AIRFLOW, FORCE & PRESSURE SENSORS Product Range Guide FOR INNOVATION THAT’S WELL APART, THERE’S ONLY HONEYWELL. With more than 50,000 products ranging from snap-action, limit, toggle, and pressure switches to position, speed, pressure, and airflow sensors, Honeywell has one of the broadest sensing and switching portfolios. Honeywell sensor, switch, and control components are tailored to exact specifications for stronger performance, longer productivity, and increased safety. Enhanced accuracy and durability are built into every part, improving output and endurance. For our customers, this can reduce expenditures and operational costs. Our global footprint and channels help to competitively price such components for your chosen application and provide immediate technical support. TABLE OF CONTENTS Force Sensors While Honeywell’s switch and sensor solutions are suitable for a wide array of basic and complex applications, our custom-engineered solutions offer enhanced precision, repeatability, and ruggedness. We offer domain knowledge and technology resources, along with a close working relationship, to develop and deliver cost-effective, individually tailored solutions. Whether clean-slate development or simple modifications to an existing design are needed, our expertly engineered solutions help to meet the most stringent requirements with world-class product designs, technology integration, and customer-specific manufacturing. Global service, sourcing, and manufacturing. Industry-leading engineers. Value-added assemblies and solutions. A one-stop, full-service, globally competitive supplier. 2 Airflow Sensors 3 4-5 Board Mount Pressure Sensors 6-10 Board Mount Pressure Sensors, Flow-Through 11 Heavy Duty Pressure Transducers 12-15 Test and Measurement Pressure Transducers 16-17 FORCE SENSORS Measure the addition or backup of force, meaning the resistance of silicon-implanted piezoresistors will increase when flexed under applied force. Potential applications include infusion pumps, anesthesia monitors, blood pressure equipment, and more. MICROFORCE FMA SERIES FSA SERIES FSG SERIES Signal conditioning amplified amplified unamplified Technology silicon die (piezoresistive) silicon die (piezoresistive) silicon die (piezoresistive) Output SPI- or I2C-compatible digital • ratiometric analog • SPI- or I2C-compatible digital 360 mV typ. Force range N: 5, 15, 25 • • • • 0 N to 5 N, 0 N to 10 N, 0 N to 15 N, 0 N to 20 N Overforce 3X force range 6804 g [15 lb] 60 N max. (range dependent) Operating temperature range -40°C to 85°C [-40°F to 185°F] 0°C to 70°C [32°F to 158°F] -40°C to 85°C [-40°F to 185°F] Compensated temperature range 5°C to 50°C [41°F to 122°F] 5°C to 50°C [41°F to 122°F] – Measurements (H x W x D) 2,54 x 5,0 mm x 5,0 mm [0.1 in x 0.20 in x 0.20 in] 8,25 mm x 17,36 mm x 25,02 mm [0.32 in x 0.86 in x 0.99 in] 9,04 mm x 12,70 mm x 18,14 mm [0.36 in x 0.50 in x 0.71 in] Features very small size, calibrated and temperature compensated using on-board Application Specific Integrated Circuit (ASIC), direct mechanical coupling of sphere, calibrated and temperature compensated using on-board Application Specific Integrated Circuit (ASIC) extremely low deflection, low repeatability and linearity error N: 5, 7. 5, 10, 15, 20, 25 lb: 1, 1.5, 2, 3, 5 g: 500, 750 kg: 1, 2 FSS SERIES FSS-SMT SERIES TBF BASIC SERIES 1865 SERIES Signal conditioning unamplified unamplified unamplified unamplified Technology silicon die (piezoresistive) silicon die (piezoresistive) silicon die (piezoresistive) silicon die (piezoresistive) Output 360 mV typ. 360 mV typ. mV • current excitation: 100 mV typ. • voltage excitation: 40 mV typ. Force range or pressure range 0 N to 5 N, 0 N to 10 N, 0 N to 15 N, 0 N to 20 N 0 N to 5 N, 0 N to 10 N, 0 N to 15 N, 0 N to 20 N • 1 bar to 10 bar • 100 kPa to 1 MPa • 15 psi to 150 psi 0 psi to 5 psi, 0 psi to 10 psi, 0 psi to 15 psi, 0 psi to 25 psi, 0 psi to 30 psi Overforce or overpressure 60 N max. (range dependent) 60 N max. (range dependent) • 17 bar max. • 1.70 MPa max. • 245 psi max. (all range dependent) 60 psi max. (range dependent) Operating temperature range -40°C to 85°C [-40°F to 185°F] -40°C to 85°C [-40°F to 185°F] 0°C to 50°C [32°F to 122°F] -28°C to 54°C [-18°F to 129°F] Compensated temperature range – – 0°C to 50°C [32°F to 122°F] -1°C to 54°C [30°F to 129°F] Measurements (H x W x D) 3,18 mm x 14,22 mm x 5,59 mm 3,18 mm x 13,70 mm x 5,59 mm [0.13 in x 0.56 in x 0.22 in] [0.13 in x 0.54 in x 0.22 in] 3,89 mm x 7 mm x 7 mm [0.15 in x 0.28 in x 0.28 in] 11,05 mm x 17,15 mm x 17,15 mm [0.44 in x 0.68 in x 0.68 in] Features low deflection, low voltage, direct mechanical coupling of sphere, small size pressure measurement for liquid media extremely small size, low power consumption pressure measurement for liquid media, 8-pin DIP electrical connection low deflection, low voltage, direct mechanical coupling of sphere, small size RANGE GUIDE | Airflow, Force, and Pressure Sensors | sps.honeywell.com/ast 3 AIRFLOW SENSORS Contain advanced microstructure technology to provide a sensitive and fast response to flow, amount/direction of air or other gases. Potential applications include HVAC, gas metering, chromatography, vent hoods, and medical equipment. HONEYWELL ZEPHYR™ HAF SERIES-HIGH ACCURACY ±50 SCCM TO ±750 SCCM HONEYWELL ZEPHYR™ HAF SERIES-HIGH ACCURACY 10 SLPM TO 300 SLPM Signal conditioning amplified, compensated amplified, compensated Technology silicon die with thermally isolated heater silicon die with thermally isolated heater Flow/pressure range ±50 SCCM to ±750 SCCM 10 SLPM, 15 SLPM, 20 SLPM, 50 SLPM, 100 SLPM, 200 SLPM, 300 SLPM Output analog (Vdc), digital (I2C) digital (I2C) Power consumption • 3.3 Vdc: 40 mW typ. (no load) (analog), 23 mW typ. (no load) (digital) • 5.0 Vdc: 55 mW typ. (no load) (analog) 38 mW typ. (no load) (digital) • 3 Vdc: 60 mW max. • 10 Vdc: 200 mW max. Port style long port, short port manifold mount, 22 mm OD tapered male fitting, G 3/8 female threaded fitting Media compatibility dry non-corrosive gases dry non-corrosive gases Temperature range • operating: -20°C to 70°C [-4°F to 158°F] • compensated: 0°C to 50°C [32°F to 122°F] • operating: -20°C to 70°C [-4°F to 158°F] • compensated: 0°C to 50°C [32°F to 122°F] Dimensions (H x W x D) • long port: 20 mm x 36 mm x 19,9 mm [0.79 in x 1.42 in x 0.78 in] • short port: 17,6 mm x 28,8 mm x 19,9 mm [0.69 in x 1.13 in x 0.78 in] 110 mm x 54,4 mm x 54 mm [4.3 in x 2.14 in x 2.1 in] (22 mm OD, tapered male fitting - largest) Features high accuracy, high sensitivity at very low flows, high stability, low pressure, linear output; customizable, full calibration and temperature compensation built-in bypass provides high performance, easy integration, and custom calibration AWM5000 SERIES AWM700 SERIES Signal conditioning amplified amplified Technology silicon die silicon die Flow/pressure range 0 SLPM to 5.0 SLPM, 0 SLPM to 10.0 SLPM, 0 SLPM to 15.0 SLPM, 0 SLPM to 20.0 SLPM 200 SLPM Output analog analog Power consumption 100 mW max. 60 mW max. Port style 1/4 in-18 NPT 22 mm tapered Media compatibility dry gas only dry gas only Temperature range • operating: -20°C to 70°C [-4°F to 158°F] • compensated: 0°C to 50°C [32°F to 122°F] • operating: -25°C to 85°C [-13°F to 185°F] • compensated: 10°C to 40°C [50°F to 104°F] Dimensions (H x W x D) 35,6 mm x 162,8 mm x 32,3 mm [1.40 in x 6.41 in x 1.27 in] 82,55 mm x 46,5 x 32,5 mm [3.25 in x 1.83 in 1.28 in] Features sensitivity to low flows, enhanced response time, low power consumption, analog output, laser trimmed sensitivity to low flows, enhanced response time, low power consumption, analog output, highly stable RANGE GUIDE | Airflow, Force, and Pressure Sensors | sps.honeywell.com/ast 4 AWM1000 SERIES AWM2000 SERIES AWM3000 SERIES unamplified, compensated unamplified, compensated amplified Signal conditioning silicon die silicon die silicon die Technology ±200 SCCM, 1000 SCCM to -600 SCCM, ±5,0 mbar [2.0 inH20] ±30 SCCM, ±200 SCCM, ±1000 SCCM, ±5,0 mbar [2.0 inH20] 30 SCCM, 200 SCCM, 1000 SCCM, ±1000 SCCM, 0 mbar to 1,25 mbar [0 inH20 to 0.5 inH20], 0 mbar to 5,0 mbar [0 inH20 to 2 inH20], 5,0 mbar [2.0 inH20] Flow/pressure range analog analog analog Output 30 mW typ. 30 mW typ. 50 mW typ. Power consumption straight straight straight Port style dry gas only dry gas only dry gas only Media compatibility -25°C to 85°C [-13°F to 185°F] -25°C to 85°C [-13°F to 185°F] -25°C to 85°C [-13°F to 185°F] Temperature range 12,7 mm x 54,4 mm x 31,5 mm [0.5 in x 2.14 in x 1.24 in] 12,7 mm x 54,4 mm x 31,5 mm [0.5 in x 2.14 in x 1.24 in] 12,7 mm x 54,4 mm x 31,5 mm [0.5 in x 2.14 in x 1.24 in] Dimensions (H x W x D) sensitivity to low flows, enhanced response time, low power consumption, analog output, bi-directional sensing capability sensitivity to low flows, enhanced response time, low power consumption, analog output, bi-directional sensing capability sensitivity to low flows, fast response time, low power consumption, analog output, amplified, bi-directional flow Features AWM40000 SERIES AWM90000 SERIES unamplified (compensated) or amplified uncompensated Signal conditioning silicon die silicon die Technology ±25.0 SCCM, 1.0 SLPM, 6.0 SLPM ±200 SCCM, ±5,0 mbar [2.0 inH20] Flow/pressure range analog analog Output 60 mW max. or 75 mW max. 50 mW max. Power consumption manifold parallel Port style dry gas only dry gas only Media compatibility • operating: -40°C to 125°C [-40°F to 251°F] • compensated: -25°C to 85°C [-13°F to 185°F] -25°C to 85°C [-13°F to 185°F] Temperature range 12,7 mm x 30,5 mm x 30,2 mm [0.50 in x 1.2 in x 1.19 in] 13,08 mm x 30,48 mm x 27,94 mm [0.52 in x 1.2 in x 1.1 in] Dimensions (H x W x D) sensitivity to low flows, enhanced response time, low power consumption, analog output, laser trimmed sensitivity to low flows, fast response time, low power consumption, analog output, bi-directional sensing capability Features RANGE GUIDE | Airflow, Force, and Pressure Sensors | sps.honeywell.com/ast 5 BOARD MOUNT PRESSURE SENSORS Utilize a specialized piezoresistive, micro-machined, sensing element which allows part interchangeability, and enhanced performance, reliability, and accuracy. TRUSTABILITY™ RSC SERIES TRUSTABILITY™ HSC SERIES TRUSTABILITY™ SSC SERIES Signal conditioning amplified amplified amplified Pressure range • ±1.6 mbar to ±10 bar • ±160 Pa to ±1 MPa • ±0.5 inH20 to ±150 psi • ±1.6 mbar to ±10 bar • ±160 Pa to ±1 MPa • ±0.5 inH20 to ±150 psi • ±1.6 mbar to ±10 bar • ±160 Pa to ±1 MPa • ±0.5 inH20 to ±150 psi Pressure reference absolute, differential, gage absolute, differential, gage absolute, differential, gage Output 24-bit digital SPI • digital: I C, SPI • analog: Vdc • digital: I2C, SPI • analog: Vdc Calibrated yes yes yes Temperature compensation yes yes yes Total error band as low as ±0.25 %FSS depending on pressure range after customer auto-zero ±1 %FSS to ±3 %FSS depending on pressure range ±2 %FSS to ±5 %FSS depending on pressure range Accuracy ±0.1 %FSS BFSL ±0.25 %FSS BFSL ±0.25 %FSS BFSL Mounting option DIP, SMT DIP, SIP, SMT DIP, SIP, SMT Operating temperature range -40ºC to 85ºC [-40ºF to 185ºF] -20°C to 85°C [-4°F to 185°F] -40°C to 85°C [-40°F to 185°F] Compensated temperature range -40ºC to 85ºC [-40ºF to 185ºF] 0°C to 50°C [32°F to 122°F] -20°C to 85°C [-4°F to 185°F] Dimensions (H x W x D) varies by package style varies by package style varies by package style Approvals RoHS, WEEE RoHS, WEEE RoHS, WEEE Features industry-leading, long-term stability, total uses a 24-bit analog-to digital converter with error band, accuracy and flexibility; high integrated EEPROM, high resolution, high burst pressures and working pressure accuracy, industry-leading, accuracy, and ranges; excellent repeatability; liquid media flexibility; power consumption
