AT-106

Fixed Attenuators (SMA Type) AT-100, AT-200, and AT-300 Series sFeatures 1.Abundant Variations of Attenuators Attenuation amounts are available in abundant variations from 0 to 4 dB in 0.5 dB steps, from 4 to 10 dB in 1 dB steps, and in 12, 13, 15, 20, 26 and 30 dB so that levels can be finely adjusted. AT-103 2.SMA Type The coupling portions are available in all types of plug and jack combinations and stainless steel is used for the external cladding to form a small and durable structure. AT-206 3.High Degree of Matching and High Reliability The design of the attenuation element uses a distributed constant circuit and metal film resistor. A high degree of matching is achieved as indicated in the VSWR of the appended tables. Furthermore, these attenuators show stable characteristics for environments of varying temperature, humidity, and gases. AT-310 sProduct Specifications Ratings Rated frequency range (Note) Characteristic impedance Maximum Input Power DC to 18.0 GHz 50 ohms 1W Operating temperature range Operating relative humidity -10ç to +65ç 95% Max. Note: The frequency range will differ depending on the model. Item 1.Vibration Standard Conditions Frequency of 10 to 2000 Hz, overall amplitude of 1.52 mm, acceleration of 98 m/s2 for 2 hours in each of 3 directions Acceleration of 490 m/s2, sine half-wave waveform, 3 cycles in each of the 3 axis Temperature: -55ç ¡ +5ç to +35ç ¡ +85ç ¡ +5ç to +35ç Time: 30 ¡ 15 max. ¡ 30 ¡ 15 max. (Minutes) 200 cycles No electrical discontinuity of 1 µs or more No damage, cracks, or parts dislocation 2.Shock 3.Temperature cycle No damage, cracks, or parts dislocation qThe test method conforms to MIL-STD-202. sMaterials Part Connector Body Insulator Male contacts Female contacts Attenuation element Material Stainless steel PTFE Beryllium copper Beryllium copper Metal film Finish Passivated ---------- sOrdering Information AT - 1 00-(0) 1 2 3 3 Attenuation 01 06 00-(0) 00-(0.5) 00-(3.5) : 1dB : 6dB : 0dB (Through) : 0.5dB : 3.5dB Gold plating Gold plating ---------- 1 AT: Indicates a fixed attenuator 2 Indicates the Series Name (Coupling Portion) 1: SMA plug - jack 2: SMA plug - plug 3: SMA jack - jack 78 sSpecifications Part Number Attenuation (dB) DC~12.4GHz 12.4~18GHz DC~4GHz AT-100-(0) AT-100-(0.5) AT-101 AT-100-(1.5) AT-102 AT-100-(2.5) AT-103 AT-100-(3.5) AT-104 AT-105 AT-106 AT-107 AT-108 AT-109 AT-110 AT-112 AT-113 AT-114 AT-115 AT-120 AT-203 AT-206 AT-210 AT-220 AT-303 AT-306 AT-310 AT-320 +0.5 0000 0 +1.0 0000 0 V.S.W.R.(Max) 4~12.4GHz 2.4~18GHz 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.20 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 1.30 Power (W) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Connectors Weight (g) 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 9 9 9 9 7 7 7 7 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-J • P HRM-P • P HRM-P • P HRM-P • P HRM-P • P HRM-J • J HRM-J • J HRM-J • J HRM-J • J 0.5±0.5 0.1±0.5 1.5±0.5 0.2±0.5 2.5±0.5 0.3±0.5 3.5±0.5 0.4±0.5 0.5±0.7 0.6±0.7 0.7±0.7 0.8±0.7 0.9±1.0 10±1.0 12±1.0 13±1.0 14±1.2 15±1.2 20±1.2 0.3±0.5 0.6±0.7 10±1.0 20±1.2 0.3±0.5 0.6±0.7 10±1.0 20±1.2 +1.0 0.5000 _0.5 1±1.00 1.5±1.00 2±1.00 2.5±1.00 3±1.00 3.5±1.00 4±1.00 5±1.20 6±1.20 7±1.20 8±1.20 9±1.25 10±1.25 12±1.25 13±1.25 14±1.30 15±1.30 20±1.30 3±1.00 6±1.20 10±1.25 20±1.30 3±1.00 6±1.20 10±1.250 20±1.30 Part Number Attenuation (dB) DC~8GHz V.S.W.R.(Max) DC~4GHz 1.15 1.15 4~8GHz 1.20 1.20 Power (W) 1 1 Connectors Weight (g) 8 8 AT-126 AT-130 26±1.0 30±1.2 HRM-J • P HRM-J • P 79 sExternal Dimensions AT-100 Type AT-126,130 Type AT-200 Type AT-300 Type AT-120 sTypical Data AT-103 AT-130 AT-206 AT-310 Input Power Characteristics 80
