2 GHz Band Power Dividers/Combiners
C/D Series
sFeatures
1.Division System
The micro stripline method, which uses the principle of the /4 impedance converter, provides excellent high frequency performance.
2.High Performance
The low insertion loss and high isolation (of over 20 dB) afforded by the Wilkinson circuit structure make these power dividers ideal for use in portable telephone base stations, measuring instruments, and for measurements.
3.Highly Reliable Design
Connectors are of the SMA type and use stainless steel for extremely high performance. The case uses corrosion-resistant aluminum and is both miniature and lightweight.
sProduct Specifications
Ratings Frequency range Characteristic impedance Maximum Input Power 1.7 to 2.3 GHz 50 ohms 1 to 25 W Operating temperature range Operating relative humidity -10ç to +65ç 95% Max.
qPlease see the specification items for details concerning insertion loss, VSWR, and isolation.
Item 1.Vibration 2.Shock Standard Conditions Frequency: 10 to 55 Hz, single amplitude of 0.75 mm, 2 hours in each of the 3 axis Acceleration of 294 m/s2, sine half-wave waveform, No damage, cracks, or parts dislocation 3 cycles in each of the 3 axis Temperature: -40ç ¡ +15ç to +35ç ¡ +85ç ¡ +15ç to +35ç 3.Temperature cycle Time: 30 ¡ 2 to 3 max. ¡ 30 ¡ 2 to 3 max. (Minutes) 100 cycles
qThe test method conforms to MIL-STD-202.
sMaterials
Part
Connector Body Connector female contacts Connector Insulator
sOrdering Information
Material Stainless steel Beryllium copper PTFE Aluminum Aluminum Dielectric Finish Passivated Gold plating
----------
2 D - 2000M - 2
1 2 3 4 1 Number of Divisions (Number of Combination) 2 Series Name:
D: Divider C: Combiner
Cover Case Board
Conductive white alumite Conductive white alumite Solder coating
3 Center Frequency
2000M : 2000MHz
4 Suffix
38
2WAY POWER DIVIDER
sSPECIFICATION
Part Number Frequency Range (GHz)
1.8~2.2
Insertion Loss (dB Max)
π(1) 0.4
V.S.W.R. (Max)
π(2) 1.3
Isolation (dB Min)
π(3) 20
Power (W)
Weight (g)
2D-2000M-1
20
110
π(1)The value of the insertion loss is the insertion loss minus the calculation value of 3 dB. π(2)The V.S.W.R. is applicable to port #0, #1, and #2. (See the Dimensions Diagram for the port numbers.) π(3)Applicable between the divider contacts.
sExternal Dimensions
PCB Mounting Pattern
50±0.1
46±0.1 4_M2.3∞0.4
4WAY POWER DIVIDER
sSPECIFICATION
Part Number Frequency Range (GHz)
1.8~2.2
Insertion Loss (dB Max)
π(1) 0.6
V.S.W.R. (Max)
π(2) 1.3
Isolation (dB Min)
π(3) 20
Power (W)
Weight (g)
4D-2000M-1
20
260
π(1)The value of the insertion loss is the insertion loss minus the calculation value of 6 dB. π(2)The V.S.W.R. is applicable to port #0, #1, #2, #3, and #4. (See the Dimensions Diagram for the port numbers.) π(3)Applicable between the divider contacts.
sExternal Dimensions
PCB Mounting Pattern
95±0.1
66±0.1 4_M2.3∞0.4
39
8WAY POWER DIVIDER
sSPECIFICATION
Part Number Frequency Range (GHz)
1.8~2.2
Insertion Loss (dB Max)
π(1)
V.S.W.R. (Max)
π(2)
Isolation (dB Min)
π(3)
Power (W)
Weight (g)
8D-2000M-1
1
1.3
20
20
480
π(1)The value of the insertion loss is the insertion loss minus the calculation value of 9 dB. π(2)The V.S.W.R. is applicable to port #0, #1, #2, #3, #4, #5, #6, #7, and #8. (See the Dimensions Diagram for the port numbers.) π(3)Applicable between the divider contacts.
sExternal Dimensions
PCB Mounting Pattern
66±0.1 152±0.1 4_M2.3∞0.4
40
3WAY POWER COMBINER
sSPECIFICATION
Part Number Frequency Range (GHz)
1.7~2.3
Insertion Loss (dB Max)
π(1) 0.5
V.S.W.R. (Max)
π(2) 1.25
Isolation (dB Min)
π(3) 22
Power (W)
Weight (g)
3C-2000M-1
1
135
π(1)The value of the insertion loss is the insertion loss minus the calculation value of 4.8 dB. π(2)The V.S.W.R. is applicable to port #0, #1, #2, and #3. (See the Dimensions Diagram for the port numbers.) π(3)Applicable between the divider contacts.
sExternal Dimensions
4-Ø2.6 75 32 14 6.5 4-4/4-36UNS-2A
PCB Mounting Pattern
9.55
#0
#1
#2
#3
9.55
32±0.1
66±0.1 4-M2.3∞0.4
25.4
25.4
8WAY POWER COMBINER
sSPECIFICATION
Part Number Frequency Range (GHz)
1.8~2.2
Insertion Loss (dB Max)
π(1) 1
89.1
66
70
V.S.W.R. (Max)
π(2) 1.3
Isolation (dB Min)
π(3) 20
Power (W)
Weight (g)
8C-2000M-1
2.5
240
π(1)The value of the insertion loss is the insertion loss minus the calculation value of 6 dB. π(2)The V.S.W.R. is applicable to port #0, #1, #2, #3, #4, #5, #6, #7, and #8. (See the Dimensions Diagram for the port numbers.) π(3)Applicable between the divider contacts.
sExternal Dimensions
136 102 4-Ø2.6 13.8 6.5 9-1/4-36UNS-2A
PCB Mounting Pattern
9.55 #0
#1
#2
#3
#4
#5
#6
#7
#7
9.55
79.1
56
60
102±0.1
56±0.1 4-M2.3∞0.4
41
2D-2000M-1
Insertion Loss
[dB] 3.4 3.2 3.0 [dB] 50 45 40 35 30
# 1. # 2 Port # 0 port #1 # 2port
Isolation
1.4
V.S.W.R.
1.3
1.2
25 20 15
# 1. # 2 port
1.1
1.8
2.0
2.2
1.8
2.0
2.2
1.0 1.8
2.0
2.2
Frequency [GHz]
Frequency [GHz]
Frequency [GHz]
4D-2000M-1
Insertion Loss
[dB] 6.6 6.4 6.2 6.0 5.8 5.6
# 1 . # 2 . # 3 . # 4 port
[dB] 50 45 40 35 30 25 20 15
#2 #1
Isolation
# 3port # 4port
V.S.W.R.
1.4
1.3
1.2
#1 #3 # 2port # 4port
# 1 . # 2 . # 3 . # 4port
1.1
# 0 port
1.8
2.0
2.2
1.8
2.0
2.2
1.0 1.8
2.0
2.2
Frequency [GHz]
Frequency [GHz]
Frequency [GHz]
8D-2000M-1
Insertion Loss
[dB] 1.0 9.8 9.6 9.4
# 1. # 2. # 3. # 4. # 5. # 6. # 7. # 8port
[dB] 50 45 40 35 30 25 20 15
#2 #6
Isolation
#1 #4
# 8port # 5port
V.S.W.R.
1.4
1.3
# 1. # 2. # 3. # 4. # 5. # 6. # 7. # 8port
1.2
# 0 port # 3port # 7port #1 #2 #5 #7 # 3port # 4port # 6port # 8port
9.2 9.0
1.1
1.8
2.0
2.2
1.8
2.0
2.2
1.0 1.8
2.0
2.2
Frequency [GHz]
Frequency [GHz]
Frequency [GHz]
42
3C-2000M-1
Insertion Loss
[dB]
5.3 5.1 4.9 4.8
# 1. # 2. # 3 Port
[dB] 50
45 40 35 30 25 22 20 15
Isolation
1.4
#1 #2 #3 # 2 port # 3 port # 1 port
V.S.W.R.
1.3 1.25 1.2
# 0 port
# 1. # 2.
# 3 port
1.1
1.7
2.0
2.3
1.8
2.0
2.2
1.0 1.7
2.0
2.3
Frequency [GHz]
Frequency [GHz]
Frequency [GHz]
8C-2000M-1
Insertion Loss
[dB]
10.0 9.8 9.6 9.4
# 1. # 2. # 3. # 4. # 5. # 6. # 7. # 8port
[dB] 50 #2
45 40 35 30 25 20 15
#6
Isolation
# 3port # 7port
#1 #4
# 8port # 5port
V.S.W.R.
1.4
1.3
# 1. # 2. # 3. # 4. # 5. # 6. # 7. # 8port
1.2
# 0 port #1 #3 #5 #7 # 2port # 4port # 6port # 8port
9.2 9.0
1.1
1.8
2.0
2.2
1.8
2.0
2.2
1.0 1.8
2.0
2.2
Frequency [GHz]
Frequency [GHz]
Frequency [GHz]
43
