1587829-3

THIS DRAWING IS A CONTROLLED DOCUMENT. REVISIONS P LTR B3 B3 DESCRIPTION DWN DATE ECO-13-000550 ECO-14-000116 AT AT DS DS 10JAN2013 27FEB2014 ( nE) 20 ( 0.40 ) APVD ( 6.00 ) 1 MATERIAL: TYPE: COPPER ALLOY 2 FINISH: UNDERPLATE TYPE: NICKEL TOP PLATE TYPE: TIN 3. PARTS MUST BE FREE OF BURRS, CRACKS, OR OTHER VISUAL IMPERFECTIONS THAT MAY AFFECT FIT FORM OR FUNCTION 4 NOTE DELETED 5.41 6.10 7.70 SIZE C 1587829-3 4.11 4.76 6.40 SIZE A 1587829-1 COPYRIGHT 20 4.76 C THIS DRAWING IS UNPUBLISHED. ALL RIGHTS RESERVED. BY TYCO ELECTRONICS CORPORATION RELEASED FOR PUBLICATION ( 11.50 ) DIMENSIONS: DWN 01JUN2009 A TYLER PRODUCT SPEC 108-2394 FINISH 1- 114-13259 - CUSTOMER DRAWING PART NO 2 - TE Connectivity NAME APPLICATION SPEC - DESCRIPTION E MATERIAL 1587829-2 SIZE B - APVD - WEIGHT 1469-35 (3/13) 7.00 01JUN2009 CHK TOLERANCES UNLESS OTHERWISE SPECIFIED: 0.2 0.10 0.013 0.0001 MIN MAX WIRE O.D. D SIMPSON mm 0 PLC 1 PLC 2 PLC 3 PLC 4 PLC ANGLES 5.41 SIZE OUTER FERRULE, HVA280 CAGE CODE A4 00779 DRAWING NO RESTRICTED TO 1587829 SCALE 4:1 SHEET 1 OF - 1 REV B3
