1534180-1
Housing for Female Terminals, Wire-to-Board / Wire-to-Device, 32 Position, .165 in / .
216 in / .33 in [4.2 mm / 8.5 mm / 5.5 mm] Centerline, Hybrid
1534180-1
ACTIVE
AMP | AMP MCP Connector System, AMP MCP Hybrids
TE Internal #: 1534180-1
Housing for Female Terminals, Wire-to-Board / Wire-to-Device, 32
Position, .165 in / .216 in / .33 in [4.2 mm / 8.5 mm / 5.5 mm]
Centerline, Hybrid
View on TE.com >
Connectors > Automotive Connectors > Automotive Housings > AMP MCP Unsealed Connector Housings
Connector System: Wire-to-Board, Wire-to-Device
Number of Positions: 32
Connector & Housing Type: Housing for Female Terminals
Centerline (Pitch): 4.2 mm, 5.5 mm, 8.5 mm [ .165 in, .216 in, .33 in ]
Sealable: No
All AMP MCP Unsealed Connector Housings (188)
Features
Product Type Features
Mixed & Hybrid Connector
No
Connector Shape
Rectangular
Connector System
Wire-to-Board, Wire-to-Device
Connector & Housing Type
Housing for Female Terminals
Sealable
No
Connector & Contact Terminates To
Wire & Cable
Primary Locking Feature
On the Terminal
Configuration Features
Number of Positions
32
Number of Rows
2
Electrical Characteristics
Operating Voltage
12 VDC
Nominal Voltage Architecture
12 V
Body Features
Cable Exit Angle
180°
Primary Product Color
Black
Connector & Keying Code
A
For support call+1 800 522 6752
01/02/2024 09:00AM | Page 1
1534180-1
Housing for Female Terminals, Wire-to-Board / Wire-to-Device, 32 Position, .165 in / .
216 in / .33 in [4.2 mm / 8.5 mm / 5.5 mm] Centerline, Hybrid
Connector & Keying Code
A
Contact Features
Contact Size
1.5mm, 2.8mm, 4.8mm
Contact Type
Receptacle
Mating Tab Width
1.5 mm, 2.8 mm, 4.8 mm[.06 in][.11 in][.188
in]
Contact Current Rating (Max)
20 A, 25 A, 35 A
Mechanical Attachment
Terminal Position Assurance
Yes
Strain Relief
Without
Mating Alignment Type
Keyed
Mating Alignment
With
Connector Mounting Type
Cable Mount (Free-Hanging)
Housing Features
Housing Material
PBT GF
Centerline (Pitch)
4.2 mm, 5.5 mm, 8.5 mm[.165 in][.216 in][.33
in]
Dimensions
Connector Height
25 mm[.984 in]
Product Width
29 mm[1.142 in]
Usage Conditions
Operating Temperature (Max)
130 °C[266 °F]
Operating Temperature Range
-40 – 130 °C[-40 – 266 °F]
Operation/Application
Circuit Application
Power
Packaging Features
Packaging Quantity
200
Packaging Method
Carton
Other
Serviceable
No
Connector Position Assurance Capable
No
Product Compliance
For compliance documentation, visit the product page on TE.com>
For support call+1 800 522 6752
01/02/2024 09:00AM | Page 2
1534180-1
Housing for Female Terminals, Wire-to-Board / Wire-to-Device, 32 Position, .165 in / .
216 in / .33 in [4.2 mm / 8.5 mm / 5.5 mm] Centerline, Hybrid
For compliance documentation, visit the product page on TE.com>
EU RoHS Directive 2011/65/EU
Compliant
EU ELV Directive 2000/53/EC
Compliant
China RoHS 2 Directive MIIT Order No 32, 2016
No Restricted Materials Above Threshold
EU REACH Regulation (EC) No. 1907/2006
Current ECHA Candidate List: JUNE 2023
(235)
Candidate List Declared Against: JUNE
2023 (235)
Does not contain REACH SVHC
Halogen Content
BFR/CFR/PVC Free, but Br/Cl >900 ppm in
other sources.
Solder Process Capability
Not applicable for solder process capability
Product Compliance Disclaimer
This information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge
based on the information they provided. This information is subject to change. The part numbers that TE has identified as
EU RoHS compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent
chromium, mercury, PBB, PBDE, DBP, BBP, DEHP, DIBP, and 0.01% for cadmium, or qualify for an exemption to these
limits as defined in the Annexes of Directive 2011/65/EU (RoHS2). Finished electrical and electronic equipment products
will be CE marked as required by Directive 2011/65/EU. Components may not be CE marked. Additionally, the part
numbers that TE has identified as EU ELV compliant have a maximum concentration of 0.1% by weight in homogenous
materials for lead, hexavalent chromium, and mercury, and 0.01% for cadmium, or qualify for an exemption to these limits
as defined in the Annexes of Directive 2000/53/EC (ELV). Regarding the REACH Regulation, the information TE provides
on SVHC in articles for this part number is based on the latest European Chemicals Agency (ECHA) ‘Guidance on
requirements for substances in articles’ posted at this URL: https://echa.europa.eu/guidance-documents/guidance-onreach
