely low-profile and can be deployed in multiple configurations, including as a single unit, alongside a single channel an/VRc-110, or in a dual-unit configuration mounted in the Universal SIncGaRS Interface Module (USIM). The Vaa features separate VHF, UHF, SaTcoM, and wideband antenna ports with automatic port switching, providing the radio system with true multimission capability. The operator only needs to select the required preset on the radio to switch among ground, ground-to-air, SaTcoM, and wideband networking communications. other features provided by the RF-300M-V150 include: VHF (30 to 90 Mhz) and UHF (200 to 400 MHz) collocation filters, internal lna, VIc-1 and VIc-3 interface, wideband Pa control interface, and external power output to power accessories such as a loudspeaker or battery charger. The Vaa provides a mechanism to lock the manpack radio for physical security. Specifications for the RF-300M-V150 General Frequency Range 30 MHz-2 GHz VHF low (30-90 MHz): 50 watts PEP VHF High/UHF (90-450 MHz): 50 watts PEP Output Power UHF (450-512 MHz): Greater than 20 watts PEP Wideband (225-450 MHz): 50 watts PEP and average Wideband (450 MHz-2 GHz): 20 watts PEP Power Input Channel Bandwidth 18-34 VDc 5 kHz to 5 MHz RF-3183-AT013 RF-3184-AT320 Data Ethernet Remote Control Audio Accessory Power Interfaces RS-232, EIa-422, PPP USB, Ethernet, RS-232 VIc-1, VIc-3, lS-671 compatible 28 VDc @ 0.2a, 5.6 W VHF low: 50 ohm Bnc Antenna Ports VHF High/UHF: 50 ohm Bnc UHF SaTcoM: 50 ohm Bnc Wideband: 50 ohm n-Type Accessories 30-512 MHz Vehicular antenna 225-450 MHz Vehicular antenna (Wideband) GPS antenna, l1 and l2 bands SaTcoM antenna antenna Mount System Configuration Single Vaa system including one an/PRc-117G(V)1(c) Dual Vaa system including two an/PRc-117G(V)1(c) Dual Vaa system including one an/PRc-117G(V)1(c and one an/PRc-152 Mounting Syystem Vehicular Interface Mount (VIM) Universal SIncGaRS Interface Module (USIM) and MT-6352 shock mount Universal SIncGaRS Interface Module (USIM) and MT-6352 shock mount Physical (including shock tray) Height Depth Width Weight Color 9.25 in. (23.5 cm) 14.5 in. (37 cm) 10.5 in. (27 cm) 37 lbs. (16.8 kg) with radio caRc Green 383 RF-3071-AT230 12006-9001-01 RF-292-01 Model Number RF-300M-V150 Environmental Shock/Vibe Sand/Dust Immersion Temperature Altitude MIl-STD-810F, ground mobile MIl-STD-810F 1 meter -40° to +70°c operational to 15,000 ft. RF-300M-V250 RF-300M-V255 RF-300M-V150 RF-300M-V250 RF-300M-V255 RF Communications | 1680 University Avenue | Rochester, NY USA 14610 w ww.harris.com | 1 -585-244-5830 Specifications are subject to change without notice. © Copyright 2008 Harris Corporation 09/08 DS-400B
