2-2842244-0

4 C 2 3 1 REVISIONS 2019 TE Connectivity. All Rights Reserved. P DIM "G" A A1 (10.0) (6.5) 2.40 DWN APVD RELEASE TO PRODUCTION 09DEC2019 AY PS DIMENSION F REMOVED FROM PCB LAYOUT 11JUN2020 AY PS NOTES: 1. MATERIAL HOUSING & P&P CAP : HIGH TEMPERATURE THERMOPLASTIC, UL94-V0; COLOR- BLACK CONTACT PIN : COPPER ALLOY FINISH : MATING SIDE: MIN. 0.1 µm GOLD OVER NICKEL UNDER PLATING. SOLDER SIDE: MIN. 2.0 µm TIN OVER NICKEL UNDER PLATING. 3.60 7.5 MAX 7.80 (0.90) 6.40 #0.20 2.00 #0.10 2. PACKAGING: TUBE (WITH PICK AND PLACE CAP) 3 TOLERANCE NOT CUMULATIVE. 0.10 A 14-26 POS 6.00 #0.25 0.15 A ALL CONTACTS 30-50 POS C 4.50 #0.20 6.30 #0.20 C A 2 DATE D 1 ( o0.50) DESCRIPTION 3 D 2.00 #0.10 3 LTR 2.00 #0.10 3 DIM "F" # 0.20 DIM "E" # 0.3 B B 0.89 #0.08 3.00 #0.08 TYP. 7.50 1.50 2-2842244-0 AS SHOWN THIS DRAWING IS A CONTROLLED DOCUMENT. 2.00 A DIMENSIONS: mm PICK AND PLACE CAP CONTACT PIN HOUSING DESCRIPTION 1471-9 (3/13) 3 2 1 ITEM NO. MATERIAL SEE NOTES - TOLERANCES UNLESS OTHERWISE SPECIFIED: 0 PLC 1 PLC 2 PLC 3 PLC 4 PLC ANGLES FINISH 0.25 - - 12NOV2019 ANKIT YADAV CHK 25NOV2019 KARTHIK JK. APVD 27NOV2019 PRASHANTH S. DWN PRODUCT SPEC 108-64040 APPLICATION SPEC 2 $ 114-32259 WEIGHT CUSTOMER DRAWING 44 50.85 52.65 50 5-2842244-0 38 44.85 46.65 44 4-2842244-4 34 40.85 42.65 40 4-2842244-0 28 34.85 36.65 34 3-2842244-4 24 30.85 32.65 30 3-2842244-0 20 26.85 28.65 26 2-2842244-6 18 24.85 26.65 24 2-2842244-4 14 20.85 22.65 20 2-2842244-0 10 16.85 18.65 16 1-2842244-6 8 14.85 16.65 14 1-2842244-4 DIM "G" DIM "F" DIM "E" POS. TE PN. TE Connectivity NAME A AMPMODU 2mm, SHROUDED HEADER, DUAL ROW, VERTICAL SMD, 0.1 Au, TUBE WITH PICK AND PLACE CAP SIZE CAGE CODE A2 00779 RESTRICTED TO DRAWING NO 2842244 SCALE 5:1 SHEET 1 OF - 1 REV A1
