Quick Reference Guide DYNAMIC Series Dynamic Series is a broad product family that provides connector solutions ranging from signal level circuitry through power circuit connectivity in a ruggedized, industrialized package. The connector family is designed for use in control system applications and is suitable for a wide range of applications requiring high density, signal and power applications. Dynamic Series consists of wire-to-board, wire-to-panel and wire-to-wire connectors with diverse housings available to meet most applications. Standard crimp and spring clamp variations of parts are available. The standardized contacts limit the amount of application tooling required. PRODUCT APPLICATIONS • Industrial Control • Elevator/Escalator • Human Machine Interface (HMI) • Power Distribution • Data Communication • Industrial Process Controls • Motion & Drives • Factory Automation Computers • Production Equipment • Numeric Controllers • Robotics • Variable Frequency Drives • Servo Drives • Switching Power Supplies te.com/products/dynamicseries RoHS Ready TE Connectivity Features & Benefits FEATURES YOU EXPECT FROM THE WORLD LEADER IN CONNECTIVITY SOLUTIONS TE makes it a practice to maintain an inventory of preferred parts so orders can be fulfilled quickly. Even with specialty or custom orders, we work to reduce lead times to facilitate effective solutions within the desired timeframe. High Performance Contact ■ Large high performance contact area prevents chance ■ Box contact provides three points of contact to ensure the of disconnection over time constant flow of electricity and minimizes costly downtime associated with contact failures ■ Made of high conductivity material ■ Gold plated versions available Robust Housing Structure ■ Vibration resistant designed to withstand the most demanding and inhospitable environments ■ Full box housing design leads to long service life and great ■ Robust retention legs and contacts provide additional electrical integrity strength, acting as a strain relief and ensuring reliability ■ Clear visible circuit numbers Secure & fast Installation ■ ■ ■ Housings are keyed preventing mis-mating and misalignment, simplifying and reducing installation/ maintenance time in the field for service engineers Positive audible locking sound when inserting the connector provides assurance of positive mating Coordinated colors & designs on both headers, receptacle housings & tools prevents human errors and increases throughput during manufacturing processes Flexibility ■ Diverse housings and different position sizes support maximum design flexibility ■ Tooling options available for semi-automated termination, as well as hand tools for field termination and repair te.com/products/dynamicseries TE Connectivity Product Overview DYNAMIC SERIES FAMILY COVERS APPLICATIONS UP TO 65A WITH VARIETY OF SUB-CATEGORIES PRODUCT OVERVIEW Its platform design is suitable for a broad range of applications requiring low level signal through high current power circuits. The centralized wiring system saves time and money by offering a modular capability to expand as needed. Series D1000 D2000 D3000 D4000 D5000 D7000 Maximum Rating (A) 5 5 15 24 45 65 Maximum Rating (V) 250 250 600 600 630 630 Maximum Durability (Mating Cycles) 50 500 500 25 50 20 10, 20 20 IP Protection Class x100 Standard 4-44 ● x200 High Voltage 2-20 ● x300 Reverse x400 Sky Scraper x500 Module x600 Hybrid x700 Motor x800 HTS Module x900 Spring Clamp Cable Clamp DZ 3-36 3-50 ● ● 48 30 8-38 ● 10 ● 3-20 ● 2-20 ● 12-20 ● 2-20 ● 6 ● 12 ● 3-11 ● 2-6 ● ● 8 ● 3-4 ● 4 ● 3-4 ● 3-7 18-24 ● Not all types of Dynamic series are shown in this guide. For a complete listing please refer to the product catalog # 1-1773732-4. Available Connector Position Sizes are shown in Orange Safety Standards: ● UL: E28476 CSA: LR7189 te.com/products/dynamicseries ● ● 4 ● 4 ● ● Board to Board Dynatap 2-8 4 12 ● TE Connectivity Technological Achievements INTRODUCING OUR TECHNOLOGICAL ACHIEVEMENTS DYNAMIC Series offers solutions for all your industrial control needs both inside and outside the cabinet in a ruggedized, industrialized package. SMT Type x600 – Hybrid Type DYNAMIC SMT connectors are designed to meet the DYNAMIC Hybrid connectors combine power and signal growing demand for a reliable, low cost, reflow solder lines which can dramatically improve productivity by capable part. Special designed retention legs increase reducing assembly steps. Along with being able to mate the strenght on the circuit board. The SMT type can different size wires at one time, it contributes to more withstand a maximum temperature of 245°C. compact size and makes maintenance more efficient. Surface Mount Technology (SMT)-Type Part Number Dynamic 2600 Hybrid Part Number D1100D – Board Mounted Header Assembly (26 Pos.) 1-1939995-3 D2600 – Board Mounted Header Assembly (48 Pos.) 1827538-1 D1100D – Receptacle Housing (26 Pos.) 1-1827863-3 D2600 – Receptacle Housing (48 Pos.) 1827540-1 x900 – Spring Clamp Type DYNAMIC spring clamp version is a screw-less, crimp-less connector. Comparing it with traditional crimping types of Dynamic, the spring clamp brings the customer a quick on-site connection with no need for crimp tooling. This is necessary for some applications where the end user must do the wiring. It provides installers a quick and easy way to terminate wires in the field which saves both time and labor. Moreover, the DYNAMIC spring clamp version has all the similar features of the existing crimp type including keying, audible locking and vibration resistance. 3900 Spring Clamp Connector* Part Number 5900 Spring Clamp Connector* Part Number 3900 Board Mount Header 10 Pos. X Keyed 1-2013519-0 5900 Board Mount Header 4 Pos. X Keyed 4-2260661-1 3900 Spring Receptacle Assy 3 Pos. X Keyed 1-2134249-3 5900 Spring Receptacle Assy 4 Pos. X Keyed 4-2260663-1 3900 Board Mount Header 3 Pos. X Keyed 1-2013519-3 5900 Board Mount Header 6 Pos. X Keyed 6-2260661-1 3900 Spring Receptacle Assy 10 Pos. X Keyed 1-2134249-0 5900 Spring Receptacle Assy 6 Pos. X Keyed 6-2260663-1 3900 Spring Clamp Opener Tool 1981045 *Other position sizes available please refer to the product catalog # 1-1773721-4. te.com/products/dynamicseries 5900 Spring Clamp Opener Tool 2260828-1 TE Connectivity Control Cabinet CONTROL CABINET APPLICATIONS 1 2 3 4 5 6 7 8 9 10 11 12 13 No Application DYNAMIC Series Product 1 Controller/PLC D3100 Series 2 Wire to board for power application (up to 15A) 3 Power Supply board-to-board DZ5200 Series 4 Power outlet (middle power) Dynatap 3200 5 Human Machine Interfaces 6 Wire to board (multi position) D1100 Series 7 Wire to board for signal application D1200 Series 8 Wire to board for signal application D2000 Series 9 Cabinet I/O and power distribution Dynamic HTS Module 10 Sensor I/O D1500 Series 11 Wire to board for power application (up to 30A) D5200 Series 12 Wire to board for power application (up to 20A) D4200 Series 13 Power outlet (high power) D7100 Series te.com/products/dynamicseries D3100 Series D1100 Series TE Connectivity Signal Application SIGNAL APPLICATION D-1000 SERIES Parts shown in grey above are actually black in color Type* Receptacle Housing D-1100S 1-Row Type (10 Pos.) 1-1939758-0 D-1200S High Voltage 1-Row Type (2 Pos.) 1-1871465-2 D-1100D 2-Row Type (34 Pos.) 1-1827863-7 D-1200D 2-Row Type (20 Pos.) D-1500T 3-Row Type (6 Pos.) D-1500T Junction Box (10 Pos.) 1-1827864-0 1-2069029-2 1971150-1 Tab Housing Part Number Board Mount Header Part Number Panel Type - Horizontal Type 1-1939760-0 Free-Hanging Type - Vertical Type - Free-Hanging Type 1-1903129-2 Vertical Type 1-1871468-2 1-1939638-7 Panel Type 1-1903128-7 Horizontal Type Free-Hanging Type 1-1903127-7 Vertical Type 1-1827872-7 Panel Type 1-1903131-0 Horizontal Type 1-1827876-0 Free-Hanging Type 1-1903130-0 Vertical Type 1-1827875-0 Panel Type 1-2040404-2 Horizontal Type 1-1827583-2 Free-Hanging Type 1-2040444-2 Vertical Type 1-1827581-2 Panel Type Horizontal 1971151-1 Panel Type Vertical 1971151-2 - - * Part numbers refer only to the shown position size. For different position sizes and keyings please see catalog 1-1773721-4. Spring Clamp Type of the D-1900D (8 Pos.)* Part Number Surface Mounted Technology (SMT)-Type** Part Number Receptacle Assembly (Spring Type) 1-1871940-4 D1100D - Board-Mount Tab Header (40 Pos.) 1-1939995-0 Board Mount Header (Horizontal) 1-1871935-4 D1200D - Board-Mount Tab Header (12 Pos.) 1-2013407-6 Board Mount Header (Vertical) 1-2013325-4 ** SMT Not Pictured Above Spring Clamp Tool te.com/products/dynamicseries 1891348-1 TE Connectivity Signal Application SIGNAL APPLICATION D-2000 SERIES Parts shown in grey above are actually black in color Type* D-2100S 1-Row Type (3 Pos.) Receptacle Housing 1-1318120-3 D-2100D 2-Row Type (8 Pos.) 1-1318119-4 D-2600 2-Row Combined Type (48 Pos.) 1827540-1 Tab Housing Part Number Board Mount Header 1-1318116-3 Horizontal Free-Hanging Type 1-1318117-3 Vertical 1318123-1 Panel 1-1318114-4 Horizontal 1376009-1 Free-Hanging Type 1-1318115-4 Vertical 1318125-1 - - Vertical 1827538-1 * Part numbers refer only to the shown position size. For different position sizes and keyings please see catalog # 1-1773721-4. D-2100M Drawer Type (50 Pos.) Part Number Receptacle Housing 1318577-1 Board Mount Header 1318579-1 Receptacle Assembly (with screw) 1376072-2 Tab Housing Panel Type 1318578-1 Tab Assembly (with screw) 1376073-2 Panel Mounting Screw 1376059-1 te.com/products/dynamicseries Part Number Panel 1376135-1 TE Connectivity Signal and Power Application SIGNAL AND POWER APPLICATION D-3000 SERIES Parts shown in grey above are actually black in color Type* D-3100S 1-Row Type (3 Pos.) D-3100M Modular 2-Row Type (6 Pos.) D-3100D 2-Row Type (6 Pos.) D-3100S SMT Type (5 Pos.) Receptacle Housing 1-178288-3 1-178288-3 178289-3 1-178288-5 Tab Housing Part Number Part Number 1-178802-3 Horizontal Type 1-178293-2 Free-Hanging Type 1-177648-3 Vertical Type 1-178313-2 Panel Type - Horizontal Type 1-178137-2 Free-Hanging Type - Vertical Type 1-178141-2 Panel Type 178803-3 Horizontal Type 178303-2 Free-Hanging Type 178964-3 Vertical Type 178323-2 Panel Type - Horizontal Type 1-177662-2 Free-Hanging Type - Vertical Type 1-177665-2 * Part numbers refer only to the shown position size. For different position sizes and keyings please see catalog # 1-1773721-4. te.com/products/dynamicseries Board Mount Header Panel Type TE Connectivity Signal and Power Application SIGNAL AND POWER APPLICATION D-3000 SERIES Parts shown in grey above are actually black in color Type* Receptacle Housing D-3200S High-Voltage 1-Row Type (4 Pos.) 1-178128-4 D-3200M High-Voltage Modular Type (6 Pos.) 1-178129-6 D-3200T High Pressure 3-Row Type (9 Pos.) Tab Housing Part Number Board Mount Header Part Number Panel Type 1-179553-4 Horizontal Type 1-179277-2 Free-Hanging Type 1-179552-4 Vertical Type 1-917338-2 Panel Type 1-179555-3 Horizontal Type 1-178139-2 Free-Hanging Type 1-179554-3 Vertical Type 1-178140-2 1-178128-3 Panel Type - Horizontal Type 1-1123624-2 D-3400F Scyscraper Type (20 Pos.) 917249-1 Panel Type - Horizontal Type 917251-2 D-3500D Sensor Connector Type (12 Pos.) 175362-1 D-3700 Motor Connector** 176346-7 Panel Type 917241-6 Horizontal Type 177555-2 Free-Hanging type 917242-6 Vertical Type 316516-2 - - - - *  Part numbers refer only to the shown position size. For different position sizes and keyings please see catalog # 1-1773721-4. ** Not Pictured Above. te.com/products/dynamicseries TE Connectivity Power Application POWER APPLICATION D-4000 SERIES Parts shown in grey above are actually black in color Type* Receptacle Housing D-4200S High Current 1-Row Type (4 Pos.) 1-1747276-4 D-4200M Standard Modular 2-Row Type (6 Pos.) 1-1903329-3 Tab Housing Part Number Board Mount Header Part Number Panel 1-1747535-4 Horizontal 1-1903328-4 Free-Hanging Type 1-1747414-4 Vertical 1-1747277-4 Panel 1-1903331-3 Free-Hanging Type 1-1903330-3 - * Part numbers refer only to the shown position size. For different position sizes and keyings please see catalog # 1-1773721-4. POWER APPLICATION D-7000 SERIES Pin and Socket Housings Type D-7100 D-7300 Pos. Pin Contact Part 4 Part Number Socket Housing 2134055-1 Pin Housing 2134057-1 Socket Contact AWG* 8 Socket Contact 1871132-2 Pin Contact 1871131-2 * For other AWG numbers please refer to product catalog # 1-1773721-4. Board Mount Header (Horizontal) 1981823-1 Socket Housing 2134059-1 Pin Housing 2134061-1 Cable Ins. Diameter Board Mounted Header (Horizontal) 1981823-1 19-25 mm 2-2069313-1 2-2069312-1 25-31 mm 1-2069313-1 1-2069312-1 4 te.com/products/dynamicseries Dyna-Clamp D7100 Dyna-Clamp D7300 TE Connectivity Power Application POWER APPLICATION D-5000 SERIES Parts shown in grey above are actually black in color Type* D-5200S High-Voltage 1-Row Type (2 Pos.) Receptacle Housing 1-179958-2 D-5200M High-Voltage Modular Type (4 Pos.) 1-917807-2 D-5200Mα High-Current/ High-Voltage Modular Type (4 Pos.) D-5300 Reversed Installation Type (4 Pos.)** 1-1747822-2 Tab Housing Part Number Part Number 1-353047-2 Horizontal 1-353079-2 Free-Hanging Type 1-353046-2 Vertical 1-353080-2 Panel 1-917809-2 Horizontal 1-1123309-2 Free-Hanging Type 1-917808-2 Vertical 1-1981458-6 - - Horizontal 1-1318983-6 Vertical - Free-Hanging Type 1-1747820-2 - - *  Part numbers refer only to the shown position size. For different position sizes and keyings please see catalog # 1-1773721-4. ** Not Pictured Above. te.com/products/dynamicseries Board Mount Header Panel TE Connectivity Application Tooling APPLICATION TOOLING DYNAMIC Series includes several tooling solutions for automated termination, manual field termination as well as wire preparation equipment. For more information about the tooling & service options please go to http://www.te.com/en/products/application-tooling.html and choose your region. Mini Application Tools Hand Tools Series* D-1000 Series AWG 30 Part Number Series* Part Number 2255139-1 D-1000 Series AWG 30 2114042-2 D-2000 Series AWG 28 2255143-1 D-2000 Series AWG 28 2151240-1 D-3000 Series AWG 28 2255146-1 D-3000 Series AWG 28 2088631-2 D-4000 Series AWG 16 1762130-1 D-4000 Series AWG 16 1762120-2 D-5000 Series AWG 16 91596-1 D-5000 Series AWG 20 1528106-2 D-7000 Series AWG 16 409777-1 D-7000 Series AWG 12 Not Applicable *Tables above showing only smallest AWG sizes available. For different sizes and part numbers please see catalog # 1-1773721-4. AMP-3K/40 and AMP-5K/40 Terminating Machines Model AMP-O-LECTRIC Model G Terminating Machine Part Number AMP 3K - Universal Mounted 1725950-3 AMP 5K - Universal Mounted 1725900-3 Model AMP 3K - Quick Mounted 1-1725950-2 Terminator with Manual Crimp Adjust AMP 5K - Quick Mounted 1-1725900-2 CQM II Kit Request Catalog # 1654856 for specifications and part numbers te.com/products/dynamicseries Application using Crimp Quality Monitoring Application NOT using Crimp Quality Monitoring 1-356462-4 356462-2 2161280-1 Not Appplicable Request Catalog # 889021 for specifications and part numbers TE Connectivity Product and Application Specifications PRODUCT AND APPLICATION SPECIFICATIONS OVERVIEW For product samples and more information about how to use the document numbers below go to www.te.com or www.te.com/products/dynamicseries. Series 1000 Designation Description Product Specification 1100S Standard 1-Row 1100D Standard 2-Row 108-78268 (Gold Plating) 108-78298 (Tin Plating) 1100 SMT Surface Mount 108-78414 1200S High Voltage 1-Row 1200D 2000 3000 4000 5000 7000 High Voltage 2-Row 1500T Junction Box 1900 Spring Clamp 2100S Standard 1-Row 2100D Standard 2-Row 114-5377 108-78268 (Gold Plating) 108-78298 (Tin Plating) 108-78336 108-5619 2100M Drawer 108-5659 2600D Hybrid of Power and Signal Line 108-78301 2800 HTS Module 108-78284 3100S Standard 1-Row 3100D Standard 2-Row 3100M Standard Modular 3200S High Voltage 1-Row 3200M High Voltage Modular 3200T High Voltage 3-Row 3400F Skyscraper Connector 3500D Sensor Connector 3700 Motor Connector 114-5148 3800 HTS Module 108-78285 Spring Clamp 108-78400 108-78997 3950 Spring Clamp Standard 4200M Module 4800 HTS Module 5200S Standard 5200M High Voltage 5200Mα High Current 5300S Reversed Housing 1-Row 5300D Reversed Housing 2-Row 114-5258 108-5349 3900 4200S Application Specification 108-78182 114-5369 108-78388 108-5453 114-5206 5800 HTS Module 108-78389 DZ-5200 Board to Board 108-78186 - 5900 Spring Clamp 108-140022 114-5206 7100 Standard 7300 Reversed Housing 108-78470 114-5452 108-78406 - Dynamic Pneumatic Special Products te.com/products/dynamicseries Multiple Enclosure 108-78417 114-5377 Dynatap 108-78370 114-5206 Questions that will help you better select the product that you need: What are the current and voltage requirements for your Would you prefer to install wires directly into the housing applications? instead of using crimping tools? The Dynamic series connector family has different series that can handle between 3 and 65 amps as well as 125 volts up to 630 volts depending on the series The Dynamic series offers both the 1900 and 3900 series which are both spring clamp versions. These versions negate the need for crimp tooling and operations. In development now are the 5900 and 2900 respective spring clamp versions of 5000 and 2000 series. Also in development is the 3950, which is the new version of the 3900 spring clamp parts. What is the operating temperature range for your applications? The Dynamic Series connectors all have an operating range of -55 °C to +105 °C Do you need a connection that is rugged and vibration Will you need additional keying configurations? resistant? The Dynamic series are available in x,y,z,xx,yy,xy keying configurations to suit your needs. The Dynamic series is an extremely rugged connector family and features full box contacts with 3 points of contact for high electrical reliability. Do you need the ability to move equipment for inspection or line changes? The Dynamic series connectors all feature quick attach and detach housings that produce an audible click when mated. This allows for equipment to be quickly changed and removed for inspection. FOR MORE INFORMATION TE Technical Support Center Internet: te.com/help Australia: +86 400-820-6015 Austria: +43 1-9056-0 Belgium: +31 73-6246999 Brazil: +55 11-2103-6000 Canada: +1 905-475-6222 China: +86 400-820-6015 Czech Republic: +42 02-7201-1103 Denmark: +46 8-5072-5000 Estonia: +37 2677-8673 Finland: +46 8-5072-5000 France: +33 1-34-20-8686 Germany: +49 6151-607-1999 Greece: +97 1-4-347-0226 Holland: +31 73-6246999 Hungary: +36 1-2892040 India: +86 400-820-6015 Ireland: +1 800-882-391 Italy: +39 011-4012632 Japan: +044-844-8052 Korea: +02-3415-4607 Latvia: +37 2-6778-673 Lithuania: +37 037426900 Luxembourg: +31 73-6246999 Mexico: +52 0 55-1106-0800 Netherlands: +31 73-6246999 New Zealand: +86 400-820-6015 Norway: +46 8-5072-5000 Part numbers in this brochure are RoHS Compliant*, unless marked otherwise. *as defined www.te.com/leadfree te.com © 2014 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All Rights Reserved. 1-1773721-5 IND WR 09/2014 TE Connectivity and TE connectivity (logo) are trademarks. Other logos, product and/or company names might be trademarks of their respective owners. While TE has made every reasonable effort to ensure the accuracy of the information in this document, TE does not guarantee that it is error-free, nor does TE make any other representation, warranty or guarantee that the information is accurate, correct, reliable or current. TE reserves the right to make any adjustments to the information contained herein at any time without notice. TE expressly disclaims all implied warranties regarding the information contained herein, including, but not limited to, any implied warranties of merchantability or fitness for a particular purpose. The dimensions in this document are for reference purposes only and are subject to change without notice. Specifications are subject to change without notice. Consult TE for the latest dimensions and design specifications. Poland: Portugal: Russia: Slovakia: Slovenia: South Africa: Spain: Sweden: Switzerland: Taiwan: Turkey: United Kingdom: USA: +48 22-4576750 +34 91-6630420 +74 95-790-790-2200 +42 02-720-11102 +38 615-602-132 +97 150-457-0806 +34 932-910-330 +46 8-5072-5000 +41 71-447-0447 +86 400-820-6015 +90 212-282-6053 +44 0800-267666 +1 800-522-6752
