Section Catalog 1654365-1
Econoseal Connector Series
Issued 4-2010.
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Introduction
Connector Series for
Waterproof Protection
and Rugged Construction
Econoseal connectors are
used in extreme conditions.
Moisture, dust, corrosive
gasses and liquids result in
premature aging of electrical
contact systems which are
not adequately protected.
Typical applications include
the wiring of sensors in the
interior of motor hoods and
connections to electrical
control systems under
extremely unfavourable
climatic conditions.
The use of Econoseal sealed
housings can avoid contact
damage caused by environmental hazards.
All specifications subject to change. Consult TE Connectivity for latest specifications.
Econoseal Connector Series
■ Econoseal E Series
■ Econoseal EHM Series
■ Econoseal III .070 Series
• Wire-to-Board
• Wire-to-Wire
■ Econoseal III .250 Series
• Wire-to-Board
■ Econoseal J Series
19-1
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
CI2 Socket Contacts
Technical Features
Wire Type:
FLK and FLR
20.3
Wire Size Range:
0.5–2.5 mm2
1.8
Contact Material:
CuSn or CuZn
⭋ 2.7
Contact Finish:
Pre-tin plated
13.5
Insulation Diameter:
2.0–3.7 mm
2.9
1.4
Product Specification:
108-18125
⭋ 3.56
Application Specification:
114-18056
⭋ 3.15
Standard Extraction Tool:
Part No. 539972-1
⭋ 2.8
CI2 Socket Contacts
Contact
Type
Socket
Socket
SWS
✱)
Wire Size
Range
mm2
(AWG)
Insulation Diameter
FLK
FLR
mm
(Inch)
mm
(Inch)
Part Numbers
Material
and Finish ✱
Strip
Form
Package
Quantity
LoosePiece
◆ Applicator ◆
0.5–1.0
2.0–2.7
–
-1 / -2 / -4
827039
–
827396
–
1528546
>1.0–2.5>
2.4–3.7
–
-1 / -2 / -3
827040
–
827397
–
1528127
0.5–1.0
–
1.4–2.3
-1 / -2 / -4
927886
–
927887
–
1528817
>1.0–2.5>
–
2.1–3.1
-1 / -2 / -3
927890
–
927891
–
1528039
0.5–1.0
3.4
–
-1
964138
–
964139
–
on request
>1.0–2.5>
3.4
–
-1
968013
–
968014
–
on request
◆)
Material and Finish:
xxx-1 = CuSn4, tin plated
xxx-2 = CuZn30, tin plated
xxx-3 = CuSn4, silverplated
xxx-4 = CuSn4, silver plated
19-2
Package
Quantity
All specifications subject to change. Consult TE Connectivity for latest specifications.
Hand
Tool
–
m2063645-1
–
The pre- and suffix for the
applicators depends on the
applied termination equipment.
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
CI2 Pin Contacts
Technical Features
Wire Type:
FLK and FLR
2.9
22.0
Wire Size Range:
0.5–2.5 mm2
1.4
⭋ 1.59
Contact Material:
CuSn or CuZn
Contact Finish:
Pre-tin plated
1.8
Insulation Diameter:
2.0–3.7 mm
Product Specification:
108-18125
29.0
Application Specification:
114-18056
⭋ 2.8
Standard Extraction Tool:
Part No. 539972-1
⭋ 3.56
⭋ 3.15
CI2 Pin Contacts
Contact
Type
Pin
✱)
Wire Size
Range
mm2
(AWG)
Insulation Diameter
FLK
FLR
mm
(Inch)
mm
(Inch)
Part Numbers
Material
and Finish ✱
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
◆ Applicator ◆
0.5–1.0
2.0–2.7
–
-1 / -2
926980
–
926981
–
1528546
>1.0–2.5>
2.4–3.7
–
-1 / -2
926982
–
926983
–
1528127
0.5–1.0
–
1.4–2.3
-1 / -2
927884
–
927885
–
1528817
>1.0–2.5>
–
2.1–3.1
-1 / -2 / -3
927888
–
927889
–
1528039
◆)
Material and Finish:
xxx-1 = CuSn4, tin plated
xxx-2 = CuZn30, tin plated
xxx-3 = CuSn4, silverplated
xxx-4 = CuSn4, silver plated
All specifications subject to change. Consult TE Connectivity for latest specifications.
Hand
Tool
–
m2063645-1
The pre- and suffix for the
applicators depends on the
applied termination equipment.
19-3
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal III Connectors
Series .070 (1.8 mm)
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Socket Contacts
Technical Features
Low Current Wire-to-Wire
Connectors .070 Series (1.8 mm)
16.5
■ Free-hanging
■ .070 Series (1.8 mm)
blade and socket
3.8
■ 2-, 3-, 4-, 6- and 13-positions
2.8
■ Wire Size Range:
from 0.5 up to 2.0 mm2
■ Contact Rating:
up to 10 A constant
3.0
■ Lanceless contact system
7.0
■ Inertia locking
1.5
Application Specification:
114-3040
3.5
Standard Extraction Tool:
Part No. 1-1579007-5
Socket Contacts
Wire Size
Range
◆)
✱)
Insulation Diameter
FLK
FLR
Part Numbers
Material
and Finish
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
◆ Applicator ◆
Hand Tool
Copper alloy,
tin plated
345808-1
6,000
345949-1
1,000
1528040
on request
–
Copper alloy,
tin plated
345806-1
6,000
345150-1
1,000
1528416
on request
–
CuSn,
gold plated
✱ 344113-1 ✱
6,000
–
–
1528416
–
mm2
(AWG)
mm
(Inch)
mm
(Inch)
0.2–0.5
(24–20)
1.6–1.8
(.062–.070)
–
0.75–2.00
(18–14)
1.85–2.70
(.073–.106)
0.5–2.0
(20–14)
1.6–2.7
(.062–.106)
Applicators are application specific, consult TE Connectivity for details.
For 16 and 36 position socket housing.
19-4
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal III Connectors
Series .070 (1.8 mm)
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Pin Contacts / Single Wire Seals and Cavity Plugs
Pin Contacts,
Mates with
Socket Contacts
.070 Series
20.4
2.5
1.8
Standard Extraction Tool:
Part No. 1-1579007-5
Y
X
3.0
1.5
1.5
8.9
0.64
Y
X
1.7
Pin Contacts
Wire Size
Range
Insulation Diameter
FLK
FLR
Part Numbers
Material
and Finish
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
Copper alloy,
tin plated
345809-1
6,000
345951-1
2,000
1426288
1426650 (unsealed)
on request
–
Copper alloy,
tin plated
345807-1
6,000
345148-1
2,000
1528804
1426601 (unsealed)
on request
–
Copper alloy,
tin plated
345807-1
6,000
345148-1
2,000
1528804
1426601 (unsealed)
on request
mm2
(AWG)
mm
(Inch)
mm
(Inch)
0.5
(20)
1.6–1.8
(.062–.070)
–
0.75–1.00
(18–17)
1.85–2.10
(.073–.083)
1.5–2.0
(15–14)
2.3–2.7
(.091–.106)
◆
Applicator ◆
Hand Tool
◆
) Applicators are application specific, consult TE Connectivity for details.
Single Wire Seals
and Cavity Plugs
for Series .070 (1.8 mm)
11.8
⭋ 4.9 ±0.2
⭋ 3.0 ±0.3
⭋ 5.1 ±0.2
Application Specification:
108-3069
Insulation Diameter
(mm)
Color
Part Number
Package
Quantity
Black
345791-1
5,000
Black
172748-1
1,000
Grey
172888-2
5,000
Grey
172748-2
1,000
(Inch)
1.6–2.4
(.062–.095)
Cavity Plug
2.4 min. – 2.7 max.
Cavity Plug
(.095–.106)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-5
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal III Connectors
Series .250 (6.3 mm)
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Socket Contacts
Technical Features
High Current Wire-to-Wire
Connectors .250 Series
(6.3 mm)
19.7
■ Free hanging
■ .250 Series (6.3 mm)
FASTON blade and socket
■ 2-, 4- and 8-positions
■ Wire Size Range:
from 0.5 to 3.0 mm2
■ Contact Rating:
up to 20 A constant
■ Lanceless contact system
■ Inertia Locking
7.44
7.75
Application Specification:
114-3036
Extraction Tool:
Part No. 724712-1
Insertion Tool:
Part No. 344525-1
Socket Contacts
Wire Size
Range
◆)
Insulation Diameter
FLK
FLR
mm2
(AWG)
mm
(Inch)
mm
(Inch)
0.5–1.5
(20–15)
1.6–2.4
(.062–.095)
–
2.0–3.0
(14–12)
2.6–3.4
(.102–.134)
–
Part Numbers
Material
and Finish
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
◆ Applicator ◆
Hand Tool
539635-1
with Die-Set
CuZn,
pre-tin plated
344070-1
3,000
344995-1
1,000
1339706
539678-2
CuZn,
pre-tin plated
344009-1
3,000
344993-1
1,000
1529079
on request
Applicators are application specific, consult TE Connectivity for details.
19-6
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal III Connectors
Series .250 (6.3 mm)
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Pin Contacts / Single Wire Seals and Cavity Plugs
Pin Contact,
Mates with
Socket Contacts
.250 Series
24.7
Extraction Tool:
Part No. 724712-1
Insertion Tool:
Part No. 344525-1
3.15
13.3
0.81
Pin Contacts
Wire Size
Range
◆)
Part Numbers
Insulation Diameter
FLK
FLR
mm2
(AWG)
mm
(Inch)
mm
(Inch)
0.5–1.5
(20–15)
1.6–2.4
(.062–.095)
–
2.0–3.0
(14–12)
2.6–3.4
(.102–.134)
–
Material
and Finish
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
CuZn,
pre-tin plated
344069-1
3,000
344991-1
1,000
1339829
on request
CuZn,
pre-tin plated
344008-1
3,000
344989-1
1,000
1529135
on request
◆
Applicator ◆
Hand Tool
Applicators are application specific, consult TE Connectivity for details.
Single Wire Seals
and Cavity Plugs
for Series .250 (6.3 mm)
9.9
⭋ 8.6
⭋ 4.0
⭋ 8.9
Application Specification:
108-3069
Insulation Diameter
(mm)
Color
Part Number
Package
Quantity
Black
344095-1
500
Grey
172749-2
500
Black
172747-1
1,0001,
Grey
172749-2
500
(Inch)
1.6–2.4
(.062–.095)
Cavity Plug
2.6–3.4
(.102–.134)
Cavity Plug
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-7
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal J Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Socket Contacts
Technical Features
Wire Size Range:
0.20–1.25 mm2
(AWG 24–20 / AWG 20–16)
7.0
3.8
3.0
2.5
Contact Material:
CuSn or CuZn
2.8
Contact Finish:
Pre-tin plated
Insulation Diameter:
1.4–2.6 mm
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
16.5
Extraction Tool:
Part No. 937313-1
Socket Contacts
Wire Size
Range
(mm2 )
(AWG)
Wire Insulation
Diameter
(mm)
0.2–0.5
24–20
1.4–2.4
0.50–1.25
20–16
2.0–2.6
Part Numbers
Material
and Finish
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
Hand
Tool
Brass, pre-tin plated
171630-1
–
171699-1
–
Copper-Alloy, sel. gold plated
171630-5
–
–
–
–
Brass, pre-tin plated
171662-1
–
173707-1
–
91583-1
Copper-Alloy, pre-tin plated
171662-4
–
–
–
Copper-Alloy, sel. gold plated
171662-5
–
–
–
◆)
19-8
◆Applicator ◆
All specifications subject to change. Consult TE Connectivity for latest specifications.
1528276
1530013
91563-1
–
–
The pre- and suffix for the
applicators depends on the
applied termination equipment.
Section Catalog 1654365-1
Issued 4-2010.
Contacts for Econoseal J Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Pin Contacts
Technical Features
Wire Size Range:
0.20–1.25 mm2
(AWG 24–20 / AWG 20–16)
2.5
0.5
0.32
Contact Material:
CuSn or CuZn
0.8
Contact Finish:
Pre-tin plated
1.0
Insulation Diameter:
1.4–2.6 mm
Product Specification:
108-5262
Application Specification:
114-5082
20.4
Instruction Sheet:
412-5325
Extraction Tool:
Part No. 937313-1
Pin Contacts
Wire Size
Range
(mm2 )
(AWG)
Wire Insulation
Diameter
(mm)
0.2–0.5
24–20
1.4–2.4
0.50–1.25
20–16
2.0–2.6
Part Numbers
Material
and Finish
Strip
Form
Package
Quantity
LoosePiece
Package
Quantity
◆Applicator ◆
Hand
Tool
Brass, pre-tin plated
171631-1
–
173600-1
–
Brass, selective gold plated
171631-2
–
–
–
–
Brass, pre-tin plated
171661-1
–
173706-1
–
91585-1
Brass, selective gold plated
171661-2
–
–
–
◆)
All specifications subject to change. Consult TE Connectivity for latest specifications.
1528891
1528457
91563-1
–
The pre- and suffix for the
applicators depends on the
applied termination equipment.
19-9
Section Catalog 1654365-1
Econoseal Connector Series
Issued 4-2010.
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Engineering Notes
19-10
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Socket Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
1 Position Socket Housings
Technical Features
No. of Positions:
1 Position
Housing Material:
PA66 GF13
Wire Size Range:
0.5–2.5 mm2
Insertion Tool:
Part No. 826790-3
11.0
30.5
Extraction Tool:
Part No. 725840-1
Product Specification:
––
3.0
Application Specification:
––
6.0
1 Position Socket Housings
Part Number
Part Number
Keying Form
with the
Mating Connector
Wire Outside
Diameter
(mm)
Collar
Form
Housing
Color
Click Stop
2.3–3.0
Cone
Black
826882-4
Gray
826881-2
Click Stop
1.3–2.3
Cone
Black
826882-5
Black
826881-3
Socket
Housing
Color of
Wire Sealing
Mating
Pin Connector
Dust Cover for Socket Housings: Part No. 927536-1.
Other Housing Colors and Special Versions with Blind Plug on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-11
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Socket Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
2 Position Socket Housings
Technical Features
No. of Positions:
2 Positions
19.0
Housing Material:
PA66 GF13
Wire Size Range:
0.5–2.5 mm2
14.3
Insertion Tool:
Part No. 826790-3
Extraction Tool:
Part No. 725840-1
27.5
Product Specification:
––
Application Specification:
––
30.5
2 Position Socket Housings
Keying Form
with the
Mating Connector
Click Stop
Locking
19-12
Wire Outside
Diameter
(mm)
Part Number
Collar
Form
Housing
Color
Socket
Housing
Part Number
Color of
Wire Sealing
Mating
Pin Connector
2.3–3.0
Cone
Black
0-826884-2
Gray
1.3–2.3
Cone
Black
0-826884-3
Black
826883-1
2.3–3.0
Cone
Black
1-826884-2
Gray
826883-2
1.3–2.3
Cone
Black
1-826884-3
Black
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Socket Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
2 Position Socket Housings
Technical Features
No. of Positions:
2 Positions
Housing Material:
PA66 GF13
17.2
Wire Size Range:
0.5–2.5 mm2
Insertion Tool:
Part No. 826790-3
30.5
Extraction Tool:
Part No. 725840-1
Product Specification:
––
Application Specification:
––
30.5
2 Position Socket Housings
Keying Form
with the
Mating Connector
Click Stop
Locking
Wire Outside
Diameter
(mm)
Part Number
Collar
Form
Housing
Color
Socket
Housing
Part Number
Color of
Wire Sealing
Mating
Pin Connector
2.3–3.0
Round
Black
0-827438-1
Gray
1.3–2.3
Round
Black
0-827438-2
Black
826883-1
2.3–3.0
Round
Black
1-827438-1
Gray
826883-2
1.3–2.3
Round
Black
1-827438-2
Black
Dust Cover for Socket Housings: Part No. 927536-1.
Other Housing Colors and Special Versions with Blind Plug on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-13
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Socket Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
3 Position Socket Housings
Technical Features
No. of Positions:
3 Positions
19.0
30.5
Housing Material:
PA66 GF13
Wire Size Range:
0.5–2.5 mm2
Insertion Tool:
Part No. 826790-3
Extraction Tool:
Part No. 725840-1
Product Specification:
––
Application Specification:
––
30.5
3 Position Socket Housings
Keying Form
with the
Mating Connector
Click Stop
Locking
Wire Outside
Diameter
(mm)
Part Number
Collar
Form
Housing
Color
Socket
Housing
Mating
Pin Connector
2.3–3.0
Cone
Black
0-826886-4
Gray
1.3–2.3
Cone
Black
0-826886-7
Black
826885-2
2.3–3.0
Cone
Black
1-826886-2
Gray
826885-8
1.3–2.3
Cone
Black
1-826886-8
Black
Dust Cover for Socket Housings: Part No. 927536-1.
Front Plate for 3 Positioins Pin and Socket Housings: Part No. 826582-1.
Other Housing Colors and Special Versions with Blind Plug on request.
19-14
Part Number
Color of
Wire Sealing
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Socket Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
3 Position Socket Housings
Technical Features
No. of Positions:
3 Positions
30.5
Housing Material:
PA66 GF13
Wire Size Range:
0.5–2.5 mm2
16.8
14.3
Insertion Tool:
Part No. 826790-3
Extraction Tool:
Part No. 725840-1
12.0
Product Specification:
––
Application Specification:
––
27.5
3 Position Socket Housings
Keying Form
with the
Mating Connector
Locking
Wire Outside
Diameter
(mm)
Part Number
Collar
Form
Housing
Color
Socket
Housing
Part Number
Color of
Wire Sealing
2.3–3.0
Round
Black
1-827520-1
Gray
1.3–2.3
Round
Black
1-827520-2
Black
Mating
Pin Connector
–
Dust Cover for Socket Housings: Part No. 927536-1.
Front Plate for 3 Positioins Pin and Socket Housings: Part No. 826582-1.
Other Housing Colors and Special Versions with Blind Plug on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-15
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Pin Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
1 Position Pin Housings
Technical Features
No. of Positions:
1 Position
Housing Material:
PA66 GF13
Wire Size Range:
0.5–2.5 mm2
48.5
Insertion Tool:
Part No. 826791-3
11.0
Extraction Tool:
Part No. 725840-1
Product Specification:
––
Application Specification:
––
8.9
1 Position Pin Housings
Part Number
Part Number
Wire Outside
Diameter
(mm)
Collar Form
Housing
Color
2.3–3.0
Cone
Black
826881-2
Gray
826882-4
1.3–2.3
Cone
Black
826881-3
Black
826882-5
19-16
Pin
Housing
Color of
Wire Sealing
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Socket Housing
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Pin Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
2 Position Pin Housings
Technical Features
No. of Positions:
2 Positions
19.0
20.0
Housing Material:
PA66 GF13
16.8
Wire Size Range:
0.5–2.5 mm2
Insertion Tool:
Part No. 826791-3
18.4
3.0
Extraction Tool:
Part No. 725840-1
Product Specification:
––
Application Specification:
––
48.5
2 Position Pin Housings
Part Number
Part Number
Wire Outside
Diameter
(mm)
Collar Form
Housing
Color
2.3–3.0
Cone
Black
826883-1
Gray
826884-2
1.3–2.3
Cone
Black
826883-2
Black
826884-3
Pin
Housing
Color of
Wire Sealing
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Socket Housing
19-17
Section Catalog 1654365-1
Issued 4-2010.
Econoseal E Series
Sealed Pin Housings E Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
3 Position Pin Housings
Technical Features
No. of Positions:
3 Positions
Housing Material:
PA66 GF13
Wire Size Range:
0.5–2.5 mm2
48.5
Insertion Tool:
Part No. 826791-3
Extraction Tool:
Part No. 725840-1
Product Specification:
––
18.4
Application Specification:
––
17.37
19.0
3 Position Pin Housings
Part Number
Part Number
Wire Outside
Diameter
(mm)
Collar Form
Housing
Color
2.3–3.0
Cone
Black
826885-2
Gray
826886-4
1.3–2.3
Cone
Black
826885-8
Black
826886-7
19-18
Pin
Housing
Color of
Wire Sealing
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Socket Housing
Section Catalog 1654365-1
Issued 4-2010.
Econoseal EHM Series
Sealed Socket Housings EHM Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
2 Position Housings for 4.0 mm Socket Contact M27 Version
Technical Features
No. of Positions:
2 Positions
25.0
Housing Material:
PBT
Wire Size Range:
0.5–4.0 mm2
20.5
Socket Contact:
Part No. 962952-1
(0.5 to 1.0 mm2)
Part No. 962952-1
(1.0 to 2.5 mm2)
20.7
Wire Seal:
Part No. 963243-1
(1.4 to 2.1 mm diameter)
Part No. 963244-1
(2.2 to 3.0 mm diameter)
Cavity Plug:
Part No. 100132-1
33.0
Extraction Tool:
Part No. 1-1579007-9
Spare Tube:
Part No. 5-1579007-1
Wire Seal Hand Applicator:
Part No. 100653-1
2 Position Housings for 4.0 mm Socket Contact M27 Version
Part Numbers
Thread
Insulation
Diameter
(mm)
Cover
Right-Angle
Cover
Straight
Connector
Assembly
M27
1.4–3.0
100291-1
100292-1
100284-1
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-19
Section Catalog 1654365-1
Issued 4-2010.
Econoseal EHM Series
Sealed Socket Housings EHM Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
3 Position Housings for 4.0 mm Socket Contact M24 Version
Technical Features
No. of Positions:
3 Positions
Housing Material:
PBT
22.7
Wire Size Range:
0.5–4.0 mm2
Socket Contact:
Part No. 962952-1
(0.5 to 1.0 mm2)
Part No. 962952-1
(1.0 to 2.5 mm2)
33.0
Wire Seal:
Part No. 963243-1
(1.4 to 2.1 mm diameter)
Part No. 963244-1
(2.2 to 3.0 mm diameter)
20.7
Cavity Plug:
Part No. 100132-1
Extraction Tool:
Part No. 1-1579007-9
Spare Tube:
Part No. 5-1579007-1
Wire Seal Hand Applicator:
Part No. 100653-1
3 Position Housings for 4.0 mm Socket Contact M27 Version
19-20
Part Numbers
Thread
Insulation
Diameter
(mm)
Cover
Right-Angle
Cover
Straight
Connector
Assembly
M27
1.4–3.0
100291-1
100292-1
100285-1
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal EHM Series
Sealed Socket Housings EHM Series
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
4 Position Housings for 4.0 mm Socket Contact 16S Bayonet Version
Technical Features
No. of Positions:
4 Positions
31.4
Housing Material:
PBT
Wire Size Range:
0.5–4.0 mm2
24.0
Socket Contact:
Part No. 962952-1
(0.5 to 1.0 mm2)
Part No. 962952-1
(1.0 to 2.5 mm2)
30.9
Wire Seal:
Part No. 963243-1
(1.4 to 2.1 mm diameter)
Part No. 963244-1
(2.2 to 3.0 mm diameter)
Cavity Plug:
Part No. 100132-1
27.4
Extraction Tool:
Part No. 1-1579007-9
Spare Tube:
Part No. 5-1579007-1
Wire Seal Hand Applicator:
Part No. 100653-1
4 Position Housings for 4.0 mm Socket Contact M27 Version
Part Numbers
Thread
Insulation
Diameter
(mm)
Cover
Right-Angle
Cover
Straight
Connector
Assembly
M27
1.4–3.0
100130-1
–
100201-1
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-21
Section Catalog 1654365-1
Econoseal Connector Series
Issued 4-2010.
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Engineering Notes
19-22
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Board – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Socket Housings
Technical Features
No. of Positions:
18 Positions
30.5
32.5
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
36.2
19.7
25.6
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3114
38.3
Application Specification:
114-5082
27.0
21.0
40.8
18 Position Socket Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
Housing
Package
Quantity
Socket
Anti-Backout
344106-1
100
1344107-1
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating PCB Header
Right-Angle
Vertical
344103-1
–
19-23
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Board – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Socket Housings
Technical Features
No. of Positions:
36 Positions
30.5
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
25.7
19.45
34.0
36.35
Extraction Tool:
Part No. 1-1579007-5
62.1
Product Specification:
108-3114
68.3
Application Specification:
114-5082
27.0
21.0
36 Position Socket Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
19-24
Socket
Housing
Package
Quantity
Socket
Anti-Backout
344111-1
100
1344112-1
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating PCB Header
Right-Angle
Vertical
344108-1
–
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Board – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Printed Circuit Board Headers
Technical Features
No. of Positions:
18 Positions
3.0
37.6
Housing Material:
PA66
Product Specification:
108-3114
25.0
20.3
22.7
Application Specification:
––
26.8
40.7
39.0
18 Position PC Board Header
Part Numbers
Keying
Options
Housing
Color
–
Black
PCB Header
Right-Angle
Vertical
344103-1
–
All specifications subject to change. Consult TE Connectivity for latest specifications.
Package
Quantity
Mating
Socket Housing
195
344106-1
19-25
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Board – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Printed Circuit Board Headers
Technical Features
No. of Positions:
36 Positions
67.8
Housing Material:
PA66
Product Specification:
108-3114
25.0
20.3
Application Specification:
––
27.0
63.0
36 Position PC Board Header
Part Numbers
19-26
Keying
Options
Housing
Color
–
Black
PCB Header
Right-Angle
Vertical
344108-1
–
All specifications subject to change. Consult TE Connectivity for latest specifications.
Package
Quantity
Mating
Socket Housing
117
344111-1
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
2 Positions
3.0
27.6
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
15.0
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3069
15.35
1.8
Application Specification:
20.6
114-3040
2 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344276-1
500
345254-1
344274-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-27
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
3 Positions
9.6
27.6
2.75
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
Extraction Tool:
Part No. 1-1579007-5
2.0
20.3
Product Specification:
108-3069
Application Specification:
25.4
114-3040
3 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344273-1
500
345256-1
344271-1
Other colors on request.
19-28
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
4 Positions
20.6
2.9
25.6
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
21.6
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3069
4.8
Application Specification:
1.8
15.4
114-3040
27.6
4 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344270-1
500
345258-1
344268-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-29
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
6 Positions
9.6
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
26.18
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3069
20.2
27.6
23.8
Application Specification:
114-3040
25.4
6 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344267-1
500
345260-1
344265-1
Other colors on request.
19-30
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
13 Positions
24.6
34.95
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
32.05
Extraction Tool:
Part No. 1-1579007-5
26.95
Product Specification:
108-3069
Application Specification:
114-3040
33.4
13 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344263-1
200
345264-1
344260-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-31
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
2 Positions
15.13
32.5
Housing Material:
PA66
11.1
Wire Size Range:
0.2–2.0 mm2
16.55
Extraction Tool:
Part No. 1-1579007-5
6.55
Product Specification:
108-3069
18.33
Application Specification:
114-3040
3 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344274-1
4,000
345253-1
344276-1
Other colors on request.
19-32
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
2.15
No. of Positions:
3 Positions
19.9
15.7
Housing Material:
PA66
11.0
Wire Size Range:
0.2–2.0 mm2
6.55
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3069
9.6
16.2
Application Specification:
114-3040
32.5
3 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344271-1
3,300
345255-1
344273-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-33
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
4 Positions
4.8
Housing Material:
PA66
2.15
Wire Size Range:
0.2–2.0 mm2
5.6
17.7
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3069
0.85
16.2
Application Specification:
114-3040
35.5
4 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344268-1
2,500
345257-1
344270-1
Other colors on request.
19-34
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
6 Positions
19.98
2.15
24.6
0.85
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
17.7
Extraction Tool:
Part No. 1-1579007-5
6.95
Product Specification:
108-3069
23.18
Application Specification:
114-3040
6 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344265-1
2,000
345259-1
344267-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-35
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .070 Series
Wire-to-Wire – Low Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
13 Positions
29.5
35.5
Housing Material:
PA66
Wire Size Range:
0.2–2.0 mm2
23.25
29.8
Extraction Tool:
Part No. 1-1579007-5
Product Specification:
108-3069
Application Specification:
114-3040
32.7
13 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344260-1
1,000
345261-1
344263-1
Other colors on request.
19-36
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .250 Series
Wire-to-Wire – High Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
2 Positions
34.85
34.0
Housing Material:
PA66
Wire Size Range:
0.5–3.0 mm2
24.95
19.68
Extraction Tool:
Part No. 724712-1
Product Specification:
108-3069
18.8
Application Specification:
––
2 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344081-1
300
345089-1
344075-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-37
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .250 Series
Wire-to-Wire – High Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
4 Positions
34.05
43.85
Housing Material:
PA66
Wire Size Range:
0.5–3.0 mm2
34.08
18.8
Extraction Tool:
Part No. 724712-1
Product Specification:
108-3069
Application Specification:
––
27.8
4 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344080-1
150
344087-1
344074-1
Other colors on request.
19-38
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .250 Series
Wire-to-Wire – High Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Socket Housings
Technical Features
No. of Positions:
8 Positions
43.85
34.0
Housing Material:
PA66
Wire Size Range:
0.5–3.0 mm2
43.11
Extraction Tool:
Part No. 724712-1
38.7
Product Specification:
108-3069
Application Specification:
––
27.8
8 Position Socket Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Socket
Housing
Package
Quantity
Socket
Anti-Backout
Mating
Pin Housing
344079-1
100
344085-1
344073-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-39
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .250 Series
Wire-to-Wire – High Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
2 Positions
28.55
37.4
Housing Material:
PA66
19.23
17.25
Wire Size Range:
0.5–3.0 mm2
Extraction Tool:
Part No. 724713-1
Product Specification:
108-3069
Application Specification:
––
32.5
2 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344075-1
2,000
344090-1
344081-1
Other colors on request.
19-40
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .250 Series
Wire-to-Wire – High Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
4 Positions
37.5
15.2
Housing Material:
PA66
Wire Size Range:
0.5–3.0 mm2
9.0
28.4
Extraction Tool:
Part No. 724713-1
Product Specification:
108-3069
18.0
Application Specification:
––
27.8
37.4
4 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344074-1
1,000
344088-1
344080-1
Other colors on request.
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-41
Section Catalog 1654365-1
Issued 4-2010.
Econoseal III .250 Series
Wire-to-Wire – High Current
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Sealed Pin Housings
Technical Features
No. of Positions:
8 Positions
37.4
37.68
Housing Material:
PA66
Wire Size Range:
0.5–3.0 mm2
37.33
35.45
Extraction Tool:
Part No. 724713-1
Product Specification:
108-3069
Application Specification:
––
41.53
8 Position Pin Housing
✱)
Keying
Options
Housing
Color ✱
–
Black
Part Numbers
Pin
Housing
Package
Quantity
Pin
Anti-Backout
Mating
Socket Housing
344073-1
700
344086-1
344079-1
Other colors on request.
19-42
All specifications subject to change. Consult TE Connectivity for latest specifications.
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
1 Position Socket (Plug) Housing
Technical Features
No. of Positions:
1 Position
15.8
27.6
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
22.0
16.0
Product Specification:
108-5262
Application Specification:
114-5082
14.2
Instruction Sheet:
412-5325
1 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174877-2
100
Socket
Lock Plate
0- 174878-7 (Yellow)
Mating
Pin (Cap) Housing
174879-2
1-174878-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-43
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
2 Position Socket (Plug) Housing
Technical Features
No. of Positions:
2 Positions
27.6
20.6
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
22.8
17.3
Product Specification:
108-5262
Application Specification:
114-5082
14.2
Instruction Sheet:
412-5325
2 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174352-2
100
Socket
Lock Plate
0- 174353-7 (Yellow)
1-174353-1 (White)
19-44
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Pin (Cap) Housing
174354-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
3 Position Socket (Plug) Housing
Technical Features
No. of Positions:
3 Positions
27.6
25.4
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
22.8
17.3
Product Specification:
108-5262
Application Specification:
114-5082
19.0
Instruction Sheet:
412-5325
3 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174357-2
100
Socket
Lock Plate
0- 174358-7 (Yellow)
Mating
Pin (Cap) Housing
174359-2
1-174358-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-45
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
4 Position Socket (Plug) Housing
Technical Features
No. of Positions:
4 Positions
20.6
27.6
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
29.3
23.8
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
19.0
4 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174257-2
100
Socket
Lock Plate
0- 174258-7 (Yellow)
1-174258-1 (White)
19-46
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Pin (Cap) Housing
174259-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
6 Position Socket (Plug) Housing
Technical Features
No. of Positions:
6 Positions
20.2
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
17.3
29.3
Product Specification:
108-5262
9.6
Application Specification:
114-5082
25.4
Instruction Sheet:
412-5325
27.6
15.0
23.8
6 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174262-2
100
Socket
Lock Plate
0- 174263-7 (Yellow)
Mating
Pin (Cap) Housing
174264-2
1-174263-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-47
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
8 Position Socket (Plug) Housing
Technical Features
No. of Positions:
8 Positions
27.6
31.0
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
33.2
17.86
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
23.8
8 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174982-2
100
Socket
Lock Plate
0- 174983-7 (Yellow)
1-174983-1 (White)
19-48
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Pin (Cap) Housing
174984-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
10 Position Socket (Plug) Housing
Technical Features
No. of Positions:
10 Positions
35.8
27.6
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
33.2
18.18
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
28.6
10 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174655-2
100
Socket
Lock Plate
0- 174656-7 (Yellow)
Mating
Pin (Cap) Housing
174657-2
1-174656-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-49
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Socket (Plug) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
12 Position Socket (Plug) Housing
Technical Features
No. of Positions:
12 Positions
40.6
27.6
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
33.2
22.3
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
33.4
12 Position Socket (Plug) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Socket
(Plug) Housing
Package
Quantity
174661-2
100
Socket
Lock Plate
0- 174662-7 (Yellow)
1-174662-1 (White)
19-50
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating
Pin (Cap) Housing
174663-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
1 Position Pin (Cap) Housing
Technical Features
No. of Positions:
1 Position
32.5
10.3
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
12.7
12.7
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
13.5
1 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174879-2
100
Pin
Lock Plate
0- 174880-7 (Yellow)
Mating Socket
(Plug) Housing
174877-2
1-174880-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-51
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
2 Position Pin (Cap) Housing
Technical Features
No. of Positions:
2 Positions
15.1
32.5
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
11.1
12.7
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
18.3
2 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174354-2
100
Pin
Lock Plate
0- 174355-7 (Yellow)
1-174355-1 (White)
19-52
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating Socket
(Plug) Housing
174352-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
3 Position Pin (Cap) Housing
Technical Features
No. of Positions:
3 Positions
19.9
32.5
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
11.1
12.7
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
23.1
3 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174359-2
100
Pin
Lock Plate
0- 174360-7 (Yellow)
Mating Socket
(Plug) Housing
174357-2
1-174360-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-53
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
4 Position Pin (Cap) Housing
Technical Features
No. of Positions:
4 Positions
15.1
35.5
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
17.6
19.2
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
18.3
4 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174259-2
100
Pin
Lock Plate
0- 174260-7 (Yellow)
1-174260-1 (White)
19-54
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating Socket
(Plug) Housing
174257-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
6 Position Pin (Cap) Housing
Technical Features
No. of Positions:
6 Positions
35.5
19.9
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
17.6
19.2
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
23.1
6 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174264-2
100
Pin
Lock Plate
0- 174265-7 (Yellow)
Mating Socket
(Plug) Housing
174262-2
1-174265-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-55
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
8 Position Pin (Cap) Housing
Technical Features
No. of Positions:
8 Positions
24.7
36.5
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
20.55
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
27.9
8 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174984-2
100
Pin
Lock Plate
0- 174985-7 (Yellow)
1-174985-1 (White)
19-56
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating Socket
(Plug) Housing
174982-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
10 Position Pin (Cap) Housing
Technical Features
No. of Positions:
10 Positions
29.5
36.5
19.7
27.5
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
Product Specification:
108-5262
Application Specification:
114-5082
19.2
Instruction Sheet:
412-5325
16.8
10 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174657-2
100
Pin
Lock Plate
0- 174658-7 (Yellow)
Mating Socket
(Plug) Housing
174655-2
1-174658-1 (White)
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-57
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
12 Position Pin (Cap) Housing
Technical Features
No. of Positions:
12 Positions
36.5
34.3
Housing Material:
PBT
Wire Size Range:
0.20–1.25 mm2
(24–16 AWG)
26.85
17.39
Product Specification:
108-5262
Application Specification:
114-5082
Instruction Sheet:
412-5325
37.5
12 Position Pin (Cap) Housing
Part Numbers
Keying
Options
Housing
Color
–
Black
Pin
(Cap) Housing
Package
Quantity
174663-2
100
Pin
Lock Plate
0- 174664-7 (Yellow)
1-174664-1 (White)
19-58
All specifications subject to change. Consult TE Connectivity for latest specifications.
Mating Socket
(Plug) Housing
174661-2
Section Catalog 1654365-1
Issued 4-2010.
Econoseal J Series, Mark II (+)
Sealed Pin (Cap) Housings
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Single Wire Seals and Cavity Plugs
Single Wire Seals
and Cavity Plugs
⭋ 5.1
7.8
⭋ 1.3
⭋ 4.8
3.0
⭋ 2.6
Single Wire Seals and Cavity Plugs
Wire Size Range
2
mm
(AWG)
0.2–0.5
(24–20)
Insulation Diameter
mm
(Inch)
1.4–2.4
(.055–.094)
1.4–2.1
(.055–.083)
Material
and
(Color)
Part Number
A
172746-1
B
178210-1
C
172888-2
D
178210-1
NBR
(Black)
2.0–2.6
(.079–.102)
0.50–1.25
(20–16)
Style
NBR
(Gray)
2.0–2.6
(.079–.102)
NBR
(Black)
Cavity Plug
–
171631-1
171631-2
173600-1
171630-1
171630-5
171699-1
171661-1
171661-2
173706-1
171662-1
171662-4
171662-5
173707-1
172748-1
–
E
NBR
(Gray)
Use with
Contact
Part Number
172748-2
All specifications subject to change. Consult TE Connectivity for latest specifications.
19-59
Section Catalog 1654365-1
Econoseal Connector Series
Issued 4-2010.
Main Catalog 1654400-1
Chapter 19 – Issued 4-2010.
Engineering Notes
19-60
All specifications subject to change. Consult TE Connectivity for latest specifications.
工商网监
湘ICP备2023018690号
