QUICK REFERENCE GUIDE High Performance Interconnect (HPI) Connectors TE Connectivity’s (TE) wire-to-board High Performance Interconnect (HPI) connector system is available in 1.0mm, 1.25mm, 1.5mm, 2.0mm, and 2.5mm centerline pitch. This connector system offers vertical and horizontal (right angle) connector mounting for versatility, and the square-peg technology enables product compatibility with industry standard products. HPI products can be used anywhere a signal or low power needs to be routed through a device. If your application has more than one printed circuit board then HPI product is an option to connect the PCBs. FEATURES BENEFITS APPLICATIONS • 1.0mm – 2.5mm centerline • Provides design flexibility • Business and retail equipment • Vertical and horizontal PCB mount • Cost effective wire-to-board • Consumer devices • Through hole (DIP) & surface mount termination (SMT) • Ensures proper compatibility of both the header and the housing • Industrial • Polarized • Prevents stubbing contacts • Medical • Partially and fully shrouded • Enables inter-changeability with industry standard designs • Appliance • Square termination posts • Latching and gold plating options available • Reach up to 2A DATA AND DEVICES /// HIGH PERFORMANCE INTERCONNECT (HPI) CONNECTORS • Automotive High Performance Interconnect (HPI) Connectors Quick Reference Guide Components: How to Read Product Selector Dimensions Understanding HPI connector’s PCB footprint will help you quickly determine if the HPI product line is the correct wire-to-board solution to meet your design objectives. The part selector matrix helps you understand the PCB footprint. Note that only PCB headers have a PCB footprint, but the mating housing will also consume valuable space within a device, which is why we highlight both poducts’ dimensions. HOUSING DIMENSIONS HEADER DIMENSIONS Width (Z) Width (Z) Length (X) Length (X) Height (Y) Height (Y) The length (X) dimension is different for each position size, however, both the height (Y) and width (Z) are constant dimensions for each base PN. All the length dimensions are listed in the product selector table for a two position connector. The length of the connector is simply calculated. For example, If you decide that PN 1734595 is the connector that you need, then a two position connector’s length is 4.3mm. However, if you need a three position connector, the length of the connector is 5.3mm, which is 4.3mm + 1.0mm. Each additional position size requires an increase of 1.0mm. For example if you need a nine position connector please refer to the following equations. (Please refer to customer drawings for tolerances.) • 2 position length = 4.3mm • 9 positions – 2 positions = 7 positions • 7 positions * 1.0mm per pin increase = 7.0mm • 9 position length = 4.3mmm + 7.0mm = 11.3mm Reading Dimensions in the Product Matrix PIN Product Type AWG 1734595 Header 28-32 PCB Termination Mount Angle Style SMT Vertical Position Range Length (X) Height (Y) Width (Z) 2 to 15 4.3 + 1.0 Per Pin Increase 4.30 5.10 Connector Dimensions (mm) Product Overview, Ratings, and Specifications In order to better understand the product capabilities and limitations, it is advised that you refer to TE’s specifications. The following table is intended to be used with the product selector matrix. The product selector matrix has a column on the far right that indicates Spec. Group, which aligns with the first column on the left in the graph below. Spec Group A B Centerline (mm) PCB Rated Product Application Qualification Termination Specification Current Specification Reports Style Amps (Max.) 1.00 SMT 1.25 SMT & DIP C D E F 1.50 SMT G H I 2.00 SMT & DIP J K L 2.50 SMT & DIP Rated Voltage (Max.) Rated Voltage (Volts) Operating Temp. 108-57264 114-57020 501-57283 1.00 50 AC/DC -55 to 105°C 108-115169 114-115031 501-115186 1.00 50 AC -40 to 85°C 108-57225 114-57016 501-57229 1.00 100 AC -40 to 85°C 108-57499 114-57016 501-57573 1.00 125 AC/DC -25 to 85°C 108-57273 114-57016 501-57299 1.00 100 AC -40 to 85°C 108-57631 114-57018 501-57736 3.00 250 AC -55 to 105°C 108-51087 114-57011 501-51084 3.00 250 AC/DC -25 to 85°C 108-57100 114-57011 501-57058 3.00 250 AC/DC -25 to 85°C 108-57499 114-57011 501-57573 1.00 125 AC/DC -25 to 85°C 108-57217 114-57013 501-57218 3.00 100 DC -25 to 85°C 108-57099 114-57004 501-57057 3.00 250 AC/DC -25 to 85°C 108-57175 114-57012 501-57195 3.00 250 AC/DC -40 to 105°C Connector Dimensions (mm) DATA AND DEVICES /// HIGH PERFORMANCE INTERCONNECT (HPI) CONNECTORS PAGE 2 High Performance Interconnect (HPI) Connectors Quick Reference Guide Product Matrix: How to select a HPI connector part number The charts on this page highlight the relationship between the key product features, including AWG, PCB termination style, mount angle, position range, and dimensions to the product base number. Once you determine the correct base number, please refer to TE’s website. 1.00mm HPI Connector Base PN Product Type AWG PCB Termination Style Mount Position Angle Range Length (X) Height (Y) Width (Z) Mating Base PN Product Spec. Group 1734597-1 Contact 28 - 32 N/A N/A N/A N/A N/A N/A 1470364 A 1470364 Housing 28 - 32 N/A N/A 2 to 15 5.0 + 1.0 Per Pin Increase 2.80 5.00 1734595; 1734709 A 1734595 SMT Vertical 2 to 15 4.3 + 1.0 Per Pin Increase 4.30 5.10 1470364 A SMT Right Angle 2 to 15 4.3 + 1.0 Per Pin Increase 2.90 4.95 1470364 A 28 - 32 N/A N/A N/A N/A N/A N/A 2367198 B 28 - 32 N/A N/A 3 to 15 6.0 + 1.0 Per Pin Increase 2.8 5 2367196; 2367197 B 28 - 32 SMT Right Angle 3 to 15 5.0 + 1.0 Per Pin Increase 2.9 4.3 2367198 B 28 - 32 SMT Vertical 3 to 15 5.0 + 1.0 Per Pin Increase 4.3 2.9 2367198 B Length (X) Height (Y) Width (Z) Mating Base PN Product Spec. Group 1734709 Header 28 - 32 Header 28 - 32 Contact (Locking) Housing 2367198 (Locking) Header 2367196 (Locking) Header 2367197 (Locking) 2367199 Connector Dimensions (mm) The hand tool for terminal PN 1734597-1 is 2119536-1. 1.25mm HPI Connector Base PN Product Type AWG PCB Mount Position Termination Angle Range Style 1734193-1 Contact 28 - 32 N/A N/A N/A N/A N/A N/A 440146-x B 440146 Housing 28 - 32 N/A N/A 2 to 15 4.25 + 1.25 Per Pin Increase 3.15 3.95 1734260-x; 1734261-x; 1734829-x; 1734598-x B 1734260 Header 28 - 32 SMT Vertical 2 to 15 7.79 + 1.25 Per Pin Increase 4.75 4.25 440146-x C 1734261 Header 28 - 32 SMT 2 to 15 7.79 + 1.25 Per Pin Increase 3.45 4.70 440146-x D 1734829 Header 28 - 32 DIP 2 to 15 4.25 + 1.25 Per Pin Increase 3.20 4.70 440146-x C 1734598 Header 28 - 32 DIP 2 to 15 4.25 + 1.25 Per Pin Increase 4.70 3.20 440146-x D Length (X) Height (Y) Width (Z) Mating Base PN Product Spec. Group Right Angle Right Angle Vertical Connector Dimensions (mm) The hand tool for terminal PN 1734193-1 is 2119537-1. 1.50mm HPI Connector Base PN Product Type AWG 1775442-1 Contact 24 - 30 PCB Termination Style Mount Position Angle Range N/A N/A N/A N/A N/A N/A 1775441-x E 1775441 Housing 24 - 30 N/A N/A 2 to 15 4.25 + 1.50 Per Pin Increase 2.70 6.15 1775443-x; 1775444-x E 1775443 Header 24 - 30 SMT Vertical 2 to 15 4.50 + 1.50 Per Pin Increase 5.00 6.00 1775441-x E Connector Dimensions (mm) The hand tool for terminal PN 1775442-1 is 2119538-1. DATA AND DEVICES /// HIGH PERFORMANCE INTERCONNECT (HPI) CONNECTORS PAGE 3 High Performance Interconnect (HPI) Connectors Quick Reference Guide 2.00mm HPI Connector Base PN Product Type AWG PCB Termination Style 1735801-1 Contact 24 - 30 Mount Position Angle Range Length (X) Height (Y) Width (Z) N/A N/A N/A N/A N/A N/A Mating Base PN 440129-x; 1735447-x 440054-x; 440055-x; 1775470-x; 1775469-x; Product Spec. Group F 440129 Housing 24 - 30 N/A N/A 2 to 16 4.7 + 2.00 Per Pin Increase 4.50 6.90 440054 Header DIP Vertical 2 to 16 6.0 + 2.00 Per Pin Increase 6.05 4.70 440129-x G 2 to 16 6.0 + 2.00 Per Pin Increase 4.95 7.70 440129-x G 2 to 16 7.4 + 2.00 Per Pin Increase 6.15 5.40 440129-x G 2 to 16 7.4 + 2.00 Per Pin Increase 5.50 7.60 440129-x G 2 to 15 8.0 + 2.00 Per Pin Increase 5.60 6.00 440129-x H 24 - 30 440055 Header 24 - 30 DIP Right Angle 1775470 Header 24 - 30 SMT Vertical 1775469 Header 24 - 30 SMT 1734827 Header 24 - 30 SMT Housing 24 - 30 (Locking) Header 1735446 24 - 30 (Locking) 1735447 1470106-1 Contact 22 - 28 N/A N/A 3 to 16 7.92 + 2.00 Per Pin Increase 6.55 9.40 1735446-x F DIP Vertical 3 to 16 8.0 + 2.00 Per Pin Increase 6.07 5.20 1735447-x F N/A N/A N/A N/A N/A N/A 1470107-x I I 1470107* Housing 22 - 28 N/A 1470109* DIP 1470108* Header Header 22 - 28 22 - 28 Right Angle Right Angle G DIP 6 to 32 8.0 + 2.00 Per Pin Increase 5.10 7.40 1470109-x; 1470108-x Vertical 6 to 32 8.0 + 2.00 Per Pin Increase 6.50 5.00 1470107-x I 8.0 + 2.00 Per Pin Increase 5.00 9.50 1470107-x I Length (X) Height (Y) Width (Z) Mating Base PN Product Spec. Group N/A N/A N/A 440133-x J J N/A Right Angle 6 to 32 * = Dual Row Connectors Connector Dimensions (mm) The hand tool for terminal PNs 440132-1 and 1735801-1 is 2119539-1. 2.50mm HPI Connector Base PN Product Type AWG 440134-1 Contact 22 - 28 PCB Termination Style N/A Mount Position Angle Range N/A N/A 440133 Housing 22 - 28 N/A N/A 2 to 15 7.1 + 2.50 Per Pin Increase 4.20 7.15 440052-x, 440053-x; 1775317-x; 1775316-x 440052 Header DIP Vertical 2 to 15 7.5 + 2.50 Per Pin Increase 6.00 3.80 440133-x J 2 to 14 7.5 + 2.50 Per Pin Increase 4.20 8.20 440133-x J 2 to 15 9.5 + 2.50 Per Pin Increase 6.40 4.80 440133-x J 8.8 + 2.50 Per Pin Increase 4.80 7.70 440133-x J 22 - 28 440053 Header 22 - 28 DIP Right Angle 1775317 Header 22 - 28 SMT Vertical 22 - 28 SMT Right Angle 1470223-1 Contact 22 - 28 N/A N/A N/A N/A N/A N/A 1470222-x K 1470222 Housing 22 - 28 N/A N/A 2 to 15 7.4 + 2.50 Per Pin Increase 4.70 8.00 1470224-x K 1470224 DIP Vertical 2 to 15 7.5 + 2.50 Per Pin Increase 5.90 4.90 1470222-x K 1775316 Header Header 22 - 28 Connector Dimensions (mm) There are no hand tools available for these terminals. DATA AND DEVICES /// HIGH PERFORMANCE INTERCONNECT (HPI) CONNECTORS PAGE 4 High Performance Interconnect (HPI) Connectors Quick Reference Guide Applications Business & Retail Equipment • • • • • • • Copiers Printers Scanners Fax Machines Projectors Vending Machines ATMs Industrial Industry • • • • • • Appliances Industrial Controls GPS Thermostats HVAC Lighting Consumer Devices • • • • • PCs Ultrabook Devices Game Consoles Set Top Boxes Stereo Equipment Medical Industry • • • • Medical Monitors Imaging Systems Portable Stations Treatment Equipment Components: A Complete Solution A typical crimp type wire-to-board interconnect solution requires four components. First a raw discrete wire, which is stripped, and then a crimp type contact is crimped onto the wire. The contact and wire are then inserted into an unloaded receptacle housing, which is mated with a header that is terminated to a PCB either through hole (DIP) or SMT style. Raw Discrete Wire (Stripped) Crimp Contact Receptacle Housing PCB Header HPI Attributes PCB MOUNT ORIENTATION TERMINATION METHOD TO PCB SQUARE TERMINATION POSTS Depends on the direction that the housing mates with the PCB header. Depends on how the PCB header is applied to a PCB. Right Angle The housing is mated parallel to the PCB. Through Hole (DIP) Attached to PCB by inserting PCB tines into the pre-drilled holes in the PCB and then soldered on the bottom side of the board. This design is an industry standard that allows TE’s products to be interchanged with other industry standard products.  Vertical The housing is mated perpendicular to the PCB. Polarized Ensures that PCB headers and cable side receptacle housings properly mate.  Surface Mount (SMT) Attached to the PCB by soldering process where PCB tines are soldered to the top of a PCB. DATA AND DEVICES /// HIGH PERFORMANCE INTERCONNECT (HPI) CONNECTORS PAGE 5 High Performance Interconnect (HPI) Connectors Quick Reference Guide Frequently Asked Questions The charts on this page highlight the relationship between the key product features, including AWG, PCB termination style, mount angle, position range, and dimensions to the product base number. Once you determine the correct base number, please refer to TE’s website. Question 1 What gauge wire (AWG) will you be using? Answer 1 TE’s HPI product accepts 22-32 AWG discrete wire. Remember that the higher the AWG measurement number, the smaller the discrete wire. For example, 32 AWG is smaller than 22 AWG will likely have less current carrying capacity. Question 2 Are you transferring signal or lower power throughout your device? Answer 2 HPI products are simple interconnect solutions that can be used to transfer signal or lower power in multiple applications across many industries. Question 4 Does your application require a locking feature to strengthen the mating connection between the plug assembly and receptacle? Answer 4 If your application requires a secure mating retention feature, TE’s 1.0mm and 2.0mm HPI product line offers an external locking feature to improve the reliability of the interconnect system. Question 5 What are the technical requirements of your application? Question 3 Does your application have a fan, motor, switch, display, light or any other simple device? Answer 5 It is imperative that you ask your customer the current and voltage requirements of their application. Current, which is expressed in amps, is usually the driving factor when selecting a small pitch wire-to-board product. Other information that you should consider include operating temperature, PCB real estate, profile height limitations, material restrictions, etc. Answer 3 HPI product may be the ideal solution to control these type of ancillary items. Question 6 What tooling is available to apply TE’s wire-to-board products? Answer 6 TE’s tooling divisions offers a wide range of hand tools, semi-automatic, and automatic tools. Please visit https://www. te.com/usa-en/products/application-tooling.html to determine the application tooling that meets your needs. TE TECHNICAL SUPPORT CENTER USA: +1 (800) 522-6752 Canada: +1 (905) 475-6222 Mexico: +52 (0) 55-1106-0800 Latin/S. America: +54 (0) 11-4733-2200 Germany: +49 (0) 6251-133-1999 UK: +44 (0) 800-267666 France: +33 (0) 1-3420-8686 Netherlands: +31 (0) 73-6246-999 China: +86 (0) 400-820-6015 te.com TE, TE Connectivity, TE (logo) and TE connectivity (logo) are trademarks owned or licensed by the TE Connectivity Ltd. family of companies. All other logos, products and/or company names referred to herein might be trademarks of their respective owners. The information given herein, including drawings, illustrations and schematics which are intended for illustration purposes only, is believed to be reliable. However, TE Connectivity makes no warranties as to its accuracy or completeness and disclaims any liability in connection with its use. TE Connectivity’s obligations shall only be as set forth in TE Connectivity‘s Standard Terms and Conditions of Sale for this product and in no case will TE Connectivity be liable for any incidental, indirect or consequential damages arising out of the sale, resale, use or misuse of the product. Users of TE Connectivity products should make their own evaluation to determine the suitability of each such product for the specific application. © 2020 TE Connectivity Ltd. family of companies All Rights Reserved. 1-1773713-2  08/20   DND DATA AND DEVICES /// HIGH PERFORMANCE INTERCONNECT (HPI) CONNECTORS
