HI-3282_06

HI-3282_06

  • 厂商:

    HOLTIC

  • 封装:

  • 描述:

    HI-3282_06 - ARINC 429 SERIAL TRANSMITTER AND DUAL RECEIVER - Holt Integrated Circuits

  • 数据手册
  • 价格&库存
HI-3282_06 数据手册
HI-3282 February 2006 ARINC 429 SERIAL TRANSMITTER AND DUAL RECEIVER FEATURES ! ARINC specification 429 compatible ! Compatible with Industry-standard alternate parts ! Small footprint 44-pin PQFP package option ! 16-Bit parallel data bus ! Direct receiver interface to ARINC bus ! Internal Lightning Protection of ARINC inputs per DO-160D, Level 3 in -10 configurations ! Timing control 10 times the data rate ! Selectable data clocks ! Automatic transmitter data timing ! Self test mode ! Parity functions ! Low power, single 5 volt supply ! Industrial & full military temperature ranges GENERAL DESCRIPTION The HI-3282 is a silicon gate CMOS device for interfacing the ARINC 429 serial data bus to a 16-bit parallel data bus. Two receivers and an independent transmitter are provided. The receiver input circuitry and logic are designed to meet the ARINC 429 specifications for loading, level detection, timing, and protocol. The ARINC inputs of the HI-3282-10 configurations also have internal lightning protection to DO-160D, Level 3. The transmitter section provides the ARINC 429 communication protocol. An external ARINC 429 Line Driver such as the Holt HI-3182 or HI-8585 is required to translate the 5 volt logic outputs to ARINC 429 drive levels. The 16-bit parallel data bus exchanges the 32-bit ARINC data word in two steps when either loading the transmitter or interrogating the receivers. The data bus interfaces with CMOS and TTL. Timing of all the circuitry begins with the master clock input, CLK. For ARINC 429 applications, the master clock frequency is 1 MHz. Each independent receiver monitors the data stream with a sampling rate 10 times the data rate. The sampling rate is software selectable at either 1MHz or 125KHz. The results of a parity check are available as the 32nd ARINC bit. The transmitter has a First In, First Out (FIFO) memory to store 8 ARINC words for transmission. The data rate of the transmitter is software selectable by dividing the master clock, CLK, by either 10 or 80. The master clock is used to set the timing of the ARINC transmission within the required resolution. PIN CONFIGURATION (Top View) - N/C - 429DI2(B) - 429DI2(A) - 429DI1(B) - 429DI1(A) - VCC - DBCEN - MR - TXCLK - CLK - N/C N/C - 1 D/R1 - 2 D/R2 - 3 SEL - 4 EN1 - 5 EN2 - 6 BD15 - 7 BD14 - 8 BD13 - 9 BD12 - 10 BD11 - 11 44 43 42 41 40 39 38 37 36 35 34 APPLICATIONS ! Avionics data communication ! Serial to parallel conversion ! Parallel to serial conversion HI-3282PQI HI-3282PQI-10 HI-3282PQT & HI-3282PQT-10 33 - N/C 32 - N/C 31 - CWSTRX 30 - ENTX 29 - 429DO 28 -429DO 27 - TX/R 26 - PL2 25 - PL1 24 - BD00 23 - BD01 44-Pin Plastic Quad Flat Pack (PQFP) (See page 10 for additional pin configurations) (DS3282 Rev. I) HOLT INTEGRATED CIRCUITS www.holtic.com N/C - 12 BD10 - 13 BD09 - 14 BD08 - 15 BD07 - 16 BD06 - 17 GND - 18 BD05 - 19 BD04 - 20 BD03 - 21 BD02 - 22 02/06 HI-3282 PIN DESCRIPTION SYMBOL VCC 429DI1 (A) 429DI1 (B) 429DI2 (A) 429DI2 (B) D/R1 D/R2 SEL EN1 EN2 BD15 BD14 BD13 BD12 BD11 BD10 BD09 BD08 BD07 BD06 GND BD05 BD04 BD03 BD02 BD01 BD00 PL1 PL2 TX/R 429DO 429DO ENTX CWSTR CLK TX CLK MR DBCEN FUNCTION POWER INPUT INPUT INPUT INPUT OUTPUT OUTPUT INPUT INPUT INPUT I/O I/O I/O I/O I/O I/O I/O I/O I/O I/O POWER I/O I/O I/O I/O I/O I/O INPUT INPUT OUTPUT OUTPUT OUTPUT INPUT INPUT INPUT OUTPUT INPUT INPUT +5V ±5% DESCRIPTION ARINC receiver 1 positive input ARINC receiver 1 negative input ARINC receiver 2 positive input ARINC receiver 2 negative input Receiver 1 data ready flag Receiver 2 data ready flag Receiver data byte selection (0 = BYTE 1) (1 = BYTE 2) Data Bus control, enables receiver 1 data to outputs Data Bus control, enables receiver 2 data to outputs if EN1 is high Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus 0V Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Latch enable for byte 1 entered from data bus to transmitter FIFO. Latch enable for byte 2 entered from data bus to transmitter FIFO. Must follow PL1. Transmitter ready flag. Goes low when ARINC word loaded into FIFO. Goes high after transmission and FIFO empty. "ONES" data output from transmitter. "ZEROES" data output from transmitter. Enable Transmission Clock for control word register Master Clock input Transmitter Clock equal to Master Clock (CLK), divided by either 10 or 80. Master Reset, active low Data bit control Enable. (Active low, with internal pull up to VDD). HOLT INTEGRATED CIRCUITS 2 HI-3282 FUNCTIONAL DESCRIPTION CONTROL WORD REGISTER The HI-3282 contains 11 data flip flops whose D inputs are connected to the data bus and clocks connected to CWSTR. Each flip flop provides options to the user as follows: DATA BUS PIN BD04 DATA BUS ARINC 429 DATA FORMAT The following table shows the bit positions in exchanging data with the receiver or the transmitter. ARINC bit 1 is the first bit transmitted or received. BYTE 1 BD BD BD BD BD BD BD BD BD BD BD BD BD BD BD BD 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 13 12 11 10 9 31 30 32 1 2 3 4 5 6 7 8 FUNCTION CONTROL PAREN DESCRIPTION Enables parity bit insertion into Transmitter data bit 32 If enabled, an internal connection is made passing 429DO and 429DO to the receiver logic inputs If enabled, ARINC bits 9 and, 10 must match the next two control word bits If Receiver 1 Decoder is enabled, the ARINC bit 9 must match this bit If Receiver 1 Decoder is enabled, the ARINC bit 10 must match this bit If enabled, ARINC bits 9 and 10 must match the next two control word bits If Receiver 2 Decoder is enabled, then ARINC bit 9 must match this bit If Receiver 2 Decoder is enabled, then ARINC bit 10 must match this bit Logic 0 enables normal odd parity and Logic 1 enables even parity output in transmitter 32nd bit CLK is divided either by 10 or 80 to obtain XMTR data clock CLK is divided either by 10 or 80 to obtain RCVR data clock ARINC BIT BYTE 2 DATA BUS ARINC BIT BD BD BD BD BD BD BD BD BD BD BD BD BD BD BD BD 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 BDO5 SELF TEST 0 = ENABLE BDO6 RECEIVER 1 DECODER 1 = ENABLE BDO7 - - THE RECEIVERS ARINC BUS INTERFACE Figure 1 shows the input circuit for each receiver. The ARINC 429 specification requires the following detection levels: BDO8 - - BDO9 RECEIVER 2 DECODER 1 = ENABLE BD10 - - STATE ONE NULL ZERO DIFFERENTIAL VOLTAGE +6.5 Volts to +13 Volts +2.5 Volts to -2.5 Volts -6.5 Volts to -13 Volts BD11 - - The HI-3282 guarantees recognition of these levels with a common mode Voltage with respect to GND less than ±5V for the worst case condition (4.75V supply and 13V signal level). The tolerances in the design guarantee detection of the above levels, so the actual acceptance ranges are slightly larger. If the ARINC signal is out of the actual acceptance ranges, including the nulls, the chip rejects the data. BD12 INVERT XMTR PARITY XMTR DATA CLK SELECT RCVR DTA CLK SELECT 1 = ENABLE BD13 0 = ÷10 1 = ÷80 0 = ÷10 1 = ÷80 BD14 vcc 429DI1 (A) OR DIFFERENTIAL AMPLIFIERS COMPARATORS ONES 429DI2 (A) GND NULL vcc 429DI1 (B) OR ZEROES 429DI2 (B) GND FIGURE 1. ARINC RECEIVER INPUT HOLT INTEGRATED CIRCUITS 3 HI-3282 FUNCTIONAL DESCRIPTION (cont.) RECEIVER LOGIC OPERATION Figure 2 shows a block diagram of the logic section of each receiver. EN1 retrieves data from receiver 1 and EN2 retrieves data from receiver 2. If another ARINC word is received and a new EOS occurs before the two bytes are retrieved, the data is overwritten by the new word. BIT TIMING The ARINC 429 specification contains the following timing specification for the received data: HIGH SPEED LOW SPEED BIT RATE 100K BPS ± 1% 12K -14.5K BPS PULSE RISE TIME 1.5 ± 0.5 µsec 10 ± 5 µsec PULSE FALL TIME 1.5 ± 0.5 µsec 10 ± 5 µsec PULSE WIDTH 5 µsec ± 5% 34.5 to 41.7 µsec INTERNAL LIGHTNING PROTECTION (-10 Only) The HI-3282-10 configurations are similar to the HI-3282 except that the ARINC inputs are internally lightning protected to DO-160D, Level 3 through 10 Kohm resistors that must be connected in series with each input from the ARINC bus. The design of the HI-3282-10 device requires the external 10 Kohm series resistors for proper ARINC level detection. The typical 10 volt differential signal is translated and input to a window comparator and latch. The comparator levels are set so that, with the external 10 Kohm resistors, they are just below the standard 6.5 V minimum ARINC data threshold and just above the 2.5 V maximum ARINC null threshold. The receivers of the HI-3282-10 when used with external 10 Kohm resistors will withstand DO-160D, Level 3, waveforms 3, 4 and 5A. No additional lightning protection circuit is necessary. RECEIVER PARITY The receiver parity circuit counts Ones received, including the parity bit, ARINC bit 32. If the result is odd, then "0" will appear in the 32nd bit. RETRIEVING DATA Once 32 valid bits are recognized, the receiver logic generates an End of Sequence (EOS). If the receiver decoder is enabled and the 9th and 10th ARINC bits match the control word program bits or if the receiver decoder is disabled, then EOS clocks the data ready flag flip flop to a "1", D/R1 or D/R2 (or both) will go low. The data flag for a receiver will remain low until after both ARINC bytes from that receiver are retrieved. This is accomplished by activating EN with SEL, the byte selector, low to retrieve the first byte and activating EN with SEL high to retrieve the second byte. APPLICATION NOTE 300 Please refer to the Holt AN-300 Application Note for additional information and recommendations on lightning protection of Holt Line Drivers and Receivers. TO PINS SEL EN D/R DECODER CONTROL BITS MUX CONTROL 32 TO 16 DRIVER CONTROL BIT BD14 CLOCK OPTION CLOCK CLK / LATCH ENABLE CONTROL BITS 9 & 10 32 BIT LATCH BIT COUNTER AND END OF SEQUENCE 32 BIT SHIFT REGISTER DATA PARITY CHECK 32ND BIT BIT CLOCK EOS EOS ONES WORD GAP WORD GAP TIMER BIT CLOCK SHIFT REGISTER START END NULL SHIFT REGISTER SEQUENCE CONTROL ZEROS SHIFT REGISTER ERROR ERROR DETECTION CLOCK FIGURE 2. RECEIVER BLOCK DIAGRAM HOLT INTEGRATED CIRCUITS 4 HI-3282 FUNCTIONAL DESCRIPTION (cont.) TRANSMITTER A block diagram of the transmitter section is shown in Figure 3. The parity generator counts the ONES in the 31-bit word. If the BD12 control word bit is set low, the 32nd bit transmitted will make parity odd. If the control bit is high, the parity is even. SELF TEST If the BD05 control word bit is set low, 429DO or 429DO are internally connected to the receivers inputs, bypassing the interface circuitry. Data to Receiver 1 is as transmitted and data to Recevier 2 is the complement. 429DO and 429DO outputs remain active during self test. FIFO OPERATION The FIFO is loaded sequentially by first pulsing PL1 to load byte 1 and then PL2 to load byte 2. The control logic automatically loads the 31 bit word in the next available position of the FIFO. If TX/R, the transmitter ready flag, is high (FIFO empty), then 8 words, each 31 bits long, may be loaded. If TX/R is low, then only the available positions may be loaded. If all 8 positions are full, the FIFO ignores further attempts to load data. SYSTEM OPERATION The two receivers are independent of the transmitter. Therefore, control of data exchanges is strictly at the option of the user. The only restrictions are: 1. The received data may be overwritten if not retrieved within one ARINC word cycle. 2. The FIFO can store 8 words maximum and ignores attempts to load addition data if full. 3. Byte 1 of the transmitter data must be loaded first. 4. Either byte of the received data may be retrieved first. Both bytes must be retrieved to clear the data ready flag. 5. After ENTX, transmission enable, goes high it cannot go low until TX/R, transmitter ready flag, goes high. Otherwise, one ARINC word is lost during transmission. DATA TRANSMISSION When ENTX goes high, enabling transmission, the FIFO positions are incremented with the top register loading into the data transmission shift register. Within 2.5 data clocks the first data bit appears at either 429DO or 429DO. The 31 bits in the data transmission shift register are presented sequentially to the outputs in the ARINC 429 format with the following timing: HIGH SPEED 10 Clocks 5 Clocks 5 Clocks 40 Clocks LOW SPEED 80 Clocks 40 Clocks 40 Clocks 320 Clocks ARINC DATA BIT TIME DATA BIT TIME NULL BIT TIME WORD GAP TIME The word counter detects when all loaded positions are transmitted and sets the transmitter ready flag, TX/R, high. TRANSMITTER PARITY Control register bit BD04 (PAREN) enables parity bit insertion into transmitter data bit 32. Parity is always inserted if DBCEN is open or high. If DBCEN is low, logic 0 on PAREN inserts data on bit 32, and logic 1 on PAREN inserts parity on bit 32. DBCEN CONTROL REGISTER BD04, BD12 BIT CLOCK MASTER RESET (MR) On a Master Reset data transmission and reception are immediately terminated, the transmit FIFO and receivers cleared as are the transmit and receive flags. The Control Register is not affected by a Master Reset. PARITY GENERATOR DATA AND NULL TIMER SEQUENCER 429DO 429DO 31 BIT PARALLEL LOAD SHIFT REGISTER WORD CLOCK BIT AND WORD GAP COUNTER START SEQUENCE ADDRESS 8 X 31 FIFO WORD COUNTER AND FIFO CONTROL INCREMENT WORD COUNT TX/R ENTX LOAD FIFO LOADING SEQUENCER DATA CLOCK PL1 PL2 CLK TX CLK DATA CLOCK DIVIDER DATA BUS FIGURE 3. TRANSMITTER BLOCK DIAGRAM CONTROL REGISTER BIT BD13 HOLT INTEGRATED CIRCUITS 5 HI-3282 FUNCTIONAL DESCRIPTION (cont.) REPEATER OPERATION The repeater mode of operation allows a data word that has been received by the HI-3282 to be placed directly into its FIFO for transmission. After a 32-bit word has been shifted into the receiver shift register, the D/R flag will go low. A logic "0" is placed on the SEL line and EN is strobed. This is the same procedure as for normal receiver operation and it places the lower byte (16) of the data word on the data bus. By strobing PL1 at the same time as EN, the byte will also be placed into the transmitter FIFO. SEL is then taken high and EN is strobed again to place the upper byte of the data word on the data bus. By strobing PL2 at the same time as EN, the second byte will also be placed into the FIFO. The data word is now ready to be transmitted according to the parity programmed into the control word register. In normal operation, either byte of a received data word may be read from the receiver latches first by use of SEL input. During repeater operation however, the lower byte of the data word must be read first. This is necessary because, as the data is being read, it is also being loaded into the FIFO and the transmitter FIFO is always loaded with the lower byte of the data word first. TIMING DIAGRAMS DATA RATE - EXAMPLE PATTERN 429DO ARINC BIT 429DO DATA NULL DATA NULL DATA NULL BIT 30 BIT 31 BIT 32 WORD GAP BIT 1 NEXT WORD LOADING CONTROL WORD DATA BUS VALID tCWSET tCWHLD CWSTR tCWSTR RECEIVER OPERATON ARINC DATA BIT 31 BIT 32 DATA READY FLAG D/R tD/R BYTE SELECT SEL DON'T CARE DON'T CARE tEND/R tEN tSELEN tENEN tDATAEN BYTE 1 VALID BYTE 2 VALID DON'T CARE tSELEN ENABLE BYTE ON BUS EN tENSEL tENSEL tD/REN DATA BUS tDATAEN tENDATA tENDATA HOLT INTEGRATED CIRCUITS 6 HI-3282 TIMING DIAGRAMS (cont.) TRANSMITTER OPERATION DATA BUS BYTE 1 VALID BYTE 2 VALID tDWSET PL1 tDWHLD tDWSET tDWHLD tPL12 tPL PL2 tPL12 TX/R tPL tTX/R TRANSMITTING DATA PL2 tDTX/R tPL2EN TX/R ENTX tENDAT 429DO or 429DO ARINC BIT tENTX/R DATA BIT 2 DATA BIT 32 DATA BIT 1 REPEATER OPERATION TIMING 429DI BIT 32 tEND/R D/R tD/R EN tD/REN tEN tENEN tEN tSELEN SEL DON'T CARE tENSEL DON'T CARE tENPL PL1 tPLEN tENPL tSELEN tENSEL tPLEN PL2 tTX/R TX/R tTX/REN ENTX tENTX/R tENDAT 429DO BIT 1 tDTX/R BIT 32 tNULL HOLT INTEGRATED CIRCUITS 7 HI-3282 ABSOLUTE MAXIMUM RATINGS Supply Voltage Vcc Voltage at ARINC input pins Voltage at any other pin DC Current Drain per input pin -0.3V to +7V -29V to +29V -0.3V to Vcc +0.3V 10mA Power Dissipation Operating Temperature Range: (Industrial) (Military) Storage Temperature Range: 500mW -40°C to +85°C -55°C to +125°C -65°C to +150°C NOTE: Stresses above those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only. Functional operation of the device at these or any other conditions above those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. DC ELECTRICAL CHARACTERISTICS Vcc = 5V ±5%, GND = 0V, TA = Operating Temperature Range (unless otherwise specified). LIMITS PARAMETER ARINC INPUTS - SYMBOL CONDITIONS MIN TYP MAX UNIT Pins: 429DI1(A), 429DI1(B), 429DI2(A), 429DI2(B) ONE ZERO NULL Differential To GND To Vcc Input Sink Input Source Differential To GND To Vcc VIH VIL VNUL RI RG RH IIH IIL CI CG CH Common mode voltage less than ±5V with respect to GND Includes the external 10KW resistors in series with each ARINC input of a -10 configuration 6.5 -13.0 -2.5 12 12 12 10.0 -10.0 0 13.0 -6.5 2.5 V V V KW KW KW 200 -450 20 20 20 µA µA pF pF pF Differential Input Voltage: Input Resistance: 27 27 Input Current: Input Capacitance: (Guaranteed but not tested) BI-DIRECTIONAL INPUTS - Pins:BD00-BD15 Input Voltage: Input Current: ALL OTHER INPUTS Input Voltage: Input Current: Input Voltage HI Input Voltage LO Input Sink Input Source VIH VIL IIH IIL 2.0 0.8 1.5 -1.5 V V µA µA Input Voltage HI Input Voltage LO Input Sink Input Source Pull-up Current (DCBEN Pin) VIH VIL IIH IIL IPU 2.0 0.8 10 -10 -150 -50 V V µA µA µA OUTPUTS Output Voltage: Output Current: (Bi-directional Pins) Output Current: (All Other Outputs) Output Capacitance: SUPPLY INPUT Standby Supply Current: Operating Supply Current: ICC1 ICC2 10 10 mA mA Logic "1" Output Voltage Logic "0" Output Voltage Output Sink Output Source Output Sink Output Source VOH VOL IOL IOH IOL IOH CO IOH = -1.5mA IOL = 1.6mA VOUT = 0.4V VOUT = VCC - 0.4V VOUT = 0.4V VOUT = VCC - 0.4V 2.7 0.4 1.6 -1.0 1.6 -1.0 15 V V mA mA mA mA pF HOLT INTEGRATED CIRCUITS 8 HI-3282 AC ELECTRICAL CHARACTERISTICS Vcc = 5V, GND = 0V, TA = Operating Temperature Range and fclk = 1mhz +0.1% with 60/40 duty cycle PARAMETER CONTROL WORD TIMING Pulse Width - CWSTR Setup - DATA BUS Valid to CWSTR HIGH Hold - CWSTR HIGH to DATA BUS Hi-Z RECEIVER TIMING Delay - Start ARINC 32nd Bit to D/R LOW: High Speed Low Speed Delay - D/R LOW to EN L0W Delay - EN LOW to D/R HIGH Setup - SEL to EN L0W Hold - SEL to EN HIGH Delay - EN L0W to DATA BUS Valid Delay - EN HIGH to DATA BUS Hi-Z Pulse Width - EN1 or EN2 Spacing - EN HIGH to next EN L0W FIFO TIMING Pulse Width - PL1 or PL2 Setup - DATA BUS Valid to PL HIGH Hold - PL HIGH to DATA BUS Hi-Z Spacing - PL1 or PL2 Delay - PL2 HIGH to TX/R LOW TRANSMISSION TIMING Spacing - PL2 HIGH to ENTX HIGH Delay - ENTX HIGH to 429DO or 429D0: High Speed Delay - ENTX HIGH to 429DO or 429D0: Low Speed Delay - 32nd ARINC Bit to TX/R HIGH Spacing - TX/R HIGH to ENTX L0W REPEATER OPERATION TIMING Delay - EN LOW to PL LOW Hold - PL HIGH to EN HIGH Delay - TX/R LOW to ENTX HIGH Master Reset Pulse Width ARINC Data Rate and Bit Timing tENPL tPLEN tTX/REN tMR 0 0 0 50 ± 1% ns ns ns ns tPL2EN tENDAT tENDAT tDTX/R tENTX/R 0 0 25 200 50 µs µs µs ns ns tPL tDWSET tDWHLD tPL12 tTX/R 50 50 10 0 840 ns ns ns ns ns tD/R tD/R tD/REN tEND/R tSELEN tENSEL tENDATA tDATAEN tEN tENEN 80 50 0 200 0 0 50 50 80 30 16 128 µs µs ns ns ns ns ns ns ns ns tCWSTR tCWSET tCWHLD 50 50 0 ns ns ns SYMBOL LIMITS MIN TYP MAX UNITS HOLT INTEGRATED CIRCUITS 9 HI-3282 ADDITIONAL HI-3282 PIN CONFIGURATIONS (See page 1 for the 44-pin Plastic QFP) PIN CONFIGURATION (Top View) Vcc (REC. 1 INPUT) 429DI1(A) (REC.1 INPUT) 429DI1(B) (REC. 2 INPUT) 429DI2(A) (REC. 2 INPUT) 429DI2(B) (REC.1 DATA FLAG) D/R1 (REC.2 DATA FLAG) D/R2 (REC. BYTE SELECT) (REC. 1 OUTPUT ENABLE) (REC. 2 OUTPUT ENABLE) SEL EN1 EN2 BD15 BD14 BD13 BD12 BD11 BD10 BD09 BD08 BD07 BD06 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 DBCEN MR CLK NC NC CWSTR (CONTROL WORD STROBE) ENTX (ENABLE XMIT) 429DO (XMIT DATA) 429DO (XMIT DATA) TX/R PL2 PL1 BD00 BD01 BD02 BD03 BD04 BD05 GND (XMIT READY FLAG) (XMIT BYTE 2 LE) (XMIT BYTE 1 LE) (MASTER RESET) (MASTER CLK IN) TX CLK (XMIT CLOCK OUT) HI-3282CDI / HI-3282CDT / HI-3282CDM HI-3282CDI-10 / HI-3282CDT-10 / HI-3282CDM-10 40-PIN CERAMIC SIDE-BRAZED DIP N/C D/R1 D/R2 SEL EN1 EN2 BD15 BD14 BD13 BD12 BD11 7 8 9 10 11 12 13 14 15 16 17 6 N/C 5 429DI2(B) 4 429DI2(A) 3 429DI1(B) 2 429DI1(A) 1 VCC 44 DBCEN 43 MR 42 TX CLK 41 CLK 40 N/C 39 N/C 38 N/C 37 CWSTR 36 ENTX 35 429DO 34 429DO 33 TX/R 32 PL2 31 PL1 30 BD00 29 BD01 N/C BD10 BD09 BD08 BD07 BD06 GND BD05 BD04 BD03 BD02 18 19 20 21 22 23 24 25 26 27 28 HI-3282PJI / HI-3282PJT HI-3282PJI-10 / HI-3282PJT-10 44-Pin J-Lead PLCC HI-3282CLI / HI-3282CT / HI-3282CLM HI-3282CLI-10 / HI-3282CT-10 / HI-3282CLM-10 44-Pin Leadless Chip Carrier (LCC) HOLT INTEGRATED CIRCUITS 10 DBCEN HI-3282 ORDERING INFORMATION HI - 3282 Cx x -xx (Ceramic) PART NUMBER INPUT SERIES RESISTANCE BUILT-IN REQUIRED EXTERNALLY No dash number -10 (Note 1) PART NUMBER 35 Kohm 25 Kohm FLOW 0 10 Kohm BURN IN LEAD FINISH TEMPERATURE RANGE I T M PART NUMBER -40°C TO +85°C -55°C TO +125°C -55°C TO +125°C PACKAGE DESCRIPTION I T M NO NO YES Gold Gold Tin / Lead (Sn / Pb) Solder CD CL 40 PIN CERAMIC SIDE BRAZED DIP 44 PIN CERAMIC LEADLESS CHIP CARRIER HI - 3282 Px x x -xx (Plastic) PART NUMBER INPUT SERIES RESISTANCE BUILT-IN REQUIRED EXTERNALLY No dash number -10 (Note 1) PART NUMBER LEAD FINISH 35 Kohm 25 Kohm 0 10 Kohm Blank F PART NUMBER Tin / Lead (Sn / Pb) Solder 100% Matte Tin (Pb-free, RoHS compliant) TEMPERATURE RANGE FLOW BURN IN I T M PART NUMBER -40°C TO +85°C -55°C TO +125°C -55°C TO +125°C PACKAGE DESCRIPTION I T M NO NO YES PJ PQ 44 PIN PLASTIC J-LEAD PLCC (Note 2) 44 PIN PLASTIC QUAD FLAT PACK (1) Internal lightning protection to DO-160D, Level 3 (-10 configurations only). Requires a 10 Kohm resistor in series with each ARINC input to guarantee specified voltage thresholds. (2) The 44-pin J-Lead PLCC package is rated as Moisture Sensitivity Level (MSL) 1 and does not require special moisture handling precautions. HOLT INTEGRATED CIRCUITS 11 HI-3282 PACKAGE DIMENSIONS inches (millimeters) 40-PIN CERAMIC SIDE-BRAZED DIP Package Type: 40C 2.020 MAX (51.308 MAX) .610 ± .010 (15.494 ± .254) .595 ± .010 (15.113 ± .254) .225 MAX (5.715 MAX) .050 TYP (1.270 TYP) .085 ± .009 (2.159 ± .229) .600 ± .010 (15.240 ± .254) .125 MIN (3.175 MIN) .018 TYP (.457 TYP) .100 BSC (2.540 BSC) .010 + .002/- .001 (.254 + .051/- .025) 44-PIN PLASTIC PLCC Package Type: 44J PIN NO. 1 .045 x 45° PIN NO. 1 IDENT .045 x 45° .050 ± .005 (1.27 ± .127) .690 ± .005 (17.526 ± .127) SQ. .653 ± .004 (16.586 ± .102) SQ. .031± .005 (.787 ± .127) .017 ± .004 (.432 ± .102) SEE DETAIL A .172 ± .008 (4.369 ± .203) .610 ± .020 (15.494± .508) .009 .011 .015 ± .002 (.381 ± .051) .020 MIN (.508 MIN) R .025 .045 DETAIL A HOLT INTEGRATED CIRCUITS 12 HI-3282 PACKAGE DIMENSIONS inches (millimeters) 44-PIN PLASTIC QUAD FLAT PACK (PQFP) Package Type: 44PQS .007 MAX. (.17) .547 ± .010 (13.90 ± .25) SQ. .394 ± .004 (10.0 ± .10) SQ. .0315 BSC (.80 BSC) .014 ± ..002 (.35 ± .05) .035 +.006 / -.004 (.88 +.15 / -.10) See Detail A .097 MAX. (2.45) .079 +.004 / -.006 (2.00 +.10 / -.15) .008 TYP. (.20 R) .012 TYP. (.30 R) 0° £ Q £ 7° Detail A 44-PIN CERAMIC LEADLESS CHIP CARRIER Package Type: 44S .020 INDEX (.508 INDEX) PIN 1 .040 x 45° 3 PLCS (1.016 x 45° 3 PLCS) .050 ± .005 (1.270 ± .127) .075 ± .004 (1.905 ± .101) .326 ± .006 (8.280 ± .152) PIN 1 .651 ± .011 (16.535 ± .279) SQ. .050 BSC (1.270 BSC) .009R ± .006 (.229R ± .152) .025 ± .003 (.635 ± .076) .092 ± .028 (2.336 ± .711) HOLT INTEGRATED CIRCUITS 13
