1445095-5

4 RELEASED FOR PUBLICATION THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 5 1 20 REVISIONS ALL RIGHTS RESERVED. BY - 20 2 3 6.00 P 9.24 REF 3.00 REF REF 1.30 CIRCUIT 1 C1 2.88 REF CONTACT C2 DESCRIPTION DATE DWN APVD REVISED PER ECR-16-011506 23JUN2017 NK CX ECO-19-006934 13MAY2019 AP WS 3.97 REF D 3.86 0.51 HOLDDOWN HOUSING DIM W # 0.39 LTR 1 MATERIAL: 2 PLATING: 4 RECOMMENDED PC BOARD THICKNESS OF 1.57. 5 KAPTON VACUUM PICK UP BUTTON. 6 PLATING: D CONTACTS - BRASS HOUSING - UL 94V-O RATED HIGH TEMP NYLON, COLOR BLACK. HOLDDOWNS: - PHOSPHOR BRONZE. CONTACTS - 0.76µm MINIMUM GOLD ON MATING END, 2.54µm MINIMUM TIN LEAD ON SOLDER TAILS, BOTH OVER 1.27µm MINIMUM NICKEL. HOLDDOWNS: 2.54µm MINIMUM MATTE TIN OVER 1.27µm MINIMUM NICKEL. CONTACTS - 0.76µm MINIMUM GOLD ON MATING END, 2.54µm MINIMUM MATTE TIN ON SOLDER TAILS, BOTH OVER 1.27µm MINIMUM NICKEL. HOLDDOWNS: 2.54µm MINIMUM MATTE TIN OVER 1.27µm MINIMUM NICKEL. C C 33.00 37.43 40.00 12 3-1445095-2 30.00 34.43 37.00 11 3-1445095-1 27.00 31.43 34.00 10 3-1445095-0 24.00 28.43 31.00 9 2-1445095-9 21.00 25.43 28.00 8 2-1445095-8 18.00 22.43 25.00 7 2-1445095-7 15.00 19.43 22.00 6 2-1445095-6 12.00 16.43 19.00 5 2-1445095-5 9.00 13.43 16.00 4 2-1445095-4 6.00 10.43 13.00 3 2-1445095-3 3.00 7.43 10.00 2 2-1445095-2 33.00 37.43 40.00 12 1-1445095-2 30.00 34.43 37.00 11 1-1445095-1 27.00 31.43 34.00 10 1-1445095-0 24.00 28.43 31.00 9 1445095-9 21.00 25.43 28.00 8 1445095-8 18.00 22.43 25.00 7 1445095-7 15.00 19.43 22.00 6 1445095-6 12.00 16.43 19.00 5 1445095-5 9.00 13.43 16.00 4 1445095-4 6.00 10.43 13.00 3 1445095-3 2 3.00 7.43 10.00 2 1445095-2 FINISH DIM Z DIM V DIM W NO. OF POSN PART NUMBER 6 6 6 6 6 6 6 6 INCLUDES CONTACT TAILS AND HOUSING STANDOFFS 6 6 B 6 SUPERSEDED BY 3-1445095-2 2 SUPERSEDED BY 3-1445095-1 SUPERSEDED BY 3-1445095-0 DIM Z 3.00 TYP 1.27 0.08 TYP 2 2 SUPERSEDED BY 2-1445095-9 2 SUPERSEDED BY 2-1445095-8 2 SUPERSEDED BY 2-1445095-7 CIRCUIT 1 2 SUPERSEDED BY 2-1445095-6 2 SUPERSEDED BY 2-1445095-5 3.20 2 SUPERSEDED BY 2-1445095-4 2 SUPERSEDED BY 2-1445095-3 2.54 2.41 A 0.08 2 PLC 0.08 SUPERSEDED BY 2-1445095-2 THIS DRAWING IS A CONTROLLED DOCUMENT. 2.15 DWN J.ROOT 09OCT2000 20-FEB-2001 K. WHITAKER APVD 20-FEB-2001 C. JONES TE Connectivity CHK TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: mm DIM V PCB LAYOUT COMPONENT SIDE 4 0 PLC 1 PLC 2 PLC 3 PLC 4 PLC ANGLES MATERIAL FINISH 1 1471-9 (3/13) 2 0.13 - SEE TABLE NAME PRODUCT SPEC 108-1836 APPLICATION SPEC - 114-13000 WEIGHT SIZE - CUSTOMER DRAWING B A VERTICAL SURF MOUNT HEADER ASSY, 30 MIC GOLD CONTACTS, THRU HOLE HOLDDOWNS,SGL ROW,MICRO MATE-N-LOK CAGE CODE A2 00779 TM RESTRICTED TO DRAWING NO 1445095 SCALE 5:1 SHEET 1 OF - 1 REV C2
