SD2440
Silicon Phototransistor
FEATURES
• Miniature, hermetically sealed, pill style, metal
can package
• 48¡ acceptance angle
• Wide operating temperature range
(- 55¡C to +125¡C)
• Ideal for direct mounting to printed circuit boards
• Wide sensitivity ranges
• Mechanically and spectrally matched to SE2460
and SE2470 infrared emitting diodes
INFRA--1.TIF
DESCRIPTION
The SD2440 is an NPN silicon phototransistor mounted
in a hermetically sealed glass lensed metal can
package. This package directly mounts in a double
sided PC board.
OUTLINE DIMENSIONS in inches (mm)
Tolerance
3 plc decimals
±0.005(0.12)
2 plc decimals
±0.020(0.51)
DIM_013.cdr
104
h
Honeywell reserves the right to make
changes in order to improve design and
supply the best products possible.
SD2440
Silicon Phototransistor
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
MIN
TYP
MAX
ABSOLUTE MAXIMUM RATINGS
UNITS
TEST CONDITIONS
SCHEMATIC
(25¡C Free-Air Temperature unless otherwise noted)
Collector-Emitter Voltage
Emitter-Collector Voltage
Power Dissipation
Operating Temperature Range
Storage Temperature Range
Soldering Temperature (10 sec)
30 V
5V
125 mW [À]
-55¡C to 125¡C
-65¡C to 150¡C
260¡C
Notes
1. Derate linearly from 25¡C free-air temperature at the rate of
1.19 mW/¡C.
Honeywell reserves the right to make
changes in order to improve design and
supply the best products possible.
h
105
SD2440
Silicon Phototransistor
SWITCHING TIME TEST CIRCUIT
SWITCHING WAVEFORM
cir_015.cdr
Fig. 1
Responsivity vs
Angular Displacement
Fig. 2
gra_037.ds4
Collector Current vs
Ambient Temperature
Normalized collector
current
-60
-45
-30
-15
0
1.6
1.2
0.8
0.4
0.0
+15 +30 +45 +60
0
Angular displacement - degrees
Fig. 3
gra_039.ds4
2.0
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
Relative response
cir_004.cdr
Dark Current vs
Temperature
10
20
30
40
50
60
70
80
Ambient temperature - °C
Fig. 4
gra_303.cdr
Non-Saturated Switching Time vs
Load Resistance
gra_041.ds4
Response time - µs
100
10
1
10
100
1000
10000
Load resistance - Ohms
106
h
Honeywell reserves the right to make
changes in order to improve design and
supply the best products possible.
SD2440
Silicon Phototransistor
Fig. 5
Spectral Responsivity
Fig. 6
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
Normalized light
current
Relative response
gra_036.ds4
400
600
800 1000 1200
Coupling Characteristics
with SE2460
gra_015.ds4
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
0.0
Wavelength - nm
0.2
0.4
0.6
0.8
1.0
1.2
Lens-to-lens separation - inches
All Performance Curves Show Typical Values
Honeywell reserves the right to make
changes in order to improve design and
supply the best products possible.
h
107
