1-1445089-2

4 RELEASED FOR PUBLICATION THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 2011 2 3 1 2011 LOC CM ALL RIGHTS RESERVED. - REVISIONS DIST 00 P LTR DESCRIPTION DATE DWN APVD A2 REVISED PER ECR-16-011506 23JUN2017 NK CX A3 ECO-19-006934 10MAY2019 AP WLS REVISED PER ECN-20-100924 15DEC2020 WLS VS B D D DIM W 0.39 1.30 HOUSING CIRCUIT NUMBER 1 CONTACT 3.86 7.88 REF 1 0.51 C 3.00 REF. 8.92 REF DIM T REF MATERIAL: HOUSING - UL 94V-0 RATED HIGH TEMP., NYLON, COLOR BLACK. CONTACTS - BRASS 2 RECOMMENDED PC BOARD THICKNESS OF 1.57. 3 PLATING: CONTACTS - 0.38µm MINIMUM GOLD ON MATING AREA. 2.54µm MINIMUM MATTE TIN ON SOLDER TAILS. ALL OVER 1.27µm MINIMUM NICKEL. C 4 COUNTERPART RECOMENDED IS PN 1445022 9DASH ACCORDING TO NUMBER OF POSITION). 5 FOR REELING DIRECTION AND PACKAGING TYPE, SEE SPECIFICATION 114-13000. B DIM X 0.15 32.20 33.00 28.70 33.00 40.14 12 3-1445089-2 29.20 30.00 25.70 30.00 37.14 11 3-1445089-1 26.20 27.00 22.70 27.00 34.14 10 3-1445089-0 23.20 24.00 19.70 24.00 31.14 9 2-1445089-9 20.20 21.00 16.70 21.00 28.14 8 2-1445089-8 17.20 18.00 13.70 18.00 25.14 7 2-1445089-7 14.20 15.00 10.70 15.00 22.14 6 2-1445089-6 11.20 12.00 7.70 12.00 19.14 5 2-1445089-5 8.00 9.00 4.70 9.00 16.14 4 2-1445089-4 3.30 - - 6.00 13.14 3 2-1445089-3 3.30 - - 3.00 10.14 2 2-1445089-2 DIM X DIM Z DIM V DIM T DIM W NO. OF POSN PART NUMBER THIS DRAWING IS A CONTROLLED DOCUMENT. A DWN J.ROOT 09OCT2000 17-APR-2001 K. WHITAKER APVD 17-APR-2001 C. JONES TE Connectivity CHK DIMENSIONS: mm 0 PLC 1 PLC 2 PLC 3 PLC 4 PLC ANGLES MATERIAL 0.13 - FINISH 1 1471-9 (3/11) TOLERANCES UNLESS OTHERWISE SPECIFIED: PRODUCT SPEC 108-1836 APPLICATION SPEC 1 WEIGHT 3 - CUSTOMER DRAWING A NAME RIGHT ANGLE THRU HOLE HEADER ASSY, 0.38 MIC GOLD CONTACTS,WITH PLASTIC HOLDDOWNS,SGL ROW,MICRO MATE-N-LOK SIZE 114-13000 B CAGE CODE A2 00779 TM RESTRICTED TO DRAWING NO - 1445089 SCALE 4:1 SHEET 1 OF 2 REV B 4 RELEASED FOR PUBLICATION THIS DRAWING IS UNPUBLISHED. C - COPYRIGHT 2011 2 3 1 2011 LOC REVISIONS DIST CM ALL RIGHTS RESERVED. 00 P LTR DESCRIPTION - DATE SEE SHEET 1 DWN - - APVD - D D 3.00 +0.20 0 1.02 TYP. 8 POS. 2 POS. 4.32 3.00 0.08 1.50 9 POS. 3 POS. 6.00 PCB LAYOUT FOR 2 POSITION 2 COMPONENT SIDE 1.02 3.00 C TYP. +0.20 0 C 4.32 4 POS. 10 POS. 3.00 0.08 PCB LAYOUT FOR 3 POSITION 2 COMPONENT SIDE 11 POS. 5 POS. DIM Z 3.00 B 6 POS. 1.02 TYP 12 POS. TYP. +0.20 0 B 4.32 7 POS. 3.00 0.08 TYP. DIM V 2.15 PCB LAYOUT FOR 4-12 POSITION COMPONENT SIDE 2 KEYING POSITION BI SIZE THIS DRAWING IS A CONTROLLED DOCUMENT. A DWN J.ROOT 09OCT2000 17-APR-2001 K. WHITAKER APVD 17-APR-2001 C. JONES TE Connectivity CHK TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: mm 0 PLC 1 PLC 2 PLC 3 PLC 4 PLC ANGLES MATERIAL FINISH 1471-9 (3/11) 0.13 - PRODUCT SPEC APPLICATION SPEC 1 WEIGHT RIGHT ANGLE THRU HOLE HEADER ASSY, 0.38 MIC GOLD CONTACTS,WITH PLASTIC HOLDDOWNS,SGL ROW,MICRO MATE-N-LOK SIZE - - CUSTOMER DRAWING A NAME CAGE CODE A2 00779 TM RESTRICTED TO DRAWING NO - 1445089 SCALE 5:1 SHEET 2 OF 2 REV B
